D-Link DSL-G604T Manuel utilisateur

DSL-G604T

Softwareandspecificationssubjecttochangewithoutnotice.DSL-G604T.12062004

If any of the above items are missing, please contact your reseller.

CD-ROM with Manual

Before You Begin:

DSL-G604T Wireless ADSL Router

Check Your Package Contents

Wireless ADSL Router

12VAC, 1.2APower Adapter

Using a power

supply with a

differentvoltagerating

will damage this

product and void its

warranty.

This product can be setup usingThis product can be setup using

This product can be setup using

anan

any curry curr

y curry curr

y currenen

enen

ent Wt W

t Wt W

t Web breb br

eb breb br

eb browserowser

owserowser

owser, i.e, i.e

, i.e, i.e

, i.e.,.,

.,.,

Internet Explorer 6 or NetscapeInternet Explorer 6 or Netscape

Internet Explorer 6 or Netscape

Navigator 6.2.3 or aboveNavigator 6.2.3 or above

Navigator 6.2.3 or above

Pleasereadand makesureyouunderstand alltheprerequisitesfor proper installationof

your new ADSL Router. Have all the necessary information and equipment on hand

beforebeginningtheinstallation.

Ethernet Cable

Telephone Cord

802.11gAntenna

Hardware Overview

Front Panel

Power LED: Solid light

indicatesaconnectionto

agood powerconnector. Status LED: A blinking

light indicates normal

operation.If thislightisnot

litandthepowerlightison,

thisindicates failure.

ADSL LED: Lightssolid

when sychronized with

theADSLconnection. WLANLED:ThisLEDblinks

to indicate wireless activity.

LAN Ports: A solid light

indicates a connection

ontheassociatedport.A

blinking light indicates

activityontheassociated

port.

ResetButton: ResetstheDSL-G604T

tothefactorydefaultsettings.Holdfor

seven seconds for the unit to factory

reset.

Power Receptor: The AC

PowerAdapterconnectshere.

LAN Ports: Your computers

connect here using standard

Ethernetcables.

ADSL Port: Connects to

yourtelephonejackusing a

standardtelephonecord.

Rear Panel

Hardware Overview (continued)

Wireless Antenna:

Used for wireless

communication.

Hardware Installation

Step a

Step b

Step c

Hardware Installation (continued)

Connectthetelephonecordfromyourphone

jack to theADSLport on the DSL-G604T.

ConnectanEthernetcablefromyourcomputer

toa LAN port on the DSL-G604T.

Connect the power adapter to the power

connector on the DSL-G604T and the other

endtoaknowngoodpowersource.

Step a

Step b

Step c

Administhedefault User Name

andPassword.Type admin into

the User name and Password

fields.

Click OK

Typehttp://192.168.1.1 intothe

URL address box and press the

Enter or Return key.

Using the Setup Wizard

Click Run Wizard

Launch your Web browser

(a shortcut is typically found

onyour desktop).

Step a

Step b

Step c

Step d

Using the Setup Wizard (continued)

Click Next

This screen allows you to enter

a new password for the admin

account. This password is used

to log into the web-based

managementinterface.

SelectyourTime Zone

Click Next

Step e

Step f

Step g

You will need to select the Internet Connection Type. If you are unsure which type of

InternetConnectionyouhave,pleasecontactyour InternetService Provider.Therearefour

connectionmodesandsettingsvarydependingontheconnectiontype.

1. Dynamic IPAddress - see Dynamic IP Address on page 8.

2. Static IPAddress - see Static IP Address on page 9.

3. PPPoE/PPPoA - see PPPoE/PPPoA on page 9.

4. Bridge Mode - see Bridge Mode on page 10.

A checklist of necessary settings is provided in the Appendix. Contact your Internet Service

Provider to obtain the necessary details.

Using the Setup Wizard (continued)

Click Next

ClickClone MAC Address

Dynamic IP Address

Select your Connection Type

andproceed to step h1, h2, h3,

or h4 depending upon your

connection type.

The DSL-G604T defaults to the

most commonly used values in the

United States.

Note: If the MAC address does not

appear, please refer to the User

Manual on the CD-ROM.

Step h

Step h1

Step h2

Step h3

Step h4

Using the Setup Wizard (continued)

Static IP Address

Click Next

PPPoE/PPPoA

Click Next

The DSL-G604T defaults to the most

commonly used values in the United

States.The IP address information on

the right is only shown as an example

of the format that you will use.

The DSL-G604T defaults to the most

commonly used values in the United

States. Only modify these settings if

youaresuretheyneedtobechanged.

The User Name and Password will

be unique to your Internet account.

If you forget your account information,

please contact your Internet Service

Provider.

Step h2

Step h3

ClickRestart

Configurationiscomplete!Typein

a URL such as www.dlink.com

to test your connection.

Bridge Mode

Click Next

Using the Setup Wizard (continued)

Step h4

Step i

Step j
