2D-Link DIR-450 Quick Install Guide

Package Contents

If any of the above items are missing, please contact your reseller.

• D-Link DIR-450 Mobile Router

• Power Adapter

• Ethernet Cable

• Manual and Warranty on CD

Note: Using a power supply with a different voltage rating than the one included with

the DIR-450 will cause damage and void the warranty for this product.

• A compatible 32-bit PCMCIA (EVDO) card with service*

• Computers with Windows®, Macintosh®, or Linux-based operating systems

with an installed Ethernet adapter

• Internet Explorer Version 6.0 or Netscape Navigator™Version 6.0 and above

(for conﬁguration)

System Requirements

* Subject to services and service terms available from your carrier.

3 D-Link DIR-450 Quick Install Guide

Connect to your Network

Note: Ensure that power to your DIR-450 Mobile Router is not connected before

performing the installation steps below.

32-bit PCMCIA (EVDO) Card Connection

1. Attach the antenna.

a.Remove the antenna from its plastic wrapper.

b. Screw the antenna in a clockwise direction to the back panel of the

unit.

c. Once secured, position the antenna upward at its connecting joint. This

will ensure optimal reception.

2.Insert your wireless 32-bit PCMCIA (EVDO) card into the Internet Card

Slot on the back of the router.

3.Insert the Ethernet cable into LAN Port 1 on the back panel of the DIR-450

Mobile Router, and an available Ethernet port on the network adapter in

the computer you will use to conﬁgure the unit.

Note:The DIR-450 Mobile Router LAN Ports are “Auto-MDI/MDIX.”This provides

either patch or crossover Ethernet cable LAN Port access.

4.Connect the power adapter to the receptor on the back panel of your

DIR-450 Mobile Router. Then plug the other end of the power adapter into

a wall outlet or power strip.

a.The Power LED will turn ON to indicate power has been applied.

b. Other LEDs will ﬂash ON and OFF as the DIR-450 Mobile Router

performs initialization and Internet connection processes. This will take

a few minutes.

c. When complete, the following LEDs will illuminate blue: Power,

Status, Internet, WLAN, and LAN Port 1 (or your speciﬁc LAN Port

connection).

4D-Link DIR-450 Quick Install Guide

Using the Setup Wizard

Open your web browser and

type http://192.168.0.1 into

the URL address box. Press

Enter.

Type admin for the

username and leave

the password blank.

The logon pop-up screen will appear:

Once you have logged in, the Setup screen will appear:

Click Setup Wizard

5 D-Link DIR-450 Quick Install Guide

Click Launch Internet Connection Setup Wizard to begin.

Click Launch Internet

Connection Setup

Wizard

Click Next to continue.

Create a new password and then click Next to continue.

Click Next

Select your time zone from the drop-down menu and then click Next to

continue.

Click Next

6D-Link DIR-450 Quick Install Guide

Select the ISP Card from the drop-down list and then click Username /

Password Connection (WWAN). Click Next to continue.

Enter your WWAN user name, password, and server information. If you do

not have this information, please contact your ISP.

Click Connect to save your settings. Once the router is ﬁnished rebooting,

click Continue. Please allow 1-2 minutes to connect.

Click Next

Click Connect

7 D-Link DIR-450 Quick Install Guide

Notes

8D-Link DIR-450 Quick Install Guide

Technical Support

D-Link’s website contains the latest user documentation and

software updates for D-Link products.

U.S. and Canadian customers can contact D-Link Technical

Support through our website or by phone.

United States

Telephone

(888) 843-6100

Monday through Friday 8:00am - 5:00pm (PST)

World Wide Web

http://support.dlink.com

Canada

Telephone

(800) 361-5265

Monday through Friday, 7:30am to 9:00pm (EST)

World Wide Web

http://support.dlink.ca

Version 1.0

August 18, 2006

trademarks of D-Link Corporation or its subsidiaries in the United States and other countries. Other trademarks are the property

of their respective owners. Maximum wireless signal rate derived from IEEE Standard 802.11g speciﬁcations. Actual data

throughput will vary. Network conditions and environmental factors, including volume of network trafﬁc, building materials

and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless

signal range. Product speciﬁcations, size and shape are subject to change without notice, and actual product appearance may

differ from that depicted on the packaging. Visit www.dlink.com for more details.
