D-Link DWL-7100AP Manuel utilisateur

AirPremierTM AG Tri-mode

Dualband Wireless Access Point

Quick Install Guide+

Руководство по быстрой установке+

Guía de instalación rápida+

Guia de instalação rápida+

快速安裝手冊+

Petunjuk Pemasangan Cepat+

DWL-7100AP

This product can be set up using

any current Web browser, i.e.,

Internet Explorer 6 or Netscape

Navigator 6.2.3 or later.

5V DC, 2.0A

Power Adapter

holders. Software and specications subject to change without notice.

Before You Begin

Check Your Package Contents

DWL-7100AP Wireless Access Point

CD-ROM (containing Manual and Warranty)

Ethernet Cable

If any of the above items are missing, please contact

your reseller.

The default IP address for the DWL-7100AP is 192.168.0.50 with a subnet mask

of 255.255.255.0. For the purpose of configuring the DWL-7100AP you will

need to assign your computer a static IP address within the same range as the

DWL-7100AP’s IP address. See the Manual on the CD-ROM if you need assistance

in assigning a static IP address for your network adapter.

Using a power

supply with a

different voltage rating

will damage and void the

warranty of this product.

DWL-7100AP

D-Link AirPremierTM AG

Tri-mode Dualband Wireless

Access Point

Connecting The DWL-7100AP To

Your Network

A. First, connect the power adapter to the receptor at the back panel of

the DWL-7100AP and then plug the other end of the power adapter

to a wall outlet or power strip. The Power LED will turn ON to indicate

proper operation.

B. Insert an Ethernet cable into the LAN port on the back panel

of the DWL-7100AP and an available Ethernet port on the network

adapter in the computer you will use to congure the DWL-7100AP.

The Link LED for the LAN Port will illuminate to indicate a proper

connection.

C. Computers with 802.11a/b/g wireless adapters can connect to the

DWL-7100AP. The DWL-AG660 AirPremierTM Wireless Cardbus

Adapter and the DWL-AG530 AirPremierTM Wireless PCI Adapter will

connect, out of the box, with the DWL-7100AP, using their default

settings.

A. Receptor for

Power Adapter.

Reset Button

Pressing this button restores

the access point to its original

factory default settings.

B. LAN Port is for

connecting to a switch

on the local network

with an Ethernet cable

C. Antennas

Used to wirelessly

connect to 802.11a/b/g

adapters.

Using The Setup Wizard

When you have completed

the steps in this Quick

Installation Guide, your

connected network should

look similar to this:

The logon pop-up

screen will appear.

Type “admin” for the

username and leave

the password eld

blank.

Open your Web

browser and type

“http://192.168.0.50”

into the URL address

box. Then press the

Enter or Return key.

Click OK

Using The Setup Wizard (continued)

Once you have logged

in, the Home screen will

appear.

You will see the following

screens.

Click Run Wizard

Click Next

Step 1 - Set up your

new password. You

have the option to

establish a password.

Step 2 - Wireless LAN

802.11a Setup

The default wireless

settings are:

SSID = dlink

Channel = 52

You can change these

settings to match an

existing wireless network.

Step 3 - WEP Encryption

for 802.11a

The DWL-7100AP is

capable of 64-, 128-, and

152-bit encryption. Select

the key size you wish to

use and enter the key

in the eld provided. By

default, WEP is Disabled.

Click Next

dlink

Your Setup is Complete!

Click Next

Click Restart

Step 2 - Wireless LAN

802.11g Setup

The default wireless

settings are:

SSID = dlink

Channel = 6

You can change these

settings to match an

existing wireless network.

Step 3 - WEP Encryption

for 802.11g

The DWL-7100AP is

capable of 64-, 128-, and

152-bit encryption. Select

the key size you wish to

use and enter the key

in the eld provided. By

default, WEP is Disabled.

Click Next

dlink

You will be returned to the Home tab.

Click to Exit

For additional settings or information, refer to the Advanced, Tools, or

Status tabs on the web-management interface; or to the manual located

on the CD-ROM.

Technical Support

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

Australia:

Tel: 1300-766-868

24/7(24Hrs, 7days a week) technical support

http://www.dlink.com.au

e-mail: [email protected]

India:

Tel: 1800-222-002

9.00 AM to 9.00 PM. All days

http://www.dlink.co.in/support/productsupport.aspx

Indonesia, Malaysia, Singapore and Thailand:

Tel: +62-21-5731610 (Indonesia)

Tel: 1800-882-880 (Malaysia)

Tel: +65 6501 4200 (Singapore)

Tel: +66-2-719-8978/9 (Thailand)

24/7, for English Support Only

http://www.dlink.com.sg/support/

e-mail: [email protected]

Korea:

Tel: +82-2-2028-1815

Monday to Friday 9:00am to 6:00pm

http://www.d-link.co.kr

e-mail: [email protected]

New Zealand:

Tel: 0800-900-900

24/7(24Hrs, 7days a week) technical support

http://www.dlink.co.nz

e-mail: [email protected]

Technical Support

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

Egypt:

Tel: +202-2919035 or +202-2919047

Sunday to Thursday 9:00am to 5:00pm

http://support.dlink-me.com

Email: [email protected]

Iran:

Te: +98-21-88880918,19

Saturday to Thursday 9:00am to 5:00pm

http://support.dlink-me.com

Email : [email protected] & [email protected]

Israel:

Magshimim 20 St., Matalon center,

Petach Tikva, Israel 49348

Consumer support line: 03-9212886

Business support line: 03-9212608

Pakistan:

Tel: +92-21-4548158 or +92-21-4548310

Monday to Friday 10:00am to 6:00pm

http://support.dlink-me.com

E-mail: [email protected]

South Africa and Sub Sahara Region:

Tel: +27-12-665-2165

08600 DLINK (for South Africa only)

Monday to Friday 8:30am to 9:00pm South Africa Time

http://www.d-link.co.za

Turkey:

Tel: +90-212-2895659

Monday to Friday 9:00am to 6:00pm

http://www.dlink.com.tr

e-mail: [email protected]

U.A.E and North Africa:

Tel: +971-4-4278127 (U.A.E)

Sunday to Thursday 9.00AM to 6.00PM GMT+4

Web: http://www.dlink-me.com

E-mail: [email protected]

Saudi ARABIA (KSA):

Telephone : +966 01 217 0008

Facsimile : +966 01 217 0009

e-mail: [email protected]

Saturday to Wednesday 9.30AM to 6.30PM

Thursdays 9.30AM to 2.00 PM
