Quick Installation Guide

Nuclias Connect AC1200 Wave 2 Outdoor Access Point

LAN2 LAN1(PoE)

Contents

English 1

DAP-3666 Quick Installation Guide 1

ENGLISH

Hardware Overview

LED Indicators

LAN2 LAN1(PoE)

Figure 1: Front Panel LED

# LED Description

1Power/

Status

Green (Solid) - Device operational

Red (Flashing) - Device booting

up/Device malfunctioned

Red (Solid) - Device boot up

has failed

Table 1: LED Description

Interface Connectors

LAN2 LAN1(PoE)

Figure 2: Bottom Connectors

# Connector Description

1Mounting

Lock

Connector for the mount screw.

2 Reset Press and hold for 10 seconds to

factory reset the device.

3 LAN2 Port Gigabit RJ-45 port for data.

4LAN1(PoE)

Port

Gigabit RJ-45 port for data and

Power over Ethernet (PoE) power.

Table 2: Interface Description

Before You Begin

This installation guide provides instructions

for installing the DAP-3666 on your network.

Additional documentation is also available on

the D-Link support website.

• Nuclias Connect Manual: For additional

information and instructions on how

to configure the device using Nuclias

Connect.

• DAP-3666 User Manual: For additional

information and instructions on how to

conﬁgure the device using the web user

interface.

Package Contents

This DAP-3666 package includes the following

items:

• DAP-3666 Access Point

• Mounting Plate and Hardware

• Grounding Wire

• Quick Start Guide

If any of the above items are damaged or

missing, please contact your local D-Link reseller.

Note: To power the unit, use an 802.3af or

802.3at PoE Switch or PoE Injector.

System Requirements

• Computers with Windows®, Macintosh®,

or Linux-based operating systems with an

installed Ethernet Adapter

• Internet Explorer 11, Safari 7, Firefox 28,

or Google Chrome 33 and above (for

conﬁguration)

1 2 3 4

2DAP-3666 Quick Installation Guide

ENGLISH

LAN2 LAN1(PoE)

Figure 3: Rear Connectors

# Connector Description

1Grounding

Wire

Connector for the grounding wire.

2Wall/Pole

Mount

Mount to connect to the

mounting plate on a wall or

a pole.

Table 3: Interface Description

Installation

The DAP-3666 can be powered using one of the

following two methods:

Using Power over Ethernet (PoE)

1. Use a standard Ethernet cable to connect

the LAN1(PoE) port on the DAP-3666

to a PoE power source device such as

an 802.3af or 802.3at PoE switch or PoE

injector.

Conguration

Using Nuclias Connect

The DAP-3666 is designed to be managed

through Nuclias Connect. Refer to the Nuclias

Connect Manual for detailed configuration

instructions.

Manual Conguration

Note: D-Link recommends manually conﬁguring

the device before mounting it.The management

computer, DHCP server and DAP-3666 must be

in the same subnet.

Use one of the following methods to access the

web user interface:

Connecting through Ethernet

1. Use an Ethernet cable to connect the

DAP-3666 to the management computer,

or to the switch or router the management

computer is connected to.

2. Manage the access point from a computer.

Enter dap3666.local in the address ﬁeld

of your browser.

3. Log in to the administration user

interface. The default login information is

Username: admin

Password: admin

Connecting Wirelessly

1. Connect the management computer to

the default SSID of the DAP-3666, “dlink”.

2. Manage the access point from a computer.

Enter dap3666.local in the address ﬁeld

of your browser.

DAP-3666 Quick Installation Guide 3

ENGLISH

3. Log in to the administration user

interface. The default login information is

Username: admin

Password: admin

Mounting

Figure 4: LAN Port Waterproof Enclosure

1. Connect an Ethernet Cable to the

LAN1(PoE) port on the DAP-3666. Use

the LAN Port Waterproof Enclosures to

seal the ports.

Mounting on a Pole

Figure 5: Attaching the Mounting Plate

1. Secure mount base to the pole with the

two stainless tie back strap sets. Ensure

that the tie back is locked securely.

Figure 6: Mounting the Device

2. Align and slide the DAP-3666 down so

that the mounting plate securely locks to

the DAP-3666.

Mounting on a Solid Wall

Figure 7: Attaching the Mounting Plate

1. Use the mounting plate to mark the

location where to drill the holes in the wall.

2. Drill holes on the markings and place the

included anchors into the drilled holes.

3. Align and place the mounting plate on

top of the anchors and use the included

screws to secure the mounting plate to

the surface.

Gland Sealing

Nut

Sealing

4DAP-3666 Quick Installation Guide

ENGLISH

Figure 8: Mounting the Device

4. Align and slide the DAP-3666 down so

that the mounting plate securely locks to

the DAP-3666.

Securing the Mount Screw and

Connecting the Grounding Wire

Figure 9: Attaching the Mount Screw

1. Use the included mount screw (hexagonal

hole) to lock the DAP-3666 to the pole/

wall mount.

Figure 10: Securing the Mount Screw

2. With the included hexagon socket

spanner, tighten the mount screw until

the DAP-3666 is secured.

Figure 11: Attaching the Grounding Wire

3. A grounding wire is recommended to

protect your device from lightning strikes

and the buildup of static electricity. Attach

the grounding wire to the DAP-3666 using

the included screw.

Figure 12: Attaching the Grounding Wire

4. Tighten the grounding wire (green-and-

yellow, 18AWG) to the DAP-3666 until it is

securely attached.

TECHNICAL SUPPORT dlink.com/support

DAP-3666 Quick Installation Guide 5

ENGLISH

Figure 13: Attaching the Grounding Wire

5. Attach the other end of the grounding

wire to either the wall or pole mount.

Ensure that the wall or pole mount is

connected to an electrical ground.

ErP Power Usage

This device is an Energy Related Product (ErP) that automatically switches to a power-saving Network

Standby mode within 1 minute of no packets being transmitted. It can also be turned o through a

power switch to save energy when it is not needed.

Network Standby: 5.84 watts

Federal Communication Commission Interference Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment o and on, the user is encouraged to try to correct the

interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Caution:

• Any changes or modications not expressly approved by the party responsible for compliance

could void the user’s authority to operate this equipment.

• This transmitter must not be co-located or operating in conjunction with any other antenna or

transmitter.

Appendix - Statements

Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

This equipment should be installed and operated with minimum distance 20cm between the radiator &

your body.

Note: The country code selection is for non-US model only and is not available to all US model. Per FCC

regulation, all WiFi product marketed in US must xed to US operation channels only.

Déclaration d’exposition aux radiations

Cet équipement est conforme aux limites d’exposition aux rayonnements ISED établies pour un

environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 0.28 m de

distance entre la source de rayonnement et votre corps.

Japan Voluntary Control Council for Interference Statement

この装置は、クラス B情報技術装置です。この装置は、家庭環境で使用することを目的としてい

ますが、この装置がラジオやテレビジョン受信機に近接して使用されると、受信障害を引き起こ

すことがあります。

取扱説明書に従って正しい取り扱いをして下さい。

Japan Voluntary Control Council for Interference Statement

This is a Class B product based on the standard of the VCCI Council. If this is used near a radio or

television receiver in a domestic environment, it may cause radio interference. Install and use the

equipment according to the instruction manual.

電波法により5GHz帯は屋内使用に限ります。

Product and Warranty Information

To nd out more about D-Link Nuclias product or marketing information, please visit the website

http://www.dlink.com or https://www.nuclias.com.

The D-Link Limited Lifetime Warranty information is available at

http://www.dlink.com/warranty

VCCI-B

Notes
