Quick Installation Guide

Wireless 108G Exterior Access Point

DAP-3220

2

DAP-3220 Wireless 108 G

Exterior Access Point

Using a power adapter with a different

voltage rating will damage and void the

warranty of this product.

System Requirements

Minimum System Requirements:

• CD-ROM Drive

• Computers with Windows®, Macintosh®, or Linux-based

operating systems

• Installed Ethernet Adapter, Internet Explorer version 6.0 or Netscape

Navigator™ version 7.0 and above

Power over Ethernet

base unit

CD-ROM with Manual

Power Adapter - DC 48V, 0.4A

Mounting Plate

4m Ethernet Cable Power cord

Screws Grounding Wire

Package Contents

3

This product should ONLY be installed by an experienced installer

who is familliar with local building and safety codes and where ever

applicable, is licensed by the appropriate authorities. Failure to do so

may void the D-Link product warranty and may expose the end user

or the service provider to legal and nancial liabilities. D-Link and its

resellers or distributors are not liable for injury, damage, or violation of

regulations associated with the installation of outdoor units or antennas.

A safety grounding system is necessary to protect your outdoor installation

from lightning strikes and the build-up of static electricity. The grounding

system must comply with the National Electrical Code and safety standards

that apply in your country. Always check with a qualied electrician if you

are in doubt as to whether your outdoor installation is properly grounded.

Important Information

It’s best to use a computer (with an Ethernet adapter) connected to a switch

to congure the DAP-3220. The default IP address for the DAP-3220 is

192.168.0.50 with a subnet mask of 255.255.255.0 on the wired Ethernet

side. You will need to assign your computer a static IP address within the

same range as the DAP-3220’s IP address for the purpose of conguring

the DAP-3220. If you need assistance assigning a static IP address

to your network adapter, please refer to the manual on the CD-ROM.

Before You Begin

DAP-3220 is certied to IP65 which means the device is protected

from dust and low pressure jets of water from all directions - limited

ingress permitted. It is recommended to place this device under a roof.

4

Physical Installation

Connect the supplied

Ethernet cable with the

waterproof enclosure to

the Ethernet port on the

DAP-3220 and attach the

grounding wire.

5

Step 1: Insert provided wall anchors in the wall where the mounting plate will be

attached.

Mounting Plate Assembly

Step 2: Use the provided screws to secure the mounting plate on the wall.

6

Step 3: Attach the remaining screws securely to the back of the

DAP-3220.

Step 4: Attach the DAP-3220 to the mounting plate.

7

Step 5: Slide the DAP-3220 down into the grooves on the mounting plate to secure

it to the plate.

8

Installing the Hardware

Step 1

Step 2

Connect one end of an Ethernet cable (included with your package)

to the LAN port on the DAP-3220 and the other end of the Ethernet

cable to the port labeled P+DATA OUT on the PoE base unit.

Connect another Ethernet cable from the DATA IN port on the PoE

base unit to your router/switch or to a PC.

Attach the power adapter to the connector labeled POWER IN on the PoE base unit.

Attach the power cord to the power adapter and into an electrical outlet.

Step 3

9

When you have completed the steps in this Installation Guide and congured your

DAP-3220 for your network, your network should look similar to this:

Your Setup is Complete

10

AP Mode:

Bridging Mode:
