D-Link DSL-564T Manuel utilisateur

BeforeYouBegin

Makesure you have allthenecessaryinformation andequipmentonhandbefore beginning

the installation.

CheckYourPackage Contents

This product can be set

up using any currentweb

browser, i.e., Internet

Explorer 6 or Netscape

Navigator 6.2.3.

DSL

ADSLRouter

specifications subject to change without notice.

DSL-564T ADSL Router

CD-ROM(containingManual)

Ethernet (CAT5 UTP) Cable

Telephone Cable

Power Adapter

If anyofthe above itemsare missing, please contactyour reseller

Using a power supply

with a differentvoltage

rating will damage and void

thewarranty for this product.

ENGLISH

Connecting the Routerto YourComputer

A. First, connectthe power adapterto the receptor at the back panelofthe

DSL-564Tand thenplugtheother endof the power adapter to awall outletor

power strip.The Power LED will turn ON toindicate proper operation.

B. Insert one endof thecableinto any Ethernet port on the back panelofthe

DSL-564Tand the otherend ofthe cable toan Ethernet Adapter or availableEthernet

port on your computer.

C. Insert one endof the Telephonecable into the ADSLport ontherear panel ofthe

outer and insertthe otherend intothewallsocket.Ifyouneedto install a lowpass filter,

followtheinstructions of your ISP.

ADSL port -

connect to

ADSL line

Ethernetports -

connectto

Ethernet cable

Factory

Reset

button

Power input-

connect to power

adapter

Configuring the Router

To useyour Web browserto access theweb pages used tosetup the Router,your computer

must be configured to Obtain an IPaddressautomatically”,that is, you must change the

IP network settings ofyour computer so that it isa DHCPClient. If you areusing Windows

XP and donot knowhowto change yournetwork settings, skipahead to Appendix and read

the instructions provided. You mayalso readtheUser Manual for instructions on changing IP

settingsfor computers running Windowsoperating systems.

Openyour Web browser and type

http://192.168.1.1”intotheURLaddress

box.Then presstheEnter or Return key.

The Login page appears.

Type admin”for the

admin”in the

Password field.

Click Login

ENGLISH

Configuring the Router(continued)

Once you haveloggedin,the Home screenwillappear.Click the Setup tabto go to the Setup

menuandconfigure the Router.

Click Setup

Configuring the Router(continued)

In the Setup menu, click the Connection 1 button togo totheconfigurationmenu for the

Internetconnection.

Click Connection 1

ENGLISH

Configuring the Router(continued)

In the Connection 1 menu, type the Username and Password used toverifytheidentity of

your ISPaccount. It maybe necessary to change the PPPencapsulation Type usedfor your

connection. You mayalso need tochange the VPI or VCI value. Your ISPwillgive these

settingsto youiftheyneed to be changed. Click the Apply buttonwhen you have entered all

the information. Tosavethe changes made toConnection 1, click the Tools tab and followthe

instructions onthenextpage.

A. Type the Username

and Password used for

your account.

D. Click Tools when

you have applied the

newsettings.

C. Click the Apply button

after youhave entered the

accountinformation.

B. Check the PPP

encapsulation Type,

VPI: and VCI: - if these

valuesare not correct,

change these according

to the instructions of

your ISP.

Configuring the Router(continued)

Nowsave the changesyou havejust made. TheSave function is accessed fromtheSystem

Commandsmenu. Clickthe System Commands button to viewthatmenu.

Click System Commands to

viewthemenu used to save

changes.

ENGLISH

Configuring the Router(continued)

To savethenewsettings,click the Save All buttonin the System Commands menu. Aftera

fewseconds, the changes will besaved. The Router will automaticallyestablish the Internet

connection aftera fewmore seconds.

Waitafewsecondsfor the Internetconnection tobe establishedandproceed toaccess the

Internetviayour webbrowser.

Click Save All to save

the newsettings.

Appendix

For additional settingsorinformation, referto the Advanced,Tools, or Status tabs on the

web-management interface;or to the manual located ontheCD-ROM.

Configuring IPSettings in Windows XP

Usethefollowingstepsto configure acomputer running Windows XPto be aDHCPclient.

1. From the Start menuon your desktop, go to Settings,then click on Network

Connections.

2. In the Network Connections window,right-click on LAN (LocalAreaConnection),

thenclick Properties.

Right-click on the Local Area

Connection icon and Select the

Properties option from the pull-

down

menu.

ENGLISH

3. In the General tabofthe Local Area Connection Properties menu, highlight Internet

Protocol(TCP/IP) under This connectionuses the following items:”byclicking onit

once. Click onthe Properties button.

4. Select Obtain an IPaddressautomatically”byclickingoncein the circle.Click the

OK button.

Your computer isnowreadytouse the Router’s DHCPserver.

Click Properties

Select Obtain an IPaddress

automatically in the Internet

Protocol (TCP/IP) Propertieswindow
