D-Link DIR-885L Manuel utilisateur

AC3150 ULTRA WIFI ROUTER

DIR-885L

QUICK

INSTALLATION

GUIDE

DIR-885L 1

ENGLISH

CONTENTS OF

PACKAGING

If any of these items are missing from your packaging, contact

your reseller.

POWER ADAPTER

12V / 3A

ETHERNET CABLE (CAT5 UTP)

CONNECTS THE ROUTER TO YOUR PC DURING SETUP

WI-FI CONFIGURATION CARD

CONTAINS THE DEFAULT WI-FI INFORMATION

Wi-Fi Conguration Note

CONTENTS

• A broadband Internet connection

• An e-mail account (required to register for mydlink service)

• Mobile device or tablet with iOS 6 or above, Android 2.3.3 or above

• Computer with:

• Microsoft Windows®8/7/Vista or Mac with OS X 10.6 or higher

• Internet Explorer 9, Firefox 20, Safari 5.1, or Chrome 25 or higher version with Java installed

and enabled

SYSTEM REQUIREMENTS

AC3150 ULTRA WIFI ROUTER

DIR-885L

4 ANTENNAS

DIR-885L

ENGLISH

PRODUCT SETUP

To set up and manage your DIR-885L, you can use the free QRS Mobile app, or you can use the

built-in web interface. In order to use all of the functions of this router, you must register it with

mydlink. Simply follow the steps at the end of the Setup Wizard during installation to register your

product with your mydlink account.

NOTE: After mydlink registration is completed, your router’s default PPPoE, L2TP, PPTP connection

will be set to Always On. If your ISP charges for usage, you may wish to manually choose Dial On

Demand as your default setting.

NOTE: Attach the antennas to the router before powering it on.

HARDWARE SETUP

Step 5

If using a PC to congure the router, plug one end of an Ethernet

cable into the port labeled 1 on the back of the router, and the other

end into the Ethernet port on your computer.

If you are setting up the DIR-885L using a laptop or mobile device,

connect it to the Wi-Fi network printed on the included Wi-Fi

Conguration Card.You can also nd the Wi-Fi network name and

password on the label attached to your router.

Step 1

Attach each of the antennas to the router by twisting them on in a

clockwise direction.

Step 2

Position your DIR-885L near your Internet-connected modem. Keep

the router in an open area for better wireless coverage.

Step 3

Use the included Ethernet cable to connect your modem to the port

labeled INTERNET on the router.

Step 4

Connect the supplied power adapter to the router and a power

outlet, press the power button, and verify that the power LED is on.

Modem

Router

ModemRouter

DIR-885L 3

ENGLISH

SETUP USING THE QRS MOBILE APP

Step 1

On your mobile device, go to the App Store or Google Play and

search for the free QRS Mobile app and download it.

Step 2

Connect your mobile device to the Wi-Fi network printed on the

included Wi-Fi Conguration Card. You can also nd the Wi-Fi

network name and password on the label attached to the router.

Wi-Fi Conguration Note

Step 3

Run the QRS Mobile app on your mobile device, and it will guide

you step by step through conguration of your router.

ANTENNA ORIENTATION

The DIR-885L is designed to give you the fastest, most stable network connection possible. In order to

maximize performance, orient the antennas at an angle, pointing outward and away from the base unit.

45°

To configure your DIR-885L, open a browser on the connected

computer. If you are not automatically directed to the D-Link Setup

Wizard, go to http://dlinkrouter.local./ and follow the onscreen

instructions. Use Admin as your username and leave the password

blank.

Admin Password:

SETUP USING THE BUILT-IN WEB INTERFACE

DIR-885L

ENGLISH

TROUBLESHOOTING

SETUP AND CONFIGURATION PROBLEMS

1. HOW DO I CONFIGURE MY DIR-885L ROUTER MANUALLY?

- Connect your PC to the router using an Ethernet cable.

- Open a web browser and enter the address http://dlinkrouter.local./ (or 192.168.0.1).

- The default username is Admin. The password should be left blank by default.

- If you have changed the password and cannot remember it, you will need to reset the router to

return to an empty password eld.

2. HOW DO I RESET MY DIR-885L ROUTER TO FACTORY DEFAULT SETTINGS?

- Ensure the router is powered on.

- Use an unfolded paperclip to press and hold the reset button on the back of the device for 10

seconds.

Note: Resetting the router to factory default will erase the current conguration settings.

To re-congure your settings, log into the router as outlined in question 1, then run the Setup Wizard.

3. HOW DO I ADD A NEW WIRELESS CLIENT OR PC IF I HAVE FORGOTTEN MY

WI-FI NAME (SSID) OR WI-FI PASSWORD?

- For every PC that needs to connect to the router wirelessly, you will need to ensure you use the

correct Wi-Fi Name (SSID) and Wi-Fi password.

- Use the web-based user interface (as described in question 1 above) to check or choose your

wireless settings.

- Make sure you write down these settings so that you can enter them for each wirelessly

connected PC. The back of this document features an area to record this important information.

4. WHY CAN'T I GET AN INTERNET CONNECTION?

- For ADSL users, please contact your ISP to make sure the service has been enabled/connected

by your ISP and that your ISP username and password are correct.

5. WHY CAN'T I REGISTER MY DEVICE WITH MYDLINK?

- If you experience issues registering this router with your mydlink account, try performing a hard

reset by using an unfolded paperclip to press and hold the reset button for 10 seconds while the

router is powered on. This may be necessary if you purchased an open box or resold unit.

MYDLINK LITE

The mydlink Lite app lets you check on your router, anywhere,

anytime. Check on your current upload and download speeds, see

who's connected, manage your wireless network details, and more!

After registering your DIR-885L with your mydlink account, just go

to the App Store, Google Play, or the Windows Store and search for

the free mydlink Lite app and download it.

DIR-885L 5

ENGLISH

TECHNICAL SUPPORT

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

Australia:

Tel: 1300-766-868

24/7 Technical Support

Web: http://www.dlink.com.au

E-mail: [email protected]

India:

Tel: +91-832-2856000

Toll Free 1800-233-0000

Web: www.dlink.co.in

E-Mail: [email protected]

Singapore, Thailand, Indonesia,

Malaysia, Philippines, Vietnam:

Singapore - www.dlink.com.sg

Thailand - www.dlink.co.th

Indonesia - www.dlink.co.id

Malaysia - www.dlink.com.my

Philippines - www.dlink.com.ph

Vietnam - www.dlink.com.vn

Korea:

Tel : +82-2-2028-1810

Monday to Friday 9:00am to 6:00pm

Web : http://d-link.co.kr

E-mail : [email protected]

New Zealand:

Tel: 0800-900-900

24/7 Technical Support

Web: http://www.dlink.co.nz

E-mail: [email protected]

South Africa and Sub Sahara

Region:

Tel: +27 12 661 2025

08600 DLINK (for South Africa only)

Monday to Friday 8:30am to 9:00pm South

Africa Time

Web: http://www.d-link.co.za

E-mail: [email protected]

D-Link Middle East - Dubai, U.A.E.

Plot No. S31102,

Jebel Ali Free Zone South,

P.O.Box 18224, Dubai, U.A.E.

Tel: +971-4-8809022

Fax: +971-4-8809066 / 8809069

Technical Support: +971-4-8809033

General Inquiries: [email protected]

Tech Support: [email protected]

Egypt

1, Makram Ebeid Street -

City Light Building - oor 5

Nasrcity - Cairo, Egypt

Tel.: +2 02 23521593 - +2 02 23520852

Technical Support: +2 02 26738470

General Inquiries: [email protected]

Tech Support: [email protected]

Kingdom of Saudi Arabia

Ofce # 84 ,

Al Khaleej Building ( Mujamathu Al-Khaleej)

Opp. King Fahd Road, Olaya

Riyadh - Saudi Arabia

Tel: +966 1121 70008

Technical Support:

+966 1121 70009

General Inquiries: info.sa@ dlinkmea.com

Tech Support: support.sa@ dlinkmea.com

Pakistan

Islamabad Ofce:

61-A, Jinnah Avenue, Blue Area,

Suite # 11, EBC, Saudi Pak Tower,

Islamabad - Pakistan

Tel.: +92-51-2800397, 2800398

Fax: +92-51-2800399

Karachi Ofce:

D-147/1, KDA Scheme # 1,

Opposite Mudassir Park, Karsaz Road,

Karachi – Pakistan

Phone: +92-21-34548158, 34326649

Fax: +92-21-4375727

Technical Support: +92-21-34548310, 34305069

General Inquiries: [email protected]

Tech Support: [email protected]

DIR-885L

ENGLISH

TECHNICAL SUPPORT

Iran

Unit 5, 5th Floor, No. 20, 17th Alley , Bokharest

St. , Argentine Sq. ,

Tehran IRAN

Postal Code : 1513833817

Tel: +98-21-88880918,19

+98-21-88706653,54

General Inquiries: [email protected]

Tech Support: [email protected]

Morocco

M.I.T.C

Route de Nouaceur angle RS et CT 1029

Bureau N° 312 ET 337

Casablanca , Maroc

Phone : +212 663 72 73 24

Email: [email protected]

Lebanon RMA center

Dbayeh/Lebanon

PO Box:901589

Tel: +961 4 54 49 71 Ext:14

Fax: +961 4 54 49 71 Ext:12

Email: [email protected]

Bahrain

Technical Support: +973 1 3332904

Kuwait:

Technical Support: + 965 22453939 / +965

22453949

Türkiye

Büyükdere Cad. Ferro Plaza No:155

D: 1 K: 1 Zincirlikuyu / Istanbul

Tel: +90 (212) 289-56-59

Email: [email protected]

לארשי

רטנס ןולטמ

20 םימישגמה 'חר

7060 ד"ת ,49348 ת"פ ,ןולטמ תירק

03-9215173 :לט

073-7962797 :לט

[email protected] :יללכ ל"אוד

[email protected] :הכימת ל"אוד

WIRELESS NETWORK REMINDER

Wireless Network Name (SSID)

Wireless Network Password

Ver.1.00(DI)_130x183 2015/07/30 6IR885LQML01G
