D-Link DIR-880L Manuel utilisateur

Wireless AC1900

Dual Band Gigabit Cloud Router

Quick Install Guide

DIR-880L

If any of the above items are missing, please contact your reseller.

DIR-880L Dual Band Gigabit Cloud Router with External Antennas

Power Adapter

Ethernet Cable

Wi-Fi Conguration Card

Quick Install Guide

Network Requirements:

Web-based Conguration Requirements

Supported Browsers:

• Internet Explorer® 9 or higher, Safari® 5.1 or higher*, Firefox® or Chrome™

mydlink Requirements

• For mydlink and mydlink app requirements refer to:

http://www.mydlink.com

Package Contents

Minimum Requirements

• An Ethernet-based broadband modem

Computer with the following:

• Windows® or Mac OS® X operating system

• An installed Ethernet adapter or wireless adapter

Make sure you have the latest version of Java installed. Visit www.java.com

to download the latest version.

*Note: We recommend Internet Explorer® 11 and Safari® 7 for best performance.

Hardware Overview

1Power LED A solid blue light indicates a proper connection to the power supply. The

light will be solid orange during boot-up.

2Internet LED

A solid blue light indicates a connection to the Internet port. If the LED

is orange, the connection is good but the router cannot connect to the

Internet.

32.4G LED

A solid blue light indicates the 2.4GHz wireless function is working properly.

During theWPS process, this light will blink quickly. When used in Bridge mode,

the light will blink slowly when successfully connected to a wireless device.

45G LED

A solid blue light indicates the 5GHz wireless function is working properly.

During theWPS process, this light will blink quickly. When used in Bridge mode,

the light will blink slowly when successfully connected to a wireless device.

5USB LED A solid blue light indicates a USB 2.0 device is connected.

6SS USB LED A solid blue light indicates a USB 3.0 device is connected.

7WPS Button Press to start the WPS process. The 2.4G or 5G LED will blink fast, depending

on which band the device is connecting with.

8LAN Ports (1-4) Connect Ethernet devices such as computers, switches, and game consoles.

9Internet Port Connect a broadband modem to this port using an Ethernet cable.

10 USB 2.0 Port Connect a USB ash drive to share content throughout your network.

Port supports USB 2.0 devices.

11 Reset Button Press and hold the reset button with a paper clip for six seconds to reset the

router to the factory default settings.

12 Power Button Press to power the router on and o.

13 Power Port Connect the supplied power adapter.

14 USB 3.0 Port Connect a USB ash drive to share content throughout your network.

Port supports USB 3.0 devices.

1 65432

8911 12 13

• Users with DSL providers - If you are using a PPPoE connection, you will need

your PPPoE user name and password. If you do not have this information, contact

your Internet provider. Do not proceed until you have this information.

• Users with Cable providers - Make sure you unplug the power to your modem.

In some cases, you may need to turn it o for up to 5 minutes.

•Advanced Users - If your ISP provided you with a modem/router combo, you will

need to set it to “bridge” mode so the DIR-880L router can work properly. Please

contact your ISP or refer to the user manual for your modem/router device.

Note: If you experience issues registering this device with your mydlink account, or if you purchased

an open box or resold unit, perform a hard reset by pressing and holding the reset button on the

device for 10 seconds while the device is powered on. If you are returning the device, please

perform the hard reset procedure to clear the device of any personal data.

To ensure your product has the latest security updates and operates at optimal performance, it is

recommended you update your product to the latest rmware after installation and to periodically

check for new rmware releases. Updates can be found by searching your model name at

http://support.dlink.com or through the mydlink mobile apps for mydlink registered devices.

Before you Start

1Unplug the power to your DSL or Cable modem.

Modem

Connect your Router

2Connect an Ethernet cable from the Internet port of the router to the

Ethernet port on your DSL or Cable modem.

3Connect another Ethernet cable from the Ethernet port on your

computer to one of the LAN ports on the router.

4Plug the power back into your DSL or cable modem. Please wait about

one minute before continuing.

1 2 3 4 INTERNET USB

RESET

POWER

ON/OFF

Computer

Ethernet Cable

DIR-880L

1 2 3 4 INTERNET USB

RESET

POWER

ON/OFF

Computer

Modem DIR-880L

1 2 3 4 INTERNET USB

RESET

POWER

ON/OFF

Ethernet Port

Modem

Ethernet Cable

DIR-880L

Internet Port (yellow)

5Plug the power adapter into your router and connect to an available

power outlet or surge protector. If the Power LED does not light up, press

the Power button on the back of the router.

6After the router has powered up, verify that the Power (blue) and Internet

(blue or orange) LEDs are both lit. Proceed with router conguration.

Open a web browser (e.g., Internet Explorer, Chrome, Firefox, or Safari)

and enter http://dlinkrouter.local./ or the IP address of the router

(http://192.168.0.1).

1 2 3 4 INTERNET USB

RESET

POWER

ON/OFF

Computer

Modem

DIR-880L

Conguration

There are two ways to congure your router:

A. Web Browser - Use a web browser from your computer.

B. QRS Mobile app - Use a mobile device with the D-Link QRS Mobile app.

Refer to the QRS Mobile Setup section for more information.

A. Web Browser Conguration

When the Welcome screen appears, click Next to continue.

The router will automatically detect your Internet connection type. If not, then

select your Internet connection and click Next to continue.

DSL (PPPoE) users enter your PPPoE user name and password supplied by

your ISP. Click Next to continue.

For both the 2.4GHz and 5GHz bands, create a name for your Wi-Fi Network

and a password. Your wireless devices (i.e., tablets, smartphones, and

laptops) will need to have this information entered to be able to connect to

your wireless network. Click Next to continue.

Continue with the Setup Wizard to nish conguring your DIR-880L router.

Once completed, the Internet LED will turn blue indicating that your router

is connected to the Internet.

Note: Setting up “mydlink” is optional and not required for the router to function.

Congratulations! You have completed the router installation.

1Scan the code below or search “QRS Mobile” (App Store or Google Play) to

download the QRS Mobile App to your iPhone, iPad, or Android device.

Once your app is installed, you may now congure your router. Connect to

the router wirelessly by going to your wireless utility on your device. Scan

for the wireless network name as listed on the suppliedWi-Fi Conguration

card/sticker. Select the network and then enter the Wi-Fi Password.

Once connected, click on the QRS Mobile icon from your mobile device,

then click Start to continue. Please follow the on-screen instructions to

complete the setup.

B. QRS Mobile Setup

Once the Setup Complete screen appears, click Save and write down the

new Wi-Fi Network name and password on your companion card for future

reference.

Note: To reconnect to your router, launch your wireless utility, select the new

Wi-Fi Network you created, and then enter your new Wi-Fi password.

iOS Android QRS Mobile App

Wi-Fi Name(SSID) 2.4Ghz:

dlink-xxxx

Wi-Fi Name(SSID) 5GHz:

dlink-xxxx-5GHz

Password: xxxxxxxx

To congure your router, go to:

http://dlinkrouter.local.

Or http://192.168.0.1

Username: “Admin”

Password:”“ (leave the eld blank)

How do I connect my wireless devices to the DIR-880L router?

1. Open your wireless network utility that displays available wireless networks.

2. Select the Wi-Fi Network name you assigned in the wizard and connect.

Note: If you did not run the setup wizard or you reset the router to its default

settings, refer to the Wi-Fi Conguration Card included for the default Wi-Fi

Network Name and Wi-Fi Password.

You can also connect wireless devices to the DIR-880L router using WPS:

1. Press the WPS button on the DIR-880L for three seconds.

2. Within one minute press the WPS button on your wireless device.

3. Allow up to two minutes to connect.

Note: Some devices may require you to log in to a utility to start the WPS process.

Refer to the user manual of the device you want to connect to the router if you do

not know how to start the WPS process.

How do I connect the DIR-880L to my wireless router when it is in bridge mode?

1. Press the WPS button on your wireless router.

2. Within one minute, press the WPS button on the DIR-880L.

3. Allow up to two minutes to connect to the router.

Note: If the WPS method fails, use the manual conguration method. Refer to the

DIR-880L User Manual.*

How do I change the wireless settings on the DIR-880L router?

1. Open a web browser (e.g., Internet Explorer, Chrome, Firefox, or Safari) and

enter http://dlinkrouter.local./ You can also enter the IP address of the

router (http://192.168.0.1).

2. At the login screen, enter the router password you created in the wizard (no

password by default).

3. Go to Setup > Wireless Settings > Manual Wireless Network Setup to

create a new Wi-Fi network name (SSID) and Wi-Fi password.

*Documentation available at http://www.dlink.com/DIR-880L.

Troubleshooting
