Quick Install Guide

DNS-323

ShareCenter™2-BAY NETWORK STORAGE

3 D-Link DNS-323 Quick Install Guide

Package Contents

System Requirements

• 1GHzProcessor/512MBRAM

• 200MBavailablespace

• CD-ROMdrive

• InternetExplorer6.0orMozillaFirefox1.0andabove

• 3.5”InternalSATAHardDrives

• WindowsVista®,orXP(ServicePack2)

• DNS-323ShareCenter™2-BayNetworkStorage

• CD-ROMwithManualandSoftware

• QuickInstallationGuide

• PowerAdapter

• PowerCableClip

• CAT5EthernetCable

Note: Using a power supply other than the one included with the DNS-323

may cause damage and void the warranty of this product.

If any of the above items are missing, please contact your reseller.

4D-Link DNS-323 Quick Install Guide

Hardware Overview

Power Button:

PressthebuttononcetopowerontheDNS-323.Pressandholdthe

buttonuntilitbeginsblinkingtopowerdownthedevice.

Drive LEDs:

These LEDs will turn a solid BLUE when drives are connected.

TheLEDswillblinkwhenthedrivesarebeingaccessed,formatted

orsynchronized.TheywillilluminateAMBERifadrivehasfailed.

Activity LED:

This LED will illuminate solid BLUE when there is an Ethernet

connection.ItwillblinktoindicateLANtrafc.

Front View

Power Button

Drive LED

Activity LED

Drive LED

5 D-Link DNS-323 Quick Install Guide

Rear View

Power Receptacle:

The12V3A/5V3Apowersupplyconnectshere.

Ethernet Port:

A Gigabit Ethernet port that connects the DNS-323 to the local

network.

USB Port:

Connectaprinter,orUPStotheport.ThisUSBportalsosupports

D-LinkSharePort™technology.RefertotheSharePort™manual

formoredetails.

Drive Eject Lever:

UsetheleverstoejecttheSATAharddrives.

Reset Button:

ApinholebuttonlocatedbesidetheEthernetportisusedtoresetthe

systemtothefactorydefaultsettings.

Note: After resetting the unit you will still have access to the data on your

hard drives.

Ethernet Port

Drive Eject

Lever

Power

Receptacle USB Port

Reset Button

Drive Eject

Lever

6D-Link DNS-323 Quick Install Guide

Hardware Installation

1. Accessthedrivebaysbyslidingthefaceplateupuntilitunlatches

fromthedevice.

2. Oncethefaceplateisunlatched,pullitoffofthedevice,exposing

thedrivebays.

3. Insert a 3.5” SATA hard drive into each available drive bay.

Makesuretoalignthedriveconnectorstotheendpointsinthe

DNS-323.Gentlypushthedriveinuntilitconnects.

Note: If only one 3.5” SATA drive is

available place this drive in the LEFT bay

with the opening (front) of the DNS-323

facing you.

7 D-Link DNS-323 Quick Install Guide

4. Attachthefaceplatetothefrontofthedevice.

5. ConnectanEthernetcableintotheavailableEthernetport.Thiscable

shouldconnectthe DNS-323 to yourlocalnetworkordirectly to a

computerforconguration.

6. Finally,connectthepoweradaptertothepowerreceptacle.

8D-Link DNS-323 Quick Install Guide

Easy Search Utility

When rst powered on, during the initial boot sequence, the

DNS-323willwaittobeassignedanIPaddressviaDHCP.Ifitdoes

notreceiveanassignedIPaddress,bydefaultitwillbootupwitha

self-assignedIPaddressof192.168.0.32.

The Easy Search Utility provided on the DNS-323 CD-ROM

makesitsimpletondanyDNS-323devicesinyournetwork.Itis

recommendedtousetheEasySearchUtilitywhenaccessingand

conguringtheDNS-323forthersttime.EachDNS-323willhave

auniquenameofdlink-xxxxxxwhere‘xxxxxx’isthelastsixdigitsof

itsMACaddress.

Note: If you want to use non-English character les, you may need to change

the Language setting from the Easy Search Utility to ensure full compatibility

with those les. Refer to the user manual for instructions.

9 D-Link DNS-323 Quick Install Guide

Togetstarted,inserttheDNS-323CDintoyourCD-ROMdriveand

clickonEasySearchUtility:

Highlight an available DNS-323

andclickCongurationtoaccess

theweb-basedutility.

Attheloginscreen, type admin

fortheusernameandleavethe

passwordeldblank.Thenclick

Conguration.

Getting Started

SelectEasy Search Utility.

10D-Link DNS-323 Quick Install Guide

Amessagewill appear warning

that all data will be erased

during formatting. Click OK to

continue.

Select the EXT2 or EXT3 file

systemonDNS-323.ClickNext

tocontinue.

Select a conguration type for

yourharddriveandclickNext.

WhenloggingintotheDNS-323forthersttime,youwillbeasked

tochooseadrive’scongurationtypeandformatthedrives.There

arefouravailablecongurationoptions,Standard,JBOD,RAID0

andRAID1.
