D-Link DCS-5030L Manuel utilisateur

QUICK

INSTALLATION

GUIDE

КРАТКОЕ РУКОВОДСТВО ПО

УСТАНОВКЕ

HD Pan & TilT Wi-Fi Day/nigHT Camera

DCS-5030l

DCS-5030l 1

ENGLISH

CONTENTS OF PACKAGING

HD PAN & TILT WI-FI DAY/NIGHT CAMERA

DCS-5030L

POWER ADAPTER

MOUNTING KIT

ETHERNET CABLE (CAT5 UTP)

CONNECTS THE CAMERA TO YOUR ROUTER DURING SETUP

If any of these items are missing from your packaging, contact your

reseller.

QUICK INSTALL CARD

DCS-5030l

ENGLISH

SYSTEM REQUIREMENTS

• 802.11ac/n/g router (a D-Link Cloud Router is recommended)

• A broadband Internet connection

• iPhone, iPad, Android, or Windows smartphone or tablet (please refer to the mobile app's store page

to check whether your device is compatible)

Please follow the instructions below to set up your mydlink camera.

Congratulations, your DCS-5030L is now ready to use! Be sure to check the mydlink.com website

periodically for the latest rmware updates to keep your product secure and up to date with the latest

features.

Note: If you experience issues registering this camera with your mydlink account, or if you purchased

an open box or resold unit, perform a hard reset by pressing and holding the reset button on the

device for 10 seconds while the device is powered on. If you are returning the device to the place

of purchase, please perform the hard reset procedure to clear the device of any personal

data.

Step 1: On your mobile device, download mydlink Lite by searching for mydlink Lite in the iTunes

App Store, Google Play, or the Windows Store.

Step 2: Launch the mydlink Lite app and create a new account or sign in to your existing account.

Follow the onscreen instructions to set up your camera.

When you are asked to scan a QR code, use the code on the Quick Install Card in your

package, or on the label attached to your device.

PRODUCT SETUP

SeTTing UP yOUr Camera WiTH myDlinK liTe

DCS-5030l 3

ENGLISH

Step 2:

Press the WPS button on your Cloud Router within 120 seconds.

The DCS-5030L will automatically create a wireless connection to

your router. While connected, the status LED will turn green.

Step 3:

From any computer, open a web browser, go to

http://www.mydlink.com and log in to your account.

Click on the device name when the new device notication appears

to add the camera to your account.

DCS-5030L

If you have a D-Link Cloud Router, you can take advantage of Zero Conguration Setup. This

feature congures your camera’s settings for you and adds it to your mydlink account automatically.

PRODUCT SETUP

ZerO COnFigUraTiOn SeTUP

Step 1:

Press the WPS button on the camera for 3 seconds. The WPS LED

will start blinking.

USing THe inSTallaTiOn WiZarD

You can also use any Windows or Mac computer to go through

the downloadable Setup Wizard, which will guide you through the

installation process from connecting your hardware to conguring

your camera.

To download the Setup Wizard, visit www.mydlink.com/support.

DCS-5030l

ENGLISH

Step 1:

Open Internet Explorer and go to www.mydlink.com, then sign into

mydlink.

Step 2:

Select your camera from the device list, and your camera’s Live

View will appear.

After registering your DCS-5030L camera with a mydlink account in the mydlink Lite mobile app, you

will be able to remotely access your camera from the mydlink website.

mydlink PORTAL

DCS-5030l 5

ENGLISH

MOUNTING THE CAMERA

Please refer to the steps below to assist you with mounting the camera using the arm mount. We

suggest that you congure the camera before mounting.

Step 1:

Place the arm mount where you want to position the camera and

use a pencil to mark the holes. Ensure the arm mount is oriented

correctly with adequate space for the camera to be mounted and

necessary cables to be routed.

Step 2:

Depending on the material of the wall or ceiling, use proper tools to

drill two holes 25mm deep with a 6mm drill bit where you marked.

After drilling the holes, insert the plastic anchors to support the

screws.

Step 4:

Fasten the mounting bracket to the wall using the screws provided.

Step 5:

Using the supplied thumbscrew, fasten the camera to the mounting

bracket. Connect the power cable to the camera.

Step 3:

If desired, the cable can be concealed behind the mounting bracket.

Run the cable through the back of the mounting bracket, securing

it with the built-in guides. Be sure to leave enough cable length

protruding to allow connection to the camera.

Step 6:

Adjust the angle of the arm on the mounting bracket as required.

Tighten the thumbscrew to lock the arm in place.

DCS-5030l

ENGLISH

TROUBLESHOOTING

SeTUP anD COnFigUraTiOn PrOBlemS

1. THE IMAGE IS OUT OF FOCUS.

You can turn the focus ring on the front of the camera to adjust the focus.

2. WHY IS THE CAMERA VIEW HAZY OR BRIGHT WHEN USING NIGHT VISION MODE?

The IR night vision lights on the camera may be reecting off of a nearby surface or window. Try

repositioning your camera to avoid reections or glare.

3. WHAT CAN I DO IF I FORGET MY CAMERA PASSWORD?

If you forget your camera password, you will need to perform a hard reset of your camera. This

process will change all your settings back to the factory defaults.

To reset your camera, please use an unfolded paperclip to press and hold the RESET button for

at least 10 seconds while your camera is plugged in.

DCS-5030l 7

ENGLISH

TeCHniCal SUPPOrT

Australia:

Tel: 1300-766-868

24/7 Technical Support

Web: http://www.dlink.com.au

E-mail: [email protected]

India:

Tel: +91-832-2856000

Toll Free 1800-233-0000

Web: www.dlink.co.in

E-Mail: [email protected]

Singapore, Thailand, Indonesia,

Malaysia, Philippines, Vietnam:

Singapore - www.dlink.com.sg

Thailand - www.dlink.co.th

Indonesia - www.dlink.co.id

Malaysia - www.dlink.com.my

Philippines - www.dlink.com.ph

Vietnam - www.dlink.com.vn

Korea:

Tel : +82-2-2028-1810

Monday to Friday 9:00am to 6:00pm

Web : http://d-link.co.kr

E-mail : [email protected]

New Zealand:

Tel: 0800-900-900

24/7 Technical Support

Web: http://www.dlink.co.nz

E-mail: [email protected]

South Africa and Sub Sahara

Region:

Tel: +27 12 661 2025

08600 DLINK (for South Africa only)

Monday to Friday 8:30am to 9:00pm South

Africa Time

Web: http://www.d-link.co.za

E-mail: [email protected]

D-Link Middle East - Dubai, U.A.E.

Plot No. S31102,

Jebel Ali Free Zone South,

P.O.Box 18224, Dubai, U.A.E.

Tel: +971-4-8809022

Fax: +971-4-8809066 / 8809069

Technical Support: +971-4-8809033

General Inquiries: [email protected]

Tech Support: [email protected]

Egypt

1, Makram Ebeid Street -

City Light Building - oor 5

Nasrcity - Cairo, Egypt

Tel.: +2 02 23521593 - +2 02 23520852

Technical Support: +2 02 26738470

General Inquiries: [email protected]

Tech Support: [email protected]

Kingdom of Saudi Arabia

Ofce # 84 ,

Al Khaleej Building ( Mujamathu Al-Khaleej)

Opp. King Fahd Road, Olaya

Riyadh - Saudi Arabia

Tel: +966 1121 70008

Technical Support:

+966 1121 70009

General Inquiries: info.sa@ dlinkmea.com

Tech Support: support.sa@ dlinkmea.com

Pakistan

Islamabad Ofce:

61-A, Jinnah Avenue, Blue Area,

Suite # 11, EBC, Saudi Pak Tower,

Islamabad - Pakistan

Tel.: +92-51-2800397, 2800398

Fax: +92-51-2800399

Karachi Ofce:

D-147/1, KDA Scheme # 1,

Opposite Mudassir Park, Karsaz Road,

Karachi – Pakistan

Phone: +92-21-34548158, 34326649

Fax: +92-21-4375727

Technical Support: +92-21-34548310,

34305069

General Inquiries: [email protected]

Tech Support: [email protected]

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

DCS-5030l

ENGLISH

Iran

Unit 5, 5th Floor, No. 20, 17th Alley , Bokharest

St. , Argentine Sq. ,

Tehran IRAN

Postal Code : 1513833817

Tel: +98-21-88880918,19

+98-21-88706653,54

General Inquiries: [email protected]

Tech Support: [email protected]

Morocco

M.I.T.C

Route de Nouaceur angle RS et CT 1029

Bureau N° 312 ET 337

Casablanca , Maroc

Phone : +212 663 72 73 24

Email: [email protected]

Lebanon RMA center

Dbayeh/Lebanon

PO Box:901589

Tel: +961 4 54 49 71 Ext:14

Fax: +961 4 54 49 71 Ext:12

Email: [email protected]

Bahrain

Technical Support: +973 1 3332904

Kuwait:

Technical Support: + 965 22453939 / +965

22453949

Türkiye

Büyükdere Cad. Ferro Plaza No:155

D: 1 K: 1 Zincirlikuyu / Istanbul

Tel: +90 (212) 289-56-59

Email: [email protected]

לארשי

רטנס ןולטמ

20 םימישגמה 'חר

7060 ד"ת ,49348 ת"פ ,ןולטמ תירק

03-9215173 :לט

073-7962797 :לט

[email protected] :יללכ ל"אוד

[email protected] :הכימת ל"אוד

TeCHniCal SUPPOrT

DCS-5030l 9

РУССКИЙ

КОМПЛЕКТ ПОСТАВКИ

БЕСПРОВОДНАЯ ОБЛАЧНАЯ СЕТЕВАЯ HD-КАМЕРА

С ПРИВОДОМ НАКЛОНА/ПОВОРОТА И ПОДДЕРЖКОЙ

НОЧНОЙ СЪЕМКИ

DCS-5030L

АДАПТЕР ПИТАНИЯ

МОНТАЖНЫЙ КОМПЛЕКТ

ETHERNET-КАБЕЛЬ 5 КАТЕГОРИИ

ДЛЯ ПОДКЛЮЧЕНИЯ КАМЕРЫ К МАРШРУТИЗАТОРУ И

НАСТРОЙКИ ПАРАМЕТРОВ

Если что-либо из перечисленного отсутствует, обратитесь к

поставщику.

КАРТОЧКА БЫСТРОЙ УСТАНОВКИ
