D-Link DAP-1620 Manuel utilisateur

Quick Installation Guide

DAP-1620

AC1300 MU-MIMO Wi-Fi Range Extender

DAP-1620 Quick Installation Guide

BEFORE YOU BEGI

Delivery Package

•Extender DAP-1620

•“Quick Installation Guide” (brochure).

If any of the ite s are issing, please contact your reseller.

The “User Manual” and “Quick Installation Guide” docu ents are available

on D-Link website (see www.dlink.ru).

!Using a power supply with different parameters than those

indicated on the device will cause damage and void the warranty

for this product.

DAP-1620 Quick Installation Guide

Default Settings

IP address of device 192.168.0.50

Username (login) admin

Password admin

ame of wireless network

(SSID)

2.4GHz dlink-XXXX1

5GHz dlink-XXXX-5GHz2

etwork key (PSK)

see the field Password

on the back panel of the

device

1 See the field Wi-Fi ame (SSID) 2.4GHz on the back panel of the device.

2 See the field Wi-Fi ame (SSID) 5GHz on the back panel of the device.

DAP-1620 Quick Installation Guide

System Requirements and Equipment

•A router enabled to access the Internet.

•A co puter with any operating syste that supports a web browser.

•A web browser to access the web-based interface of the extender:

◦Apple Safari 8 and later

◦Google Chro e 48 and later

◦Microsoft Internet Explorer 10 and later

◦Microsoft Edge 20.10240 and later

◦Mozilla Firefox 44 and later

◦Opera 35 and later.

•A NIC (Ethernet or Wi-Fi adapter) to connect to the extender.

•An 802.11a, b, g, n, or ac Wi-Fi adapter to create a wireless network.

DAP-1620 Quick Installation Guide

CO ECTI G TO PC

PC with Ethernet Adapter

1. Сonnect an Ethernet cable between the LAN port of the extender and the

Ethernet port of your PC.

2. Plug the device into an electrical outlet or power strip.

Now you need to configure an IP address for the Ethernet adapter of your PC.

DAP-1620 Quick Installation Guide

Configuring IP Address in S Windows 7

1. Click the Start button and proceed to the Control Panel window.

2. Select the etwork and Sharing Center section. (If the Control Panel

has the category view (the Category value is selected fro the View by

drop-down list in the top right corner of the window), choose the View

network status and tasks line under the etwork and Internet

section.)

3. In the enu located on the left part of the window, select the Change

adapter settings line.

4. In the opened window, right-click the relevant Local Area Connection

icon and select the Properties line in the enu displayed.

5. In the Local Area Connection Properties window, on the

etworking tab, select the Internet Protocol Version 4 (TCP/IPv4)

line. Click the Properties button.

DAP-1620 Quick Installation Guide

6. Select the Use the following IP address radio button and enter the

value 192.168.0.51 in the IP address field. The Subnet mask

field will be filled in auto atically. Click the OK button.

7. Click the OK button in the connection properties window.

Now you can connect to the web-based interface of DAP-1620 for configuring

all needed para eters. To gain access to an external network (to the Internet),

you also need to specify the default gateway and the addresses of DNS servers.

DAP-1620 Quick Installation Guide

Configuring IP Address in S Windows 10

1. Click the Start button and proceed to the Settings window.

2. Select the etwork & Internet section.

3. In the Change your network settings section, select the Change

adapter options line.

4. In the opened window, right-click the relevant Local Area Connection

icon and select the Properties line in the enu displayed.

5. In the Local Area Connection Properties window, on the

etworking tab, select the Internet Protocol Version 4 (TCP/IPv4)

line. Click the Properties button.

DAP-1620 Quick Installation Guide

6. Select the Use the following IP address radio button and enter the

value 192.168.0.51 in the IP address field. The Subnet mask

field will be filled in auto atically. Click the OK button.

7. Click the Close button in the connection properties window.

Now you can connect to the web-based interface of DAP-1620 for configuring

all needed para eters. To gain access to an external network (to the Internet),

you also need to specify the default gateway and the addresses of DNS servers.

DAP-1620 Quick Installation Guide

PC with Wi-Fi Adapter

1. Plug the device into an electrical outlet or power strip.

2. Make sure that the Wi-Fi adapter of your PC is on. As a rule, odern

notebooks with built-in wireless NICs are equipped with a button or

switch that turns on/off the wireless adapter (refer to your PC docu ents).

If your PC is equipped with a pluggable wireless NIC, install the software

provided with your Wi-Fi adapter.

Now you should configure your Wi-Fi adapter.
