Quick Installation Guide
DAP-1610
AC1200 Wi-Fi Range Extender
DAP-1610 Quick Installation Guide
BEFORE YOU BEGIN
Delivery Package
•Extender DAP-1610
•“Quick Installation Guide” (brochure).
If any of the item are mi ing, plea e contact your re eller.
The “User Manual” and “Quick Installation Guide” document are available
on D-Link web ite ( ee www.dlink.ru).
!
Using a power supply with different parameters than those
indicated on the device will cause damage and void the
warranty for this product.
Default Settings
Do ain na e of device dlinkap.local.
IP address of device 192.168.0.50
Userna e (login) admin
Password admin
Na e of wireless network
(SSID)
2.4GHz DAP-1610
5GHz DAP-1610-5G
Network key (PSK password)
ee WPS PIN on the
barcode label on the
back panel of the
device
2
DAP-1610 Quick Installation Guide
System Requirements and Equipment
•A router enabled to acce the Internet.
•A computer with any operating y tem that upport a web brow er.
•A web brow er to acce the web-ba ed interface of the device:
◦Apple Safari 8 and later
◦Google Chrome 48 and later
◦Micro oft Internet Explorer 10 and later
◦Micro oft Edge 20.10240 and later
◦Mozilla Firefox 44 and later
◦Opera 35 and later.
•A NIC (Ethernet or Wi-Fi adapter) to connect to the extender.
•An 802.11a, b, g, n, or ac Wi-Fi adapter to create a wirele network.
3
DAP-1610 Quick Installation Guide
CONNECTING TO PC
PC with Ethernet Adapter
1. Connect an Ethernet cable between the Ethernet port of the extender and
the Ethernet port of your PC.
2. Plug the device into an electrical outlet or power trip.
Now you need to configure an IP addre for the Ethernet adapter of your PC.
4
DAP-1610 Quick Installation Guide
Obtaining P Address Automatically
in OS Windows 7
1. Click the Start button and proceed to the Control Panel window.
2. Select the Network and Sharing Center ection. (If the Control Panel
ha the category view (the Category value i elected from the View by
drop-down li t in the top right corner of the window), choo e the View
network status and tasks line under the Network and Internet
ection.)
3. In the menu located on the left part of the window, elect the Change
adapter settings line.
4. In the opened window, right-click the relevant Local Area Connection
icon and elect the Properties line in the menu di played.
5. In the Local Area Connection Properties window, on the
Networking tab, elect the Internet Protocol Version 4 (TCP/IPv4)
line. Click the Properties button.
5
DAP-1610 Quick Installation Guide
6. Select the Obtain an IP address auto atically and Obtain DNS
server address auto atically radio button . Click the OK button.
7. Click the OK button in the connection propertie window.
Now your computer i configured to obtain an IP addre automatically.
6
DAP-1610 Quick Installation Guide
PC with Wi-Fi Adapter
1. Plug the device into an electrical outlet or power trip.
2. Turn on your Wi-Fi adapter. A a rule, modern notebook with built-in
wirele NIC are equipped with a button or witch that turn on/off the
wirele adapter (refer to your PC document ). If your PC i equipped
with a pluggable wirele NIC, in tall the oftware provided with your
Wi-Fi adapter.
Now you hould configure your Wi-Fi adapter.
7
DAP-1610 Quick Installation Guide
Configuring Wi-Fi Adapter in OS Windows 7
1. Click the Start button and proceed to the Control Panel window.
2. Select the Network and Sharing Center ection. (If the Control Panel
ha the category view (the Category value i elected from the View by
drop-down li t in the top right corner of the window), choo e the View
network status and tasks line under the Network and Internet
ection.)
3. In the menu located on the left part of the window, elect the Change
adapter settings line.
4. In the opened window, elect the icon of the wirele network connection
and make ure that your Wi-Fi adapter i on.
5. To open the li t of available wirele network , elect the icon of the
wirele network connection and click the Connect To button or left-
click the network icon in the notification area located on the right ide of
the ta kbar.
8
DAP-1610 Quick Installation Guide
6. In the opened window, in the li t of available wirele network , elect the
wirele network DAP-1610 (for operating in the 2.4GHz band) or
DAP-1610-5G (for operating in the 5GHz band) and click the Connect
button.
7. In the opened window, enter the network key ( ee WPS PIN on the
barcode label on the back panel of the device) in the Security key field
and click the OK button.
8. Wait for about 20-30 econd . After the connection i e tabli hed, the
network icon will be di played a the ignal level cale.
!
If you perform initial configuration of the acce point via Wi-Fi
connection, note that immediately after changing the wirele default
etting of the acce point you will need to reconfigure the wirele
connection u ing the newly pecified etting .
9
DAP-1610 Quick Installation Guide
CONFIGURING EXTENDER
Connecting to Web-based nterface
Start a web brow er. In the addre bar of the web brow er, enter the domain
name of the extender (by default, dlinkap.local) with a dot at the end
and pre the Enter key. Al o you can enter the IP addre of the device (by
default, 192.168.0.50).
!
If the error “ The page cannot be displayed ” (or “ Unable to display the
page ”/“ Could not connect to remote server ”) occur upon connecting to
the web-ba ed interface of the extender, make ure that you have
properly connected the device to your computer.
If the device ha not been configured previou ly or the default etting have
been re tored, after acce to the web-ba ed interface the Initial Configuration
Wizard open ( ee the Initial Configuration Wizard ection, page 13).
