DNR-202L
Quick Install Guide
3D/HD
TV
SMART
TV
note:
for packaging,
use “with” mydlink logo
microSD
Get maximum coverage inside and
outside your home / Obtenez une
couverture maximale à l'intérieur et à
l'extérieur de votre maison
Get Full Coverage in and out of your
home with SmartBeam™ high gain
antennas / Obtenir la Couverture pleine
dans et dehors de votre maison avec
antennes SmartBeam™ à gaine élevé
with/avec
Next Generation /
Dernière génération
NEXTGEN
mydlinkTM Camera Video Recorder
Quick Install Guide
DNR-202L Install Guide 1
• Computer with Microsoft Windows® 8, 7; Mac OS 10.7 or above
• PC with Pentium 4 – 2.4 GHz or above; at least 512 MB RAM
•Internet Explorer 8, Safari 7 (Mac OS) or above
• Existing 10/100 Ethernet-based network
Thank you for purchasing the mydlink Camera Video Recorder. Follow the
easy steps in this guide to properly set up your recorder. Please verify that
all the package contents listed above are included.
Write your settings here so you can refer to them later:
Device IP address:
Device password:
mydlink username:
mydlink password:
Minimum Requirements
Notes
Package Contents
DNR-202L mydlink Camera Video Recorder
Power Adapter
Ethernet Cable
Quick Install Guide
2DNR-202L Install Guide
*Note: Ensure that your cameras have been set up on the network before starting the
DNR-202L setup wizard.
Important Note: When connecting a USB drive to the DNR-202L, it will need to be formatted by the
device in order to function. All data on the drive(s) will be permanently erased.
1Open your web browser and go to http://support.dlink.com/DNR-202L and
click the Downloads tab. Download the Setup Wizard for your operating
system and save it to your computer. Once downloaded, run the setup le.
Setup Wizard
2
3
Click Start.
Connect your USB hard drive to the DNR-202L and click Next to continue.
DNR-202L Install Guide 3
4
5
Connect the power adapter to the DNR-202L and then to a power outlet.
Click Next to continue.
Connect an Ethernet cable from your router’s LAN port to the DNR-202L.
Click Next to continue.
4DNR-202L Install Guide
6
7
Make sure the LED on the NVR is lit blue then click Next to continue.
The wizard will attempt to nd your NVR in your network. You can click
Rescan to search for the DNR-202L at any time. Click Next to continue.
Write down the IP address of the DNR-202L for future reference.
DNR-202L Install Guide 5
8
9
Once your NVR has been found, you can set a password for it in the text boxes.
Click Next to continue.
You must format the attached hard drive(s) for the NVR. Make sure you do
not have any important data on this drive before clicking Next.
Click OK to proceed with formatting.
*Note: Formatting will permanently erase all existing data on the drive(s).
Write the password down on the rst page for future reference.
6DNR-202L Install Guide
10
11
The wizard will scan for all available cameras attached to your network.
Registered mydlink cameras will be veried automatically. Click Rescan if
you are adding more cameras.
You can preview the discovered cameras by clicking on the blue camera
icon, or click Next to continue.
A pop-up will ask you to enter the password for your camera.
Click OK.
The checkbox next to your camera will now have a green check mark to
indicate it has been added successfully.
Click Next to continue.
If you want to add any additional cameras in the future, refer to the “Adding a
Camera to the NVR”section.
DNR-202L Install Guide 7
12
13
The wizard will guide you through the process of connecting your NVR to
a mydlink account. If you already have a mydlink account, enter the correct
conguration information and click Next to continue, otherwise select I
want to sign up for a new account or I don’t want to use mydlink service
and follow the instructions.
Click Next to continue.
Setup is complete. Make a note of the details presented and click on Go To
NVR to log in to the NVR for further conguration or click Finish.
Congratulations, your DNR-202L is now ready to use! Be sure to check the
support.dlink.com website periodically for the latest rmware updates to
keep your product secure and up to date with the latest features.
8DNR-202L Install Guide
Accessing the NVR
*Note: In order to connect to the DNR-202L using this method, you MUST be connected to the
same network as the device.
*Note: You will be prompted to enter your username and password. The default username is admin
and the password will have been congured by you during step 8 of the initial setup.
1
2
Open your web browser (e.g., Internet Explorer, Firefox, Safari) and enter the IP
address of your DNR-202L into the address bar. The IP address can be found during
the setup wizard (step 7 on page 6).
You are now logged into your DNR-202L.
Alternatively, you can use the mydlink portal to remotely connect to the DNR-202L
over the Internet if you added the DNR-202L to your mydlink account during the
initial setup.
Select your DNR-202L and click the Connect button.
Go to www.mydlink.com and log into your account.
