D-Link PCMCIA WIRELESS ASAPTER DWL-650 Manuel utilisateur

DWL-650

11 Mbps Wireless PC Card Adapter

Quick Install GuideQuick Install Guide

for Windows 2000for Windows 2000

11 Insert DWL-650 Driver CDInsert DWL-650 Driver CD

22 Installing the DriversInstalling the Drivers

With the laptop turned ON, insert

the driver CD for the DWL-650 Wireless PC

Adapter into the CD-ROM.

The driver CD will automatically load.

The following “Welcome” screen will be

displayed.

Click Next.

For instructions on configuration, please see your User’s Manual.

Click the “Install Drivers” button.

Rev. dwl.120.2k-12-18-00,10amRev. dwl.120.2k-12-18-00,10am

Installing the DriversInstalling the Drivers continuedcontinued

Then the “Software License

Agreement” will be displayed.

Click Yes to accept.

The next screen will prompt for the

System ID. The word “default” will

be displayed in the text box.

Type in the desired name of the System ID in

the provided text box. The System ID needs to

be the same for all wireless network devices.

Click Next.

Select the Network Mode.

If you are connecting to an Access Point,

select “Infrastructure”. Otherwise, if you

are connecting directly to another wireless

adapter without an Access Point, or Wireless

Residential Gateway, then select “Ad Hoc”.

Click Next

Windows will prompt for the destination folder.

Click Next to accept the selected folder.

Otherwise, click Browse and select the

desired folder.

Rev. dwl.120.2k-12-18-00,10am

44 Finish InstallationFinish Installation

Windows will recognize new hardware.

At the “Welcome” screen,

Click Next to continue.

Rev. dwl.120.2k-12-18-00,10am

At the next screen,

select “Search for a suitable driver for my

device”.

Click Next to continue.

At the following window,

select “CD-ROM drives”.

Click Next to continue.

At the next window,

Click Next to continue.

The following screen will only appear at

initial installation.

Click Yes to continue.

Rev. dwl.120.2k-12-18-00,10am

At the next window

Click Finish.

Restart the computer to complete installation.

To check that the wireless adapter is working,

click on the configuration utility icon in the

task bar. Make sure that there is a wireless

connection under the “link info tab”.

Installing the DriversInstalling the Drivers continuedcontinued

Installing DWL-650Installing DWL-650

Wireless PC CARDWireless PC CARD

The next screen will appear.

Click Next

Windows will then load the system files. After

the system files are loaded, Windows will

prompt to restart the computer.

Then insert the DWL-650 Wireless PC Adapter into

an available PC slot in the laptop.

After the computer reboots if the

following prompt appears,

Click OK to continue.

Click Finish

Rev. dwl.120.2k-12-18-00,10am
