D-Link DFE-538TX Instructions de montage

Contents of Package:

• DFE-538TX Fast Ethernet Adapter

• Quick Install Guide

• CD-ROM, which includes driver software

If any of the above items are missing, please contact your reseller.

Pre-installation Procedures:

If you have already installed the DFE-538TX into a PCI slot, advanced users may utilize the

“Add New Hardware Wizard” to manually specify the location of the driver on the CD-

ROM.

Otherwise, we strongly recommend canceling the “Add New Hardware Wizard” and

instead using the “Install Drivers” program in the CD-ROM.

Here is quick summary of the proper installation procedure:

• Run the driver installation from the DFE-538TX CD-ROM.

• Turn Off the computer and install the DFE-538TX into the PCI slot.

• Restart the computer to complete the installation.

Installing the DFE-538TX Drivers

• Turn ON the computer.

• Insert the driver CD, which is included with the DFE-538TX, into the

CD-ROM drive.

DO NOT insert the DFE-538TX into the computer’s PCI

ltbf i

t lli th d i

DO NOT insert the DFE-538TX into the

computer’s PCI slot before installing the drivers.

The following window will appear.

Click on “Install Drivers.”

For Windows 2000 and Windows ME users, the following screen will appear.

Click OK

For Windows 98/98SE users, this screen will be displayed.

Click Yes

Installing the DFE-538TX into the

computer’s PCI slot

Note: To avoid static electric charges, please touch an unpainted screw on the

outside of the power supply before installing or working with the DFE-528-TX.

Next, TURN OFF the computer and

unplug the power cord.

• Turn off your computer and unplug the power cord.

• Remove the back cover of your computer. (Refer to your computer’s manual

if needed.)

• Locate an available PCI slot. PCI slots are usually white or cream colored.

• Remove the backplate (the small piece of metal that covers the opening for

the PCI card on the back cover that you just removed.)

• Insert the DFE-538TX carefully and firmly into the PCI slot.

• Secure the DFE-538TX with the screw from the backplate.

• Replace your computer’s cover.

Finishing the Installation

• TURN ON the computer.

For Windows 98/98SE and Windows ME users, the following screen will appear.

Click Yes, to restart the computer.

For Windows 2000 users, this screen will be displayed.

Click OK, to complete the installation.

(Note: Windows 2000 will not require a restart.)

Checking the Installation

• Go to START>RUN.

• Type “winipcfg.” (In Win2000, type “ipconfig/all.”) In some

cases it may be necessary to “Release and Renew” the IP address.

Make sure to select the DFE-538TX as the specified adapter in the

pull down menu.

• If the IP address belongs to the same IP range and subnet mask as

the local network, then open the web browser and test the Internet

connection.

Technical Support

You can find the most recent software and user

documentation on the D-Link website.

D-Link provides free technical support for customers

within the United States for the duration of the

warranty period on this product.

U.S. customers can contact D-Link technical support

through our web site or by phone.

D-Link Technical Support over the Telephone:

(877) 453-5465

24 hours a day, seven days a week

D-Link Technical Support over the Internet:

http://support.dlink.com
