D-Link PCMCIA WIRELESS ASAPTER DWL-650 Manuel utilisateur

DWL-650

11 Mbps Wireless PC Card Adapter

Quick Install GuideQuick Install Guide

11 Insert DWL-650 Driver CDInsert DWL-650 Driver CD

22 Installing the DriversInstalling the Drivers

With the laptop turned ON, insert

the driver CD for the DWL-650 Wireless PC

Adapter into the CD-ROM.

The driver CD will automatically load.

The following “Welcome” screen will be

displayed.

Click Next.

Rev. dwl650me-12-7-00,11am

Rev. dwl650me-12-5-00,1:37pm

For instructions on configuration, please see your User’s Manual.

APPENDIXAPPENDIX

Click Browse.

Click OK.

Providing Driver FilesProviding Driver Files

If prompted for the Driver files, insert Driver CD.

Select the correct Drive

Windows will copy the necessary files. Click the “Install Drivers” button.

for Windows MEfor Windows ME

Installing the DriversInstalling the Drivers continuedcontinued

Installing DWL-650Installing DWL-650

Wireless PC CARDWireless PC CARD

Finish InstallationFinish Installation

Then the “Software License

Agreement” will be displayed.

Click Yes to accept.

The next screen will prompt for the

System ID. The word “default” will

be displayed in the text box.

The next screen will appear.

Click Next.

Type in the desired name of the System ID in

the provided text box. The System ID needs to

be the same for all wireless network devices.

Click Next.

Select the Network Mode.

If you are connecting to an Access Point,

select “Infrastructure”. Otherwise, if you

are connecting directly to another wireless

adapter without an Access Point, or Wireless

Residential Gateway, then select “Ad Hoc”.

Click Next.

Windows will prompt for the destination folder.

Click Next to accept the selected folder.

Otherwise, click Browse and select the

desired folder.

Windows will then load the system files. After

the system files are loaded, Windows will

prompt to restart the computer.

Then insert the DWL-650 Wireless PC Adapter into

an available PC slot in the laptop.

If the following prompt appears after the

computer is restarted,

Click OK to continue.

Windows will recognize the DWL-650 Wireless PC Adapter.

If prompted for driver files please refer to Appendix A.

(Note that some computers may require a reboot.)

To check that the wireless adapter is working, click on the

configuration utility icon in the task bar. Make sure that there is a

wireless connection under the “link info tab”.

Click Finish.

Rev. dwl650me-12-7-00, 11am Rev. dwl650me-12-5-00, 1:37pm
