D-Link AirPremier AG DWL-AG660 Manuel utilisateur

AirPremierTM AG Dualband

Wireless Cardbus Adapter

DWL-AG660

cations subject to change without notice. DWL-AG660 11132003

If any of the above items are missing, please contact your reseller.

CD-ROM (containing Drivers, Manual and Warranty)

This product works with the

following operating system

software: Windows XP,

Windows 2000

DWL-AG660 AirPremierTMAG Dualband Wireless

Cardbus Adapter

Turn on the computer and Insert the

DWL-AG660 Driver CD in the CD-ROM

drive.

The step-by-step instructions that follow

are shown in Windows XP. The steps

and screens are similar for other Windows

operating systems.

Insert the D-Link CD Into Your Laptop PC

Do NOT install

the DWL-AG660

Cardbus Adapter into

your computer before

installing the driver

software from the D-Link

CD!

Before You Begin

You must have at least the following:

• A laptop/notebook computer with an available 32-bit cardbus slot

• At least a 500MHz processor and 128MB of memory

• Cardbus controller properly installed and working in the laptop computer

• An 802.11a, 802.11b or 802.11g access point (for Infrastructure Mode) or

another 802.11a, 802.11b, or 802.11g wireless adapter (for Ad-Hoc; Peer-to-Peer

networking mode.)

Check Your Package Contents

These are the items included with your DWL-AG660 purchase:

The Install Screen will appear.

If the CD Autorun function

does not automatically start

on your computer , go to Start

> Run and type “D:\driver\

setup.exe.” If it does start,

proceed to the next screen.

The letter “D”

represents the letter

of the CD-ROM drive.

Your CD-ROM drive may

be a different drive letter.

Type “D:\driver\setup.exe.”

Click OK

Click Next

Continued...

Click Next

Click Install Driver

Shut down your computer

Click Next

Click Finish

Continued...

Installing the DWL-AG660 Wireless

Cardbus Adapter in Your Computer

Link/Activity LED

Indicates that the DWL-AG660

is properly installed when the

computer is on and blinks when

data is being transmitted

Antenna

Used to wirelessly

connect to

802.11a, b or g

networks.

A. Make sure to turn off the laptop computer.

B. Locate the Cardbus slot on your laptop computer.

32-bit connector

This is the connector that ﬁts

into the Cardbus slot of your

laptop.

C. Gently insert the DWL-AG660 into the Cardbus slot in your laptop

computer (as shown.)

Restart Your Computer

When you restart your computer

this Found New Hardware

Wizard (Windows XP) screen

will appear:

Click Next

For Windows XP: This Hardware

Installation alert screen may appear

after the desktop computer restarts.

Select Install the software

automatically (Recommended)

Click Continue Anyway

to ﬁnalize the installation

Click Finish to ﬁnalize

the installation.

The D-Link driver software for this

device is undergoing Windows Logo testing.

Microsoft certiﬁcation is pending.

For Windows 2000, this

Digital Signature Not

Found screen may appear

after your computer restarts.

The D-Link driver software for this device is

undergoing Windows Logo testing. Microsoft

certiﬁcation is pending.

Click Yes to ﬁnalize the

installation.

Your Installation is Complete!

Continued...

After you have ﬁnished the installation in Windows XP, 2000, Me, or

98SE, the D-Link AirPremierTM DWL-AG660 Conﬁguration Utility will

automatically start and the utility icon will appear in the bottom right hand

corner of the desktop screen (systray). If this icon appears GREEN,

then you have successfully installed the DWL-AG660, are connected

to a wireless network and are ready to communicate!

Double-click the utility icon to

use the conﬁguration utility.

If the utility icon does not appear,

double-click the shortcut icon that

has appeared on your desktop.

Appendix

Click the XP Networking icon

to use the Zero Conﬁguration

Wireless Settings.

Click Advanced

Uncheck “Use

Windows to conﬁgure

my wireless network

settings.”

Click OK

For Windows XP, if you wish to use the AirPremierTM utility, please do the

following steps.

Click Wireless

Networks

Appendix (Continued)

Using the Conﬁguration Utility

G. Tx Rate: The default

setting is Auto; meaning,

Tx Rate settings are

automatically determined

by the DWL-AG660

depending on the

distance from the access

point.

J. Packet Count:

Graphically displays

the statistics of data

transmitted and

received.

I. Link Quality / Signal

Strength: Displays the Link

Quality for the DWL-AG660

wireless connection to the

access point. The Signal

Strength represents the

wireless signal between the

access point and the DWL-

AG660. The percentage

coincides with the graphical

bar.

H. Channel:

Displays the channel

information. By

default, the channel is

set to 6 and selection

is automatically

determined by the

wireless access point

or router.

C. Frequency:

Displays the

current frequency

used by the current

connection to the

access point.

E. Encryption:

Displays the current

encryption status

of the wireless

connection.

A. Status: Displays

the MAC address

of the access point

that is associated

with the DWL-

AG660.

B. SSID: The Service

Set Identiﬁer is the

name assigned to the

wireless network. The

factory SSID setting

is set to default.

D. Wireless Mode:

The factory setting is

set to Infrastructure.

Ad-Hoc mode is used

for Peer-to-Peer

networking.

F. Connection Info:Displays

connected or authenticated

information.

O. Key Length:When

encryption is enabled, you

will have the option to specify

the level and key format of

the encryption used. Select

the appropriate Key Index:

1-4 and enter ACSII or

hexadecimal digits in the

appropriate ﬁeld.

P. IEEE 802.1X:When

encryption is enabled,

you will have the option to

specify if you wish to use

802.1x authentication.

N. Data Encryption:

The default setting is

set to Disable. The

adapter supports

WEP and AES when

encryption is enabled.

k. SSID: The Service Set

Identiﬁer is the name assigned

to the wireless network. The

factory SSID setting is set to

default. Make changes here

to match the SSID on existing

wireless router or access point.

L. Wireless Mode:

The factory setting is

set to Infrastructure.

Ad-Hoc mode is used

for Peer-to-Peer

networking.

M. Authentication:

You can specify the

authentication mode

for the wireless

network. The default

setting is set to Open

Authentication.

IP Address Conﬁguration

To connect to a network, make sure

the proper network settings are

conﬁgured for DWL-AG660.

For Microsoft Windows XP:

Go to Start > Right-click on

My Network Places >

select Properties > Right-click and select

Properties on the Network Connection

associated with the DWL-AG660.

Input a static IP address in the same range as the

wireless router or access point.

Static IP address setup

Click OK

IP address: 192.168.0.52

Subnet mask: 255.255.255.0

Click OK

Click Internet Protocol (TCP/IP)

Click Properties

Select Obtain an IP address

automatically (if the wireless

router or access point has DHCP

server enabled)

Select Obtain DNS server

address automatically

Dynamic IP address setup

Used when a DHCP server is available on

the local network. (i.e. Router)

Used when a DHCP server is not available

on the local network.

Select Use the following IP address
