Custom Audio Electronics TK300II Manuel d'installation

PRINTER READY

28/04/08 11:03:50

TK300II

COMMAND REFERENCE

KPM300

KUBE II

KUBE-L

Edit by:

CUSTOM ENGINEERING S.p.A.

Str. Berettine 2 - 43010 Fontevivo (PARMA) - Italy

http: www.custom.biz

2 Command Reference

1 INTRODUCTION

1.1 Command description

Each command reported in this manual is described as shown in the following picture. In the ﬁrst heading line

(grey colour) is reported the hexadecimal command value. In the second heading line are listed the printers on

which it is possible to use the command (for example printer AAAA).

The next ﬁelds give all the information useful to use the command.

[Name] Command title

[Format] ASCII, hexadecimal and decimal command value.

[Range] Limits of the values the command and its variables can take

[Description] Description of command function

[Notes] Additional information about command use and settings .

[Default] Default value of the command and its variables.

[Reference] Pertaining commands related to described command.

[Example]

Printers: AAAA, BBBB,

CCCC

[

Name]

Print and carriage return

[

Format]

ASCII

Hex

Decimal

[

Ran

[

Description]

When autofeed

is “CR enabled”, thi

otherwise it is disregarded.

[

Notes]

This command sets the print position

AAAA, BBBB

•

This command sets the print p

CCCC

•

This command is immediat

is full.

• This status is transmitted when

•

[

ault

]

[Reference] $0A

[

Example

]

ctions in the same wa

as $0A,

the line.

innin

the line.

d even when the data bu

uence is received

1° HEADING: Command title

2° HEADING: Printers that use the command

Information valid for printers

AAAA, BBBB, CCC

Information valid for printers

AAAA, BBBB

Information valid for printer

CCCC

XXYY

The information reported in the picture are aligned with line X or line Y:

LINE X Description valid for all the printers listed in the second heading line.

LINE Y Description valid for a speciﬁc printer (written in bold).

LEGEND

$ indicates the representation of the command hexadecimal value (for example $40 means

HEX 40).

{ } indicates an ASCII character not performable.

n, m, t, x, y

are optional parameters that can have different values.

Introduction

Command Reference 3

1.2 Print direction

The printer has two printing direction which can be selected by means of the control characters: normal e

reverse.

PAPER OUTFEED DIRECTION

Normal Mode Reverse Mode

1234567890

abcdefghilmnopqrs

ABCDEFGHILMNOPQRS

abcdefghilmnopqrs

1234567890

Introduction

4 Command Reference

2 ESC/POSTM EMULATION

The following table lists all the commands for function management in ESC/POS Emulation of the printer. The

commands can be transmitted to the printer at any moment, but they will only be carried out when the commands

ahead of them have been executed. The commands are carried out when the circular buffer is free to do so.

COMMAND DESCRIPTION TABLE Tab.1

Com. HEX Com. ASCII Description

PRINT COMMANDS

$0A LF Print and line feed

$0D CR Print and carriage return

$1B $4A ESC J Print and feed paper

$1B $64 ESC d Print and feed paper n lines

$1C $82 FS { } Print date

$1C $83 FS { } Print time

LINE SPACING COMMANDS

$1B $30 ESC 0 Select 1/8-inch line spacing

$1B $32 ESC 2 Select 1/6-inch line spacing

$1B $33 ESC 3 Set line spacing using minimum units

CHARACTER COMMANDS

$18 CAN Cancel current line trasmitted

$1B $20 ESC SP Set character right-side spacing

$1B $21 ESC ! Set print mode

$1B $25 ESC % Select/cancel user-deﬁned character set

$1B $26 ESC & Deﬁne user-deﬁned characters

$1B $2D ESC - Turn underline mode on/off

$1B $3F ESC ? Cancel user-deﬁned characters

$1B $45 ESC E Select emphasized mode

$1B $47 ESC G Select double-strike mode

$1B $4D ESC M Select character font

$1B $52 ESC R Select international character set

$1B $56 ESC V Select print mode 90° turned

$1B $74 ESC t Select character code table

$1B $7B ESC { Set/cancal upside-down character printing

$1B $C1 ESC { } Set/cancel cpi mode

$1D $21 GS ! Select character size

$1D $42 GS B Turn white/black reverse printing mode on/off

PRINT POSITION COMMANDS

$08 BS Back space

$09 HT Horizontal tab

$1B $24 ESC $ Set absolute position

$1B $28 $76 ESC ( v Set relative vertical print position

ESC/POS™ Emulation

Command Reference 5

$1B $44 ESC D Set horizontal tab position

$1B $5C ESC \ Set relative print position

$1B $61 ESC a Select justiﬁcation

$1D $4C GS L Set left margin

$1D $57 GS W Set printing area width

BIT-IMAGE COMMANDS

$1B $2A ESC * Select image print mode

$1D $2A GS * Deﬁne downloaded bit image

$1D $2F GS / Print downloaded bit image

$1D $76 $30 GS v 0 Print raster image

VERIPRINT ® COMMANDS

$1C $8A FS { } Delete the disk contents

$1C $8B FS { } Print images saved in SD/MMC card

$1F $46 US F Enable/disable scanner

$1F $4D $57 US M W Request for paper width stored

$1F $4D $77 US M w Request for paper width detection

STATUS COMMANDS

$10 $04 DLE EOT Real-time status transmission

$1B $76 ESC v Transmit printer status

$1D $72 GS r Transmit status

$1D $E0 GS { } Enable / disable automatic FULL STATUS back

$1D $E1 GS { } Reading of length paper (cm) available before virtual paper end

$1D $E2 GS { } Reading number of cuts performed from the printer

$1D $E3 GS { } Reading of length (cm) of printed paper

$1D $E5 GS { } Reading number of power up

BARCODE COMMANDS

$1C $B0 FS { } Sets barcode reader status

$1C $B1 FS { } Get barcode reader status

$1C $B2 FS { } Barcode reader trigger

$1D $28 $6B GS ( k Print two-dimensional barcode

$1D $48 GS H Select printing position of HRI characters

$1D $66 GS f Select font for HRI characters

$1D $68 GS h Select barcode height

$1D $6B GS k Print barcode

$1D $77 GS w Select horizontal size (enlargement) of barcode

MACRO FUNCTION COMMANDS

$1D $3A GS : Set start/end of macro deﬁnition

$1D $5E GS ^ Execute macro

MECHANISM CONTROL COMMANDS

$1B $69 ESC i Total cut

$1B $6D ESC m Partial cut

ESC/POS™ Emulation

6 Command Reference

$1C $C1 FS { } Paper recovery after cut

$1D $56 GS V Select cut mode

MISCELLANEOUS COMMANDS

$1B $63 $35 ESC c 5 Enable/Disable keys panel

$1B $3D ESC = Select device

$1B $40 ESC @ Initialize printer

$1B $70 ESC p Generate pulse

$1C $3C FS < Change printer emulation to SVELTA

$1C $6C FS l Reload paper

$1C $80 FS { } Read date/time of the real time clock

$1C $81 FS { } Set date/time of the real time clock

$1C $84 FS { } Set user-deﬁned date/time formats

$1C $90 FS { } Get number of stored logo

$1C $91 FS { } Get pictures header list

$1C $92 FS { } Get pictures header info

$1C $93 FS { } Print logo

$1C $94 FS { }

Save the image received from serial port into the ﬂash

$1C $C0 FS { } Hardware reset

$1D $49 GS I Transmit printer ID

$1D $50 GS P Set horizontal and vertical motion units

$1D $E6 GS { } Virtual paper end limit

TICKET MANAGEMENT COMMANDS

$1D $7C GS { } Set printing density

$1D $E7 GS { } Set notch distance

$1D $F0 GS { } Set printing speed

$1D $F6 GS { } Ticket align at print

$1D $F8 GS { } Ticket align at cut

ESC/POS™ Emulation

Command Reference 7

Given below are more detailed descriptions of each command.

$08

Printers: KPM300

VeriPrint, KUBE II VeriPrint, KUBE-L VeriPrint, TK300II VeriPrint

[Name] Back space

[Format] ASCII BS

Hex 08

Decimal 8

[Range]

[Description] Moves print position to previous character.

[Notes] Can be used to put two characters at the same position.

[Default]

[Reference]

[Example]

$09

Printers: KPM300 VeriPrint, KUBE II VeriPrint, KUBE-L VeriPrint, TK300II VeriPrint

[Name] Horizontal tab

[Format] ASCII HT

Hex 09

Decimal 9

[Range]

[Description] Moves the print position to the next horizontal tab position.

[Notes] • Ignored unless the next horizontal tab position has been set.

• If the command is received when the printing position is at the right margin, the printer

executes print buffer full printing and horizontal tab processing from the beginning of the

next line.

• Horizontal tab position are set using $1B $44

[Default]

[Reference] $1B $44

[Example]

$0A

Printers: KPM300 VeriPrint, KUBE II VeriPrint, KUBE-L VeriPrint, TK300II VeriPrint

[Name] Print and line feed

[Format] ASCII LF

Hex 0A

Decimal 10

[Range]

[Description] Prints the data in the buffer and feeds one line based on the current line spacing.

[Notes] • Sets the print position to the beginning of the line.

• If the buffer is empty, the printing feeds of (character height + spacing gap) dot.

[Default]

[Reference] $1B $32, $1B $33, $0D

[Example]

ESC/POS™ Emulation

8 Command Reference

$0D

Printers: KPM300 VeriPrint, KUBE II VeriPrint, KUBE-L VeriPrint, TK300II VeriPrint

[Name] Print and carriage return

[Format] ASCII CR

Hex 0D

Decimal 13

[Range]

[Description] When autofeed is “CR enabled”, this command functions in the same way as $0A, oth-

erwise it is disregarded.

[Notes] • Sets the print position to the beginning of the line.

[Default] See “Autofeed in setup” parameter.

[Reference] $0A

[Example]

$10 $04

Printers: KPM300 VeriPrint, KUBE II VeriPrint, KUBE-L VeriPrint, TK300II VeriPrint

[Name] Real-time status transmission

[Format] ASCII DLE EOT n

Hex 10 04 n

Decimal 16 4 n

[Range] 1 ≤n ≤4; n=17; n=20; n=21

[Description] Transmits the selected printer status speciﬁed by nin real time according to the following

parameters:

n = 1 transmit printer status

n = 2 transmit off-line status

n = 3 transmit error status

n = 4 transmit paper roll sensor status

n = 17 transmit print status

n = 20 transmit FULL STATUS

n = 21 transmit printer ID

n = 22 transmit EXTENDED FULL STATUS

[Notes] • Immediately executed even when the data buffer is full.

• This status is transmitted whenever data sequence $10 $04 n is received.

[Default]

[Reference] See tables below.

[Example] n=1: Printer status

BIT OFF/ON HEX Decimal FUNCTION

0 Off 00 0 Not used. Fixed to Off

1 On 02 2 Not used. Fixed to On

2 - - - RESERVED

3 Off 00 0 On-line.

On 08 8 Off-line.

4 On 10 16 Not used. Fixed to On

5 - - - RESERVED

6 - - - RESERVED

7 Off 00 0 LF key released

On 80 128 LF key pressed

ESC/POS™ Emulation

Command Reference 9

n=2: Off-line status

BIT OFF/ON HEX Decimal FUNCTION

0 Off 00 0 Not used. Fixed to Off

1 On 02 2 Not used. Fixed to On

2 Off 00 0 Cover closed

On 04 4 Cover opened

3 Off 00 0 Paper isn’t feeded by FEED. key

On 08 8 Paper is feeded by FEED. key

4 On 10 16 Not used. Fixed to On

5 Off 00 0 Paper present

On 20 32 Printing stop due to paper end

6 Off 00 0 No error

On 40 64 Error

7 Off 00 0 Not used. Fixed to Off

n=3: Error status

BIT OFF/ON HEX Decimal FUNCTION

0 Off 00 0 Not used. Fixed to Off

1 On 02 2 Not used. Fixed to On

2 - - - RESERVED

3 Off 00 0 Cutter ok

On 08 8 Cutter error

4 On 10 16 Not used. Fixed to On

5 Off 00 0 No unrecoverable error.

On 20 32 Unrecoverable error

6 Off 00 0 No auto-recoverable error

On 40 64 Auto-recoverable error

7 Off 00 0 Not used. Fixed to Off

n=4: Paper roll sensor status

BIT OFF/ON HEX Decimal FUNCTION

0 Off 00 0 Not used. Fixed to Off

1 On 02 2 Not used. Fixed to On

2,3 Off 00 0 Paper present..

On 0C 12 Near paper end.

4 On 10 16 Not used. Fixed to On

5, 6 Off 00 0 Paper present

On 60 96 Paper not present

7 Off 00 0 Not used. Fixed to Off

n=17: Print status

BIT OFF/ON HEX Decimal FUNCTION

0 Off 00 0 Not used. Fixed to Off

1 On 02 2 Not used. Fixed to On

2 Off 00 0 Paper drag motor off

On 04 4 Paper drag motor on

3 - - - RESERVED

4 On 10 16 Not used. Fixed to On

5 Off 00 0 Paper present

On 20 32 Paper absent

6 - - - RESERVED

7 Off 00 0 Not used. Fixed to Off

ESC/POS™ Emulation

10 Command Reference

Autres manuels pour TK300II

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Custom Audio Electronics Imprimante

Custom Audio Electronics

Custom Audio Electronics Kube Scanner 120 Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics Q3X Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics BIGII Touch PC Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics VKP80III Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics KPM302III Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics TG1260HIII Series Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics PRT 80 Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics SMICE-PS Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics TG2460H Instructions d'installation

Custom Audio Electronics

Custom Audio Electronics FT190 II Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics TPTCM60IIIL Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics S16SB Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics MY PRINTER X Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics P 150 Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics P190 Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics F 190 Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics FUSION NF Supplément

Custom Audio Electronics

Custom Audio Electronics Q1 Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics DPT 282 PLM Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics K3 Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics VKP80II-EE Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics PT 285 Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics FH190SP Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics KPM302 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
