INSTRUCTION AND

RECIPE BOOKLET

For your safety and continued enjoyment of this product,

always read the instruction book carefully before using.

Smart Stick®Variable Speed Hand Blender CSB-179

IMPORTANT SAFEGUARDS

When using an electrical appliance, especially when children are

present, basic safety precautions should always be taken, including

the following:

1. READ ALL INSTRUCTIONS.

2. Unplug from outlet when not in use, before putting on or

taking off parts, and before cleaning. To unplug, grasp plug

and pull from electrical outlet. Never pull cord.

3. To protect against electric shock, do not put the motor body,

cord or electrical plug of this hand blender in water or other

liquids. Only the detachable blending shaft and other certain

parts of this appliance have been designed for immersion into

water or other liquids. Never submerge any other portion of this

unit. If hand blender falls into liquid, remove immediately. Do not

reach into the liquid without unplugging the unit first.

4. This appliance should not be used by children. To avoid

possible accidental injury, close supervision is necessary when

any appliance is used by or near children or individuals with

certain disabilities.

5. Avoid contact with moving parts.

6. During operation, keep hands, hair and clothing, as well as

spatulas and other utensils, away from attachments and any

mixing container to reduce risk of injury to persons and/or

damage to the appliance. A spatula may be used, but must be

used only when the unit is not operating.

7. Do not operate any appliance with a damaged cord or plug,

or after the appliance has malfunctioned or has been dropped

or damaged in any way or is not operating properly. Return the

appliance to the nearest Cuisinart Repair Center for examination,

repair, or mechanical or electrical adjustment.

8. Remove detachable shaft from the motor body before washing

the blades or shaft.

9. Blades are SHARP. Handle carefully when removing,

inserting or cleaning. Exercise the same care when removing

or inserting the cutting blade, or reversing disc for the food

processor attachment.

10. When mixing liquids, especially hot liquids, use a tall container

or mix small quantities at a time to reduce spillage, splattering

and the possibility of injury from burning.

11. To reduce the risk of injury, never place chopper/grinder

attachment cutting blade on base without first putting work bowl

properly in place.

12. Be certain the food processor attachment cover is securely

locked in place before operating appliance. Do not attempt to

remove cover until blade has stopped rotating.

13. Check work bowl for presence of foreign objects before using.

14. The use of attachments or accessories not recommended by

Cuisinart may cause fire, electric shock, or risk of injury.

15. Do not use outdoors or for other than its intended use.

16. Do not let any cord hang over the edge of the table or counter.

Do not let cord contact hot surfaces, including stovetop.

17. Make sure the appliance is off, the motor has stopped

completely, and the appliance is unplugged from outlet before

putting on or taking off attachments, and before cleaning.

18. Maximum rating is based on the 300W chopper/grinder

attachment that draws the greatest power.

19.

Do not operate your appliance in an appliance garage or

under a wall cabinet. When storing in an appliance garage,

always unplug the unit from the electrical outlet. Not doing

so could create a risk of fire, especially if the appliance

touches the walls of the garage or the door touches the unit

as it closes.

SAVE THESE INSTRUCTIONS

FOR HOUSEHOLD USE ONLY

NOTICE

This appliance has a polarized plug (one blade is wider than the

other). As a safety feature, this plug will fit in a polarized outlet only

one way. If the plug does not fit fully in the outlet, reverse the plug.

If it still does not fit, contact a qualified electrician. Do not attempt

to defeat this safety feature.

CONTENTS

Important Safeguards ....................................2

Unpacking Instructions ...................................4

Parts and Features ......................................5

Assembly..............................................7

Blending Attachment................................7

Chopper/Grinder Attachment .........................7

Whisk Attachment ..................................8

Reversible Blade ...................................8

Operation.............................................11

Blending.........................................11

Whisking ........................................12

Pulsing..........................................12

Chopping/Grinding ................................12

Cleaning and Maintenance ...............................13

Tips and Hints .........................................13

Frequent Uses for Chopper/Grinder ........................16

Recipes ..............................................17

Warranty .............................................30

UNPACKING INSTRUCTIONS

Place the package containing the Cuisinart®Smart Stick®Variable

Speed Hand Blender on a sturdy surface. Unpack the hand blender

from its box by removing the upper protective insert. Gently slide the

unit from the box. Remove all support materials from the box and

replace the upper insert. Save packaging for possible repacking of the

unit.

NOTE: The blending blade is extremely sharp.

Before using the Cuisinart®Smart Stick®Variable Speed Hand Blender

for the first time, we recommend that you wipe the motor body

housing with a clean, damp cloth to remove any dirt or dust. Dry it

thoroughly with a soft, absorbent cloth. Handling it carefully, wash the

detachable blending shaft with fixed-mount blade and the whisk by

hand. Dry thoroughly before use. Read all instructions completely for

detailed operating procedures.

PARTS AND FEATURES

1. Variable Speed Slide Control: Lets you adjust speed from low to

high for the ingredients you are blending.

2. Comfort Handle: The ergonomic handle allows you to maneuver

the hand blender with ease.

3. LOCK/UNLOCK Button: Must be pressed to unlock before

power handle will operate.

4. ON/OFF Button: Simply press and hold down the button to

blend. Once the button is released, blending will stop.

4a. Pulse Feature: Repeatedly press and release the ON/OFF

button to PULSE (while holding down the LOCK/UNLOCK

button).

5. Motor Body Housing: Powers the blender. Release button in

back makes it easy to attach and detach blending shaft and

whisk assembly.

6. Release Button: (not shown)

7. Detachable Blending Shaft

7a. Blade Guard: Snaps into the motor body housing. The fixed-

mount stainless blade is partially covered by a stainless guard

to keep splatter to a minimum.

7b. Stainless Steel Blade

8. Whisk Attachment: Whisk attachment snaps into the gearbox

which connects to the motor body housing. The whisk is great for

whipping cream, egg whites and other delectable treats.

8a. Detachable Gear Box: Whisk attaches to it.

9. Chopper/Grinder Attachment with Reversible Blade: Chop,

mince and grind with the Cuisinart®chopper/grinder attachment.

Chopper/grinder attaches to the motor body in place of the

blending shaft or whisk attachment.

10. Mixing/Measuring Cup: 3-cup (24 oz.) mixing cup is top-rack

dishwasher safe. Use this container to blend drinks, shakes,

salad dressings and more. Designed for easy gripping and drip-

free pouring.

8. Whisk

Attachment

8a. Detachable

Gear Box

PARTS AND FEATURES

9. Chopper/Grinder

Attachment

5. Motor

Body

Housing

6. Release

Button

(not shown)

7. Blending

Shaft

10. Mixing/

Measuring

Cup

4. ON/OFF

Button

4a. Pulse

Feature

7a. Blade Guard

7b. Stainless

Steel Blade

(not shown)

3. LOCK/

UNLOCK

Button

2. Comfort

Handle

1. Variable Speed

Slide Control

ASSEMBLY

BLENDING ATTACHMENT

1. Align the motor body housing with

the blending shaft and push the

pieces together until you hear and

feel them click together. It may be

helpful to press the release button

when assembling.

2. Plug the power cord of the hand

blender into an electrical outlet.

CHOPPER/GRINDER ATTACHMENT

1. Connect the motor body

housing to the top of the

work bowl cover.

2. Align the spine in the

chopper/grinder cover’s

drive shaft with the ribbed

opening on the underside

of the motor body housing.

3. When aligned properly,

slide the two pieces

together until you feel

and hear a slight click.

CHOPPER/GRINDER ATTACHMENT

4. Place the chopping/grinding blade into

center of the work bowl over metal blade shaft.

5. Place the motor body housing with cover

on top of the work bowl and rotate clockwise

to lock into place.

6. Plug the power cord of the hand blender

into an electrical outlet.

WHISK ATTACHMENT

1. Align the motor body housing

with the assembled whisk

attachment and push the pieces

together until you hear and feel

them click together. It may be

helpful to press the release

button when assembling.

NOTE: Whisk and whisk

gearbox are detachable

from one another.

REVERSIBLE BLADE

The Cuisinart®Smart Stick®Variable Speed Hand Blender chopper/

grinder attachment is equipped with a reversible blade. This blade is

sharp on one side and blunt on the other. The blade is attached to a

plastic ring that slides over the plastic blade sheath, so it can be

easily turned over to select the appropriate blade. To reverse the

blade, see detailed instructions on page 10. Also see Frequent Uses

for Chopper/Grinder (page 16).

Assemble the parts:

1. Place the work bowl on a flat, dry, stable

surface near an electrical outlet with the

same specifications as the hand blender.

2. The fully assembled two-piece metal

blade assembly (A) should be attached to

the bottom of the work bowl. If not, slide

it onto the metal shaft (B) in the bowl.

IF METAL BLADE RING (C) HAS NOT BEEN ATTACHED TO PLASTIC

SHEATH (D), OR TO SAFELY REASSEMBLE BLADE ASSEMBLY

AFTER USE AND CLEANING, CAREFULLY FOLLOW THESE

INSTRUCTIONS:

Assembling the Blade Ring

ALWAYS HOLD THE BLADE RING BY THE CENTRAL HUB’S

HOLDING GRIPS (E). DO NOT TOUCH THE RAZOR-

SHARP BLADES!

To assemble using base of bowl to turn blade:

1. Turn work bowl upside down and stand the

sheath (D) on the raised round nub in the center

of bowl bottom.

2. Place the metal blade ring (C) over the sheath, lining up the two

notches in the interior of the center hub with the two ridges (F) on

either side of the sheath. Let the blade ring slide to the bottom

of the sheath.

3. Grasp the top of the sheath firmly and turn counterclockwise to

lock the blade into place on the sheath. The three rubberized

nubs will guide the blade ring without you needing to touch it.

4. To remove the blade from the sheath, stand the metal blade

assembly on the overturned work bowl and turn the sheath

clockwise to unlock the blade. Holding the central hub by the

grips, carefully lift the blade ring off the sheath.

To assemble turning blade by hand:

1. Carefully place the metal blade ring (C) over the sheath (D), lining

up the two notches in the interior of the center hub with the two

RUBBER

NUBS CENTER

NUBS

ridges (F) on either side of the sheath. Let the blade ring slide to

bottom of sheath.

2. Grasp the top of the sheath firmly and, holding the grips (E) on

the central hub of the blade ring, turn the blade ring clockwise to

lock it into place on the sheath.

3. To remove the blade from the sheath, hold the sheath firmly and

holding the central hub by the grips, turn the blade ring

counterclockwise to unlock it and carefully lift it off the sheath.

TWO-WAY CUTTING BLADE

(See section on Frequent Uses for Chopper/Grinder, page 16, to learn

which side of blade – SHARP or DULL – is best for what you are

prepping.)

SHARP – Place blade ring over plastic blade sheath so the word

“SHARP” is on top side of blade.

DULL – Place blade ring over plastic blade sheath so no writing is on

top of blade.

SHARP SIDE

DULL SIDE UP

Autres manuels pour Smart Stick CSB-179

Table des matières

Autres manuels Cuisinart Mixer

Cuisinart

Cuisinart SMARTPOWER SPB-7C Series Manuel de service

Cuisinart

Cuisinart PowerBlend 600 Manuel utilisateur

Cuisinart

Cuisinart SmartStick CSB-100 Manuel utilisateur

Cuisinart

Cuisinart PowerBlend 600 SPB-10 Series Manuel d'installation et d'exploitation

Cuisinart

Cuisinart VELOCITY Ultra 1 HP SPB-650 Manuel de service

Cuisinart

Cuisinart Hurricane CSB-750H Manuel utilisateur

Cuisinart

Cuisinart SPB-8 Series Manuel de service

Cuisinart

Cuisinart Smart Stick CSB-75 Series Manuel de service

Cuisinart

Cuisinart SMARTPOWER CLASSIC 0511000 Manuel de service

Cuisinart

Cuisinart Mini Prep Pro ECH4 Series Manuel utilisateur

Cuisinart

Cuisinart Smart Stick PowerTrio CSB-80C Manuel de service

Cuisinart

Cuisinart RPB-100XA Manuel d'exploitation

Cuisinart

Cuisinart CBJ-450 Manuel de service

Cuisinart

Cuisinart EVOLUTIONX RPB 100 Manuel d'exploitation

Cuisinart

Cuisinart EVOLUTIONX CORDLESS RHB-100C Manuel d'exploitation

Cuisinart

Cuisinart Tasty HB200T Manuel utilisateur

Cuisinart

Cuisinart SmartPower SPB-7 Series Manuel de service

Cuisinart

Cuisinart CSB800U Manuel utilisateur

Cuisinart

Cuisinart SSB-1HK Manuel utilisateur

Cuisinart

Cuisinart VELOCITY Manuel utilisateur

Cuisinart

Cuisinart CBT700U Manuel utilisateur

Cuisinart

Cuisinart SBC-1000 Manuel utilisateur

Cuisinart

Cuisinart csb-175 Guide rapide

Cuisinart

Cuisinart CBT700E Manuel utilisateur

Manuels Mixer populaires d'autres marques

ROTOR

ROTOR 1125.201 Manuel utilisateur

Braun

Braun Multiquick 5 Vario series Manuel utilisateur

ARENDO

ARENDO MIRA 305424 Manuel utilisateur

CHEF-BUILT

CHEF-BUILT CCB-3500 Manuel utilisateur

Viconte

Viconte VC-4406 Manuel utilisateur

Oster

Oster BLSTAB-CB0 Manuel utilisateur

HOFFEN

HOFFEN MC-3005 Manuel utilisateur

Black & Decker

Black & Decker BLC18750DM Manuel utilisateur

Sunbeam

Sunbeam 4182 Manuel utilisateur

Bialetti

Bialetti FMX35 Manuel utilisateur

Black & Decker

Black & Decker BL8000 Manuel utilisateur

Duronic

Duronic BL530 Manuel utilisateur

Exquisit

Exquisit MS 3002 wes Manuel utilisateur

Lumme

Lumme LU-KP1891A Manuel utilisateur

Binatone

Binatone HB-735 Manuel utilisateur

Moulinex

Moulinex LM936E10 Manuel utilisateur

Oster

Oster VERSA Manuel d'installation et d'exploitation

Ninja

Ninja NN210Q Manuel utilisateur
