Crestron IM-WCCV Comment utiliser

Crestron IM-WCCV-M

iMedia Wall Plate Computer &

Video Center

Operations & Installation Guide

This document was prepared and written by the Technical Documentation department at:

Crestron Electronics, Inc.

15 Volvo Drive

Rockleigh, NJ 07647

1-888-CRESTRON

All brand names, product names and trademarks are the property of their respective owners.

Crestron IM-WCCV-M iMedia Wall Plate Computer & Video Center

Contents

iMedia Wall Plate Computer & Video Center: IM-WCCV-M 1

Introduction ...............................................................................................................................1

Features and Functions................................................................................................1

Applications.................................................................................................................2

Internal Block Diagram ...............................................................................................3

Specifications ..............................................................................................................3

Physical Description....................................................................................................4

Industry Compliance ...................................................................................................7

Setup ..........................................................................................................................................8

Network Wiring........................................................................................................... 8

IM Wiring....................................................................................................................8

Installation................................................................................................................... 9

Hardware Hookup ..................................................................................................... 11

System Configuration................................................................................................ 12

Operation .................................................................................................................................13

Problem Solving ......................................................................................................................14

Troubleshooting......................................................................................................... 14

Reference Documents................................................................................................15

Further Inquiries ........................................................................................................ 15

Future Updates .......................................................................................................... 15

Return and Warranty Policies ..................................................................................................16

Merchandise Returns / Repair Service ...................................................................... 16

CRESTRON Limited Warranty.................................................................................16

Operations & Installation Guide – DOC. 6621A Contents •i

Crestron IM-WCCV-M iMedia Wall Plate Computer & Video Center

iMedia Wall Plate Computer &

Video Center: IM-WCCV-M

Introduction

Features and Functions

• A simple, affordable wall plate multimedia interface

• Streamlined user controls for foolproof operation

• iMedia transport for fast and easy single cable installation

• Supports XGA resolution up to 84 feet (25.6 meters), UXGA maximu

up to 34 feet (10.4 meters)

• Supports composite video signals

• Complete system setup in minutes using iMedia Wizard software

The iMedia Transport

The iMedia (IM) transport utilizes a single CAT5e* type cable to transmit computer

RGB, video and stereo audio signals to a single projector or plasma display. A

typical XGA signal (1024 x 768 pixels at 60 Hz) can be transmitted up to 84 feet

(25.6 meters) using iMedia, while higher resolutions up to 1600 x 1200 can be

handled over shorter distances. Audio is transmitted digitally at 20-bit, 48 kHz

resolution. Control and power signals are also contained on the same wire,

eliminating the need for separate control or power cables.

* For optimum performance, Crestron strongly recommends using CRESCAT-IM cable, available from

Crestron. Other high quality, low skew (15 ns per 100 m maximum) CAT5e/CAT6 wiring may also

be used with varying performance.

Wall Plate Multimedia Interface

The IM-WCCV-M is an iMedia transmitter designed to install in a standard three-

gang electrical box, providing composite video, RGB and stereo audio inputs for

connection to the output of a computer or AV source. Installing wiring for the

IM-WCCV-M is extremely simple requiring just a single CrestCAT-IM cable for

audio and video. Up to three IM-WCCV-Ms or other IM transmitters may be

installed as part of a complete system to provide multiple input locations within the

room.

Operations & Installation Guide – DOC. 6621A iMedia Wall Plate Computer & Video Center: IM-WCCV-M •1

iMedia Wall Plate Computer & Video Center Crestron IM-WCCV-M

Foolproof Operation

Every iMedia system is easy and intuitive to use. A single press of the VIDEO or

PC buttons on the face of the IM-WCCV-M selects the appropriate input, lowers the

screen or lift, turns on the projector (or plasma, etc.) and routes all the signals where

they need to go. The front panel volume control affords easy adjustment of the audio

level or wireless microphone level and the entire system can be turned off at any

time by simply holding down either button for five seconds.

For systems having more than one IM transmitter, selecting an input at a given input

location overrides the previously selected input at any other location. The audio level

for each input location is controlled individually by its respective volume control.

Applications

The IM-WCCV-M is an IM transmitter. As shown in the following diagram, IM

transmitters provide input points for video and PC sources on an IM receiver.

iMedia System Diagram

2 •iMedia Wall Plate Computer & Video Center: IM-WCCV-M Operations & Installation Guide – DOC. 6621A

Crestron IM-WCCV-M iMedia Wall Plate Computer & Video Center

Internal Block Diagram

The following diagram represents the signal routing and functions of the

IM-WCCV-M.

Internal Block Diagram of the IM-WCCV-M

VIDEO

LED

VOLUME

BUTTON

VGA

VIDEO

COMPUTER

AUDIO

STEREO

AUDIO

Video

Switch

Audio

Switch

Output

A/D

Power

Supply

Power

Micro-

processor

Specifications

Specifications for the IM-WCCV-M are listed in the following table.

IM-WCCV-M Specifications

SPECIFICATION DETAILS

RGB

Gain 0 dB (75 Ωtermination)

Formats RGBHV, RGBS or RGsB

Resolution 1024 x 768 @ 60 Hz with maximum cable

length of 84 feet, 1600 x 1200 @ 60 Hz with

maximum cable length of 34 feet; refer to

“IM Wiring” on page 8 for other resolutions

Video

Gain 0 dB (75 Ωtermination)

Formats 480i (NTSC), 576i (PAL)

Audio

A-D Conversion 20 bit, 48 kHz

Frequency Response 20 Hz to 20 kHz ±1 dB

Power Requirements Power is provided by the IM receiver via the

IM transport

(Continued on following page)

Operations & Installation Guide – DOC. 6621A iMedia Wall Plate Computer & Video Center: IM-WCCV-M •3

iMedia Wall Plate Computer & Video Center Crestron IM-WCCV-M

IM-WCCV-M Specifications (Continued)

SPECIFICATION DETAILS

Environmental

Temperature 41º to 104ºF (5º to 40ºC)

Humidity 10% to 90% RH (non-condensing)

Enclosure Three-gang wall plate, mountable in a 2.5 in

(6.35 cm) deep electrical box;

NOTE: Conduit must enter box via top or

bottom knockouts only

Dimensions

Height 4.50 in (11.43 cm)

Width 6.36 in (16.16 cm)

Depth 2.95 in (7.48 cm)

Weight 1.29 lbs (0.58 kg)

Physical Description

This section provides information on the connections, controls and indicators

available on your IM-WCCV-M.

IM-WCCV-M Physical View

4 •iMedia Wall Plate Computer & Video Center: IM-WCCV-M Operations & Installation Guide – DOC. 6621A

Crestron IM-WCCV-M iMedia Wall Plate Computer & Video Center

IM-WCCV-M Physical Dimensions - Front View Side View

6.36 in

(16.16 cm)

4.50 in

(11.43 cm)

2.95 in

(7.48 cm)

2.48 in

(6.29 cm)

Rear View

5.17 in

(13.14 cm)

2.53 in

(6.43 cm)

Connectors, Controls & Indicators

# CONNECTORS,

CONTROLS &

INDICATORS

DESCRIPTION

1 VOLUME

(1) Rotary knob, adjusts audio level for local input.

Microphone level is adjusted by holding the

VIDEO or PC button and turning the VOLUME

knob.

(Continued on following page)

Operations & Installation Guide – DOC. 6621A iMedia Wall Plate Computer & Video Center: IM-WCCV-M •5

iMedia Wall Plate Computer & Video Center Crestron IM-WCCV-M

Connectors, Controls & Indicators (Continued)

# CONNECTORS,

CONTROLS &

INDICATORS

DESCRIPTION

2 VIDEO

(1) RCA female, composite video input;

Input impedance: 75 Ω;

Maximum input: 1 Vp-p

3PC

PIN1

PIN6

PIN15

(1) DB15HD female, RGB (VGA) input:

Formats: RGBHV, RGBS, RG

Input impedance: 75 Ω;

Sync impedance: 1 kΩ;

Maximum input level: 1 V

p-p;

Maximum sync level: 5 V

p-p

PIN FUNCTION PIN FUNCTION

1 Red Video 9 No Connect

2 Green Video 10 Ground

3 Blue Video 11 No Connect

4 Reserved 12 Monitor Sense 1

5 Ground 13 Horizontal Sync

6 Red Ground 14 Vertical Sync

7 Green

Ground

15 Monitor Sense 2

8 Blue Ground

4 VIDEO

(1) Pushbutton with green LED; Momentary press

initiates “system power on” command and selects

local VIDEO input; press and hold for five seconds

or more initiates “system power off”.

5 PC

(1) Pushbutton with green LED; Momentary press

initiates “system power on” command and selects

local PC input; press and hold for five seconds or

more initiates “system power off”.

6 AUDIO

(2) RCA female;

Unbalanced stereo line level audio input (linked

with VIDEO);

Maximum input level: 2 V

rms

;

Input impedance: 10 kΩ

7 AUDIO

(1) 3.5 mm TRS mini phone jack;

Unbalanced stereo line level audio input;

Maximum input level: 2 V

rms

;

Input impedance: 10 kΩ

8 IM

1, 2, 3

(1) 8-wire RJ-45 female, iMedia output port;

Connects to IM input port of an iMedia receiver via

CresCAT-IM cable.

9 GROUNDING

WIRE

(1) flying lead, green, chassis ground wire

1. The eight-pin RJ-45 iMedia port accepts CresCAT-IM or CAT5E/CAT6 carrying video, audio, power

and control signals. Refer to the table on the following page for connector pinouts. Power is supplied

to pins 4 and 5 from the IM receivers.

6 •iMedia Wall Plate Computer & Video Center: IM-WCCV-M Operations & Installation Guide – DOC. 6621A
