Crestron HD-MD4X2-4KZ-E Manuel utilisateur

HD-MD4X2-4KZ-E and HD-MD4X1-4KZ-E

4K60 4:4:4 HDR AV Switchers

Web Interface Configuration Guide

Crestron Electronics, Inc.

The original language version of this document is U.S. English.

All other languages are a translation of the original document.

Regulatory Model: M201946001

Crestron product development software is licensed to Crestron dealers and Crestron Service Providers (CSPs) under a

limited nonexclusive, nontransferable Software Development Tools License Agreement. Crestron product operating

system software is licensed to Crestron dealers, CSPs, and end-users under a separate End-User License Agreement.

Both of these Agreements can be found on the Crestron website at www.crestron.com/legal/software_license_

agreement.

The product warranty can be found at www.crestron.com/warranty.

The specific patents that cover Crestron products are listed online at www.crestron.com/legal/patents.

Certain Crestron products contain open source software. For specific information, please visit

www.crestron.com/opensource.

Crestron, the Crestron logo, Crestron Toolbox, and XiO Cloud are either trademarks or registered trademarks of

Crestron Electronics, Inc. in the United States and/or other countries. macOS and Safari are either trademarks or

registered trademarks of Apple, Inc. in the United States and/or other countries. HDMI and High Definition Multimedia

Interface are either trademarks or registered trademarks of HDMI Licensing LLC in the United States and/or other

countries. Internet Explorer and Windows are either trademarks or registered trademarks of Microsoft Corporation in

the United States and/or other countries. Firefox is ether a trademark or registered trademark of the Mozilla Foundation

in the United States and/or other countries. USB-C and USB Type-C are either trademarks or registered trademarks of

USB Implementers Forum, Inc. in the United States and/or other countries. Other trademarks, registered trademarks,

and trade names may be used in this document to refer to either the entities claiming the marks and names or their

products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for

errors in typography or photography.

Contents

Introduction 1

Web Interface Configuration 1

Access the Web Interface 1

Access the Web Interface with a Web Browser 2

Access the Web Interface with the Crestron Toolbox™ Application 3

Actions Menu 4

Rebooting the AV Switchers 5

Restoring to Factory Default Settings 5

Updating Firmware 6

Downloading Logs 6

Managing Certificates 7

To Add Certificates 8

To Delete Certificates 8

EDID Management 9

To Load a Custom EDID File 10

To Delete a Custom EDID File 11

Downloading Configuration 11

Uploading Configuration 12

Status 13

Device 13

Input/Output 14

Inputs 14

Outputs 15

Network 15

Control System 16

Settings 17

System Setup 17

Network 18

Configure DHCP 18

Front Panel 19

Cloud Settings 19

Auto Update 20

Date/Time 21

Time Synchronization 21

Time Configuration 21

Control System 22

Service Ports 22

Inputs 23

Web Interface Configuration Guide — Doc. 8907B Contents • i

Global EDID 23

Inputs 24

Edit HDMI Input Settings 25

Outputs 26

Edit AUX Output Settings 26

Edit HDMI Output Settings 27

Routing 33

Configure Auto Route 33

Configure Follow Output 33

Configure Priority Routing 34

Route a Single Input to all the Outputs 34

Manually Route a Local Input to the Output 34

Security 35

Current User 35

Users 36

Create New Local User 37

Add Active Directory User 38

Delete User 38

View User Details 39

Update User Details 39

Groups 40

Create Local Group 41

Add Active Directory Group 41

Delete a Group 42

View Group Details 42

802.1x Configuration 43

To Configure AV Switchers for 802.1X Authentication 44

ii • Contents Web Interface Configuration Guide — Doc. 8907B

iii • Contents Web Interface Configuration Guide — Doc. 8907B

Web Interface Configuration Guide — Doc. 8907B HD-MD4X2-4KZ-E and HD-MD4X1-4KZ-E • 1

Introduction

The HD-MD4X2-4KZ-E and HD-MD4X1-4KZ-E are 4K60 4:4:4 HDR (High Dynamic Range) AV

switchers. The HD-MD4X2-4KZ-E is equipped with four HDMI® inputs and two HDMI outputs.

The HD-MD4X1-4KZ-E is equipped with four HDMI inputs and one HDMI output. The

HD-MD4X2-4KZ-E and HD-MD4X1-4KZ-E, hereinafter referred to as AV switchers, both include

features such as automatic switching of inputs, EDID management, HDCP 2.3 compliance,

enterprise-grade security, and XiO Cloud® service support.

Web Interface Configuration

The web interface of the AV switchers allows you to view status information and configure

network and device settings.

NOTE: Unless otherwise indicated in this guide, the web interface of the AV switchers is the

same.

Access the Web Interface

The web interface is accessed from a web browser. The following table lists operating systems

and their corresponding supported web browsers.

OPERATING SYSTEM SUPPORTED WEB BROWSERS

Windows® operating system Chrome™ web browser, version 31 and later

Firefox® web browser, version 31 and later

Internet Explorer web browser, version 11 and later

Microsoft Edge web browser

macOS® operating system Safari® web browser, version 6 and later

Chrome web browser, version 31 and later

Firefox web browser, version 31 and later

Operating System and Supported Web Browsers

To access the web interface, do either of the following:

lOpen it directly in a web browser.

lOpen a web browser from within the Crestron Toolbox™ application.

2 • HD-MD4X2-4KZ-E and HD-MD4X1-4KZ-E Web Interface Configuration Guide — Doc. 8907B

Access the Web Interface with a Web

Browser

1. Enter the IP address of the AVswitcher into a web browser.

NOTE: To obtain the IP address, press the Setup button on the AVswitcher to display

the IP address on the HDMI output. The IP address is displayed for 20 seconds.

2. If you are creating a user account for the first time, do the following; otherwise, skip to

step 3.

a. Enter a username in the Username field.

b. Enter a password in the Password field.

c. Re-enter the same password in the Confirm Password field.

d. Click Create User. The Device Administration page appears.

Web Interface Configuration Guide — Doc. 8907B HD-MD4X2-4KZ-E and HD-MD4X1-4KZ-E • 3

3. Enter the username in the Username field.

4. Enter the password in the Password field.

5. Click Sign In.

Access the Web Interface with the

Crestron Toolbox™ Application

To access the web interface by opening a web browser within the Crestron Toolbox™ application,

do the following:

1. Open the Crestron Toolbox™ application.

2. From the Tools menu, select Device Discovery Tool. You can also access the Device

Discovery Tool by clicking the Device Discovery Tool button ( ) in the Crestron Toolbox

toolbar. The AV switchers are discovered and listed in the device list on the left side of the

screen. The associated host name, IP address, and firmware version are also displayed.

NOTE: If there is security software running on the computer, a security alert might be

displayed when the Crestron Toolbox application attempts to connect to the network.

Make sure to allow the connection, so that the Device Discovery Tool can be used.

3. In the Device Discovery Tool list, double-click your device.

4. Enter your credentials in the Authentication Required dialog that opens, and then click Log

In.

5. Click the Web Configuration button in the Configuration page displayed on the left side of

the Device Discovery Tool.

4 • HD-MD4X2-4KZ-E and HD-MD4X1-4KZ-E Web Interface Configuration Guide — Doc. 8907B

Actions Menu

The Actions drop-down menu is displayed at the top right side of the interface and provides

quick access to common device functionality of the AV switchers, such as:

lRebooting

lRestoring

lUpdating Firmware

lDownloading Logs

lManaging Certificates

lEDID Management

lDownloading Configuration

lUploading Configuration

lSaving Changes

lReverting

Web Interface Configuration Guide — Doc. 8907B HD-MD4X2-4KZ-E and HD-MD4X1-4KZ-E • 5

Rebooting the AV Switchers

Certain changes to the settings may require the AV switchers to be rebooted to take effect. To

reboot the device, do the following:

1. Click Reboot in the Actions drop-down menu. The Confirmation message box appears.

2. Click Yes, Reboot Now to reboot the device. The Reboot message box appears.

Wait for the device reboot to complete before attempting to reconnect to the device.

Restoring to Factory Default Settings

1. Click Restore in the Actions drop-down menu to restore the settings of the AV switchers to

factory defaults.

NOTE: When settings are restored, all settings, including the network settings, will

revert to the factory default. If a static IP address is set, restoring the device to

factory default settings will revert the IP address to the default DHCP mode.

2. Click Yes in the Confirmation dialog to restore the AV switchers to factory settings. Click

No to cancel the restore operation.

A dialog is displayed again, indicating that the Restore process was successful and that

the device rebooted.
