Crestron UC-M70-NC-T Manuel utilisateur

The UC-M70-NC-T Crestron Flex tabletop conferencing system provides

a large room conference solution for use with Microsoft Teams® Rooms

software. It supports single or dual video displays and features a

Crestron Flex tabletop conference device and UC bracket assembly.

Minimum Requirements:

lA Microsoft Teams certified USB Camera (not included).

lA video display (not included) connected to the UCEngine. A second

display is optional.

lA Microsoft Teams Rooms provisioned account (not included).

In the Box

Tabletop Conference Device

1 Tabletop Conference Device, Microsoft Teams video

(6510716)

1 Cable, CAT5e, RJ-45 - RJ-45, 12 ft (3.7 m) (2033988)

1 Cable Retention Plate (2047908)

3 Tie Wrap (2047935)

UC Bracket Assembly

1 UC Bracket Assembly with UC Engine and HDMI® content

ingest (UC-BRKT-200-S-T-ASSY,6512689)

2 Anchor, Drywall, Plastic, 3/8 in. x 1/2 in. (9.5mm x

12.7mm) (2052565)

1 Key, Anchor (4529654)

2 Screw, 8-AB x 1-1/2 in. (38.1 mm), Pan Head, Combo

(2052567)

4 Tie Wrap (2047935)

Additional Items

1 Microphone pod (6508084)

1 Cable, CAT6a, RJ-45 - RJ-45, 20 ft (6.1 m) (6507640)

1 Cable, CAT5e, RJ-45 - RJ-45, 7 ft (2.1 m) (6509924)

1 Cable, DisplayPort™ to HDMI, 6 ft (1.8 m) (6508282)

1 Cable, HDMI, 20 ft (6.1 m) (6503567)

1 Cable, HDMI, 6 ft (1.8 m) (6512150)

1 Cable, USB 2.0, A - Micro-B, 6 ft (1.8 m) (6510947)

1 Cable, USB Extension, USB Type A Male-to-Female, 15 ft

(4.6m) (6508260)

1 Power supply (6500187)

UC-M70-NC-T QuickStart

Crestron Flex Tabletop Large Room Conference System for Microsoft Teams® Rooms

Mount Devices

Mount the UC Bracket Assembly

Mount the UC Bracket Assembly to VESA® compliant display devices, a

wall, or other building structure. Anchors and screws are supplied for

installation on walls with 3/8 in. (9.5mm) to 3/4 in. (19mm) thickness.

CAUTION: Preinstalled screws may protrude from the back of the

UC Bracket Assembly. Exercise caution when handling the UC

Bracket Assembly to avoid scratching or damaging surfaces.

NOTE: The integrated cable tie wraps are reusable. Avoid damaging

the cable tie wraps.

Install the Cable Retention Plate

The included cable retention plate provides tie-down points for cables

that connect to the Crestron® conference device.

Remove the adhesive backing from the cable retention plate and install

the plate on the underside of the conference device as shown in the

following diagram. Ensure the cable retention plate is firmly attached

before securing cables.

CAUTION: When turning over the device, place the device on a soft

surface to avoid damage.

NOTE: If a swivel mount kit (CCS-UCA-SMK) is to be used, use the

cable retention bracket included with the swivel mount kit as

described in the CCS-UCA-SMK DO Guide (Doc. 7882).

UC-M70-NC-T QuickStart

Crestron Flex Tabletop Large Room Conference System for Microsoft Teams® Rooms

Connect

Identify the UC Bracket Assembly

The UC Bracket Assembly is available in two models. Identify the model included with your Crestron Flex system. Tap or click the corresponding

image below to navigate to the appropriate connection instructions.

UC Bracket Assembly with HD-CONV-USB-200 UC Bracket Assembly with HD-CONV-USB-300

UC-M70-NC-T QuickStart

Crestron Flex Tabletop Large Room Conference System for Microsoft Teams® Rooms

System Overview

For UC Bracket Assembly with HD-CONV-USB-200

When connections are complete, the system appears as shown below. Refer to Make Connections for detailed connection instructions.

UC-M70-NC-T QuickStart

Crestron Flex Tabletop Large Room Conference System for Microsoft Teams® Rooms

For UC Bracket Assembly with HD-CONV-USB-300

When connections are complete, the system appears as shown below. Refer to Make Connections for detailed connection instructions.

UC-M70-NC-T QuickStart

Crestron Flex Tabletop Large Room Conference System for Microsoft Teams® Rooms

Make Connections

NOTE: For reference, the UC Bracket Assembly is shown with the HD-CONV-USB-200 in the following connection diagrams. Unless otherwise

indicated in this guide, the connections remain the same for the UC Bracket Assembly with HD-CONV-USB-200 and HD-CONV-USB-300.

1. Make UC Engine connections as shown in the following illustrations. The conference device can communicate with the UC Engine over a direct

connection or a network connection. Select one of the connection types as described below.

lMake a direct connection for simple installation and setup. Only use the direct connect adapter to connect the conference device to the UC

Engine. Do not use the direct connect adapter to connect the UC Engine to the network.

Direct Connection

UC-M70-NC-T QuickStart

Crestron Flex Tabletop Large Room Conference System for Microsoft Teams® Rooms

lMake a network connection if the system is to be managed by the XiO Cloud® service.

NOTE: When a network connection is used, disconnect the direct connect adapter from the UC Engine.

Network Connection

UC-M70-NC-T QuickStart

Crestron Flex Tabletop Large Room Conference System for Microsoft Teams® Rooms

2. Connect displays to the UC Engine.

UC-M70-NC-T QuickStart

Crestron Flex Tabletop Large Room Conference System for Microsoft Teams® Rooms

3. Connect a camera (not included) to the UC Engine as shown in the image below. Do not connect the camera to any of the other USB ports.

UC-M70-NC-T QuickStart

Crestron Flex Tabletop Large Room Conference System for Microsoft Teams® Rooms

4. Connect a laptop to the HD-CONV-USB-200 or HD-CONV-USB-300.

5. Bundle the cables to the bracket assembly with the integrated cable tie wraps. The cable tie wraps are reusable.
