Crestron CCS-UC-1-X Manuel utilisateur

The Crestron® CCS-UC-1-X provides video conference capabilities to a

conference room.

In the Box

1 CCS-UC-1-X, Crestron Mercury® X Tabletop UC System

Additional Items

1 Cable, USB 2.0, A - Micro B, 6 ft (1.83 m) (P/N 2047803)

1 Cable, HDMI®, Thin, 6 ft (1.8 m) (P/N 6508218)

1 Cable, CAT5e, RJ-45 Male - RJ-45 Male, 12 ft (3.66 m) (P/N

2033988)

1 Retention Plate, Cable (P/N 2047908)

3 Tie Wrap (P/N 2047935)

1 Power Pack, 24 VDC, 2.5 A, 100-240 VAC (P/N 2045873)

1 Power cord (varies by location)

Install the Cable Retention Plate

The cable retention plate provides tie-down points for cables that are

connected to the device.

Remove the adhesive backing from the cable retention plate and install it

on the underside of the CCS-UC-1-X as shown in the following diagram.

CAUTION: When turning over the device, place the device on a soft

surface to avoid damage.

NOTES:

lIf the CCS-UCA-SMK swivel mount kit is to be used, use the

cable retention bracket included with the CCS-UCA-SMK. For

details, refer to the CCS-UCA-SMK DO Guide (Doc. 7882) at

www.crestron.com/manuals.

lBefore securing cables, ensure the cable retention plate is firmly

attached.

CCS-UC-1-X Quick Start

Connect

Make connections to the CCS-UC-1-X.

Make Connections

When making connections, it is highly recommended to use the cables

shipped with the device. The cables and accessories have been designed so

that a service loop can be implemented prior to the cables leaving the

chassis body of the device (if necessary). If an extension option is required,

Crestron solutions should always be used and can be found under

MODELS & ACCESSORIES on the Crestron Mercury Xweb page.

CCS-UC-1-X Quick Start

Route Cables

CCS-UCA-SMK Swivel Mount Kit

If the CCS-UCA-SMK swivel mount kit is used in the installation, refer to

the CCS-UCA-SMK DO Guide for installation instructions (Doc. 7882).

NOTE: Do not route the HDMIand USB cables through the swivel tube.

USBand HDMICables

Insert the included USB and HDMI cables into the appropriate cable

channels on the underside of the CCS-UC-1-X.

NOTE:If the system design dictates that the USB and HDMI Input

cables should not exit through the front but at the rear with all other

cables, the USB and HDMIinput cables should be bundled and secured

to the cable retention plate on the underside of the CCS-UC-1-X. Make

sure to leave enough cable for a 2- to 3- inch service loop before exiting

the rear of the device.

Power,Ethernet, HDBaseT, and Other Cables

Bundle the Ethernet, HDBaseT, and other cables together and use a

provided tie wrap to secure the bundle to one of the positions on the cable

retention plate.

Configure Settings

For details on configuring the device, refer to the CCS-UC-1 Product

Manual (Doc. 7844).

CCS-UC-1-X Quick Start

Additional Information

Original Instructions

The U.S. English version of this document is the original instructions.

All other languages are a translation of the original instructions.

Crestron product development software is licensed to Crestron dealers and Crestron

Service Providers (CSPs) under a limited nonexclusive, nontransferable Software

Development Tools License Agreement. Crestron product operating system software is

licensed to Crestron dealers, CSPs, and end-users under a separate End-User License

Agreement. Both of these Agreements can be found on the Crestron website at

www.crestron.com/legal/software_license_agreement.

The product warranty can be found at www.crestron.com/warranty.

The specific patents that cover Crestron products are listed at

www.crestron.com/legal/patents.

Certain Crestron products contain open source software. For specific information, visit

www.crestron.com/opensource.

Crestron, the Crestron logo, and Crestron Mercury are either trademarks or registered

trademarks of Crestron Electronics, Inc. in the United States and/or other countries.

HDBaseT is either a trademark or registered trademark of the HDBaseT Alliance in

the United States and/or other countries. HDMI and the HDMI logo are either

trademarks or registered trademarks of HDMI Licensing LLC in the United States

and/or other countries. Other trademarks, registered trademarks, and trade names

may be used in this document to refer to either the entities claiming the marks and

names or their products. Crestron disclaims any proprietary interest in the marks and

names of others. Crestron is not responsible for errors in typography or photography.

Doc ID 8453A

(2053534)

11/14/19

CCS-UC-1-X Quick Start
