Creative IRoar Go Manuel utilisateur

Model No.: MF8225

A USER GUIDE TO

Discover the many features of the Creative iRoar Go!

Discover more ways

to experience your

Creative iRoar Go!

http://www.creative.com/support/iroargo

1 2

Technical speciﬁcation

Bluetooth®

Version: Bluetooth 4.2

Operating Frequency: 2402 - 2480 MHz

DC Output: 5V 1000mA

Energy Saving Information

Power consumption

- Standby/Off : < 0.5 W

- Networked Standby : < 3 W (Bluetooth)

< 3 W (USB)

< 3 W (all network ports activated)

Power Management

- Power consumption < 0.5W after 28 hours inactivity when all network ports are deactivated /

disconnected

- Networked standby within 20 minutes inactivity (Bluetooth, USB)

Activation & deactivation of wireless network port(s)

- To activate, perform Bluetooth device pairing

- To deactivate, disconnect Bluetooth from external device providing the audio source

Power Adapter Information

Model Number: FJ-SW1501600N

Input: 100-240VAC 50/60Hz

Output: 15VDC 1.6A

Operating Temperature range: 0ºC to 45ºC

Water resistance IP ratings: IPX6 (IEC 60529) with port covers closed and tightly sealed.

Supported Bluetooth proﬁles*:

A2DP (Wireless Stereo Bluetooth), AVRCP (Bluetooth Remote Control), HFP (Handsfree proﬁle)

Supported Codec: SBC, AAC

Operating Range: Up to 10 meters, measured in open space.

RF Output Power: < 4 dBm

Walls and structures may affect range of device.

Supports microSD cards of Class 10 and above, up to 32GB in FAT16/FAT32 format

Supports USB ﬂash drives up to 128GB in FAT16/FAT32/exFAT format

Supported audio formats: MP3, FLAC and WAV (16 bit 48Khz PCM)

Support MP3 up to 320kbps.

Support FLAC up to 1.3Mbps.

Recommended external electret microphone impedance: 2.2k ohm

Records audio in MP3 format.

Note: Compliance markings are located on the bottom of this product.

* Refer to your Bluetooth device (notebook¹, PC¹, or mobile device²) manufacturer’s documentation/

website for supported proﬁles.

¹ Compatible with PC (Windows 7/8/8.1/10), Apple Macintoshes (Mac OSX 10.10 and above) equipped

with Bluetooth wireless stereo.

² Compatible with most major brands of Bluetooth A2DP enabled mobile phones.

Compatibility Disclaimer

Wireless performance is dependent on your device’s Bluetooth wireless technology. Refer to your

device manufacturer’s manual. Creative will not be liable for any lost of data or leakages resulting

from the use of these devices.

Product Registration

Registering your product ensures you receive the most appropriate service and product support

available. You can register your product during installation or at http://www.creative.com/register.

Please note that your warranty rights are not dependent on registration.

Safe Removal of Built-in Battery

Detailed instructions on removal of integrated battery can be found at creative.com/support/iRoarGo,

these instructions are meant strictly for independently qualiﬁed professionals.

1 2

Overview

1. Power button / Battery Status Indicator

2. Volume -

3. Volume +

4. Bluetooth®Button / Status Indicator

5. Source Button

6. NFC touchpoint

7. Source Indicator

8. Button / Status Indicator

9. Equalizer Status Indicator

10. Previous Button

11. Next Button

12. Play / Pause Button

13. Record Button / Recording Status Indicator

14. (Record) Play / Pause Button

15. MP3/FLAC Shufﬂe Button / Shufﬂe Playback

Indicator

16. MicroSD Slot

17. Micro USB Connector

18. DC Out (USB 1.0A) / USB Flash drive Connector

19. Aux-In / External Microphone In

20. 15V DC In

21. Microphone

Front Top

2 4

1 3 5 76

817

16 18

IPX6 (IEC 60529)

3 4

Charging your speaker - Power adapter

The dual-purpose battery powers

your iRoar Go and also charges

your smartphone!

Here’s how you do it!

Simply connect a USB cable

to the iRoar Go’s USB DC

Out and the other end to

your smartphone when the

speaker is turned on.

Power Adapter

Battery Life: Up to 12 hours (Actual battery life may vary with use,

settings and environmental conditions)

Use only bundled adaptor

The Lithium-ion battery life may suffer when it is constantly fully

depleted or overexerted at low voltage. It is a good practice to

keep battery well charged.

3 Hours

Assemblng the

Power Adapter

Adapter Model No.: FJ-SW1501600N

Removing the

Power Adapter

3 4

Charging your speaker - Battery status indication

Power Saving

For better user connectivity experience, the iRoar Go automatically enter

auto standby mode after approximately 28 hours of inactivity when the

power adapter is attached via a main outlet to the speaker. This power

saving mode can disabled via the iOS or Android mobile app if desired.

Note: The speaker automatically powers down after 15 minutes when

battery operated if there is no Bluetooth or USB connection, and no

audio recording/playback. This feature helps to protect the internal

battery and cannot be disabled.

Whenever the speaker is connected to the power adapter, the battery status

indicator will continually blink to indicate charging, or be continually lit to

indicate full charge.

Battery full Green

Battery Half Full Orange

Battery low Red

Battery charging Blinking

green

Battery Power Status indication

5 6

Source selection

The Source Indicator lights up to show which source is currently

selected for listening, and you could press the source button to

manually switch between available sources

* If a USB Flash drive and a

Computer USB audio connection

are both present, the USB audio

connection will be given priority.

To hear audio playback from

the USB Flash Drive, please

disconnect the USB connection

to your computer

Source Indicator When?

Waiting for Bluetooth pairing

Waiting for Bluetooth connection

A mobile device is brought close to NFC touchpoint

Recording from internal Mic

Playing back recording

Playing back music from SD card

Connected to computer*

USB Flash drive is inserted*

Aux in cable is inserted

Mic adapter is inserted

Speaker is turned off

USB

Aux

None

Here’s how you do it!

5 6

The iRoar Go connects

to Bluetooth devices.

NFC technology makes

connecting even easier

– just tap and play!

Here’s how you do it!

1A. One-touch pairing with NFC

2Start playback on your

connected device.

B. Manual Bluetooth pairing

(i) Press and hold until the

Bluetooth status LED blinks

white rapidly.

(ii) Select Creative iRoar Go on

your device.

Turn on NFC on your NFC-enabled

device and tap your device on the

NFC logo to connect.

To disconnect, tap your device on

the NFC logo again.

Connecting your speakers - Bluetooth / NFC

The iRoar Go lets you stream music wirelessly.

Powered ON but not

connected to any

Bluetooth devices

Bluetooth Pairing

Mode, waiting for

device to connect

Connected to a

Bluetooth device

Green LED

stays lit

White LED

blinking rapidly

White LED

stays lit

Bluetooth

status LED

Status

7 8

Gain full control of your iRoar Go and enhances your listening experience

with professionally tuned presets and customizable sound controls.

Search for “Sound Blaster Connect” on

the Apple®App StoreTM or Google Play®

Download Sound Blaster Connect for

Mac or PC from

www.creative.com/support/iroargo

iRoar Go apps

For the complete iRoar Go experience

7 8

To toggle between modes, simply just press the button.

Toggles from ON-> Equalizer Mode ->OFF

Here’s how you do it!

Audio settings

Understanding Roar, Custom Audio proﬁles

and EQ

The iRoar Go is carefully tuned to produce detailed, dynamic and

beautifully natural sound that belies its compact size. Even at high

listening levels, the sound remains well balanced and clean with

minimal compression [NOT common for battery operated portables]

ROAR mode takes this great sound further to a whole new level. Select

ROAR mode to instantly enhance the loudness, depth and spaciousness

of any music. Updated for the iRoar Go, ROAR mode now incorporates

Terabass processing and intelligently compensates for the human ear’s

loss of perceived bass and treble details during low playback level as

well – dramatically improving the fullness and clarity of your music

even at whisper low volumes.

Equalizer mode. Choose from a variety of expertly tuned presets to suit

your listening environment and preference, or use the equalizer option

to ﬁne tune your Roar’s sound, Equalizer mode allows you to make the

sound of the iRoar Go uniquely yours.

To explore the endless possibilities of Equalizer mode, download the

free Android or iOS mobile app now!

9 10

Connect an external microphone to your iRoar Go to

transform it to a portable public address (P.A.) system

The iRoar Go includes a built in microphone preampliﬁer with limiter

circuitry to help prevent distortion. Compatible with most electret

condenser and dynamic type microphones (cardioid / unidirectional

type microphone are strongly recommended) .

1Connect an external

microphone to the mic adapter

2Plug the adapter into the Aux-in

socket

3Adjust the volume and the

system is ready to use

Here’s how you do it!

If you encounter howling noise

(feedback), try reducing the speaker

volume, facing the microphone away

from the speaker or increasing the

distance from the microphone to the

speaker. Do not cover the microphone

with your hand, as this will increase

the possibility and severity of

feedback.

Understanding the microphone input
