Creative Sound Blaster EVO Manuel utilisateur

User’s Guide

Model No.: GH0260

Congratulations! 1

Congratulations!

Thank you for choosing the Sound Blaster EVO USB entertainment headset. Connect it to your

computer and you are about to experience the legendary audio quality of Sound Blaster.

The EVOUSB enhances the quality of all your audio content, even from online streaming sources such

as YouTube. Its beamforming dual microphone array guarantees crystal clear communication in any

environment. Beyond that, it allows you to connect to your mobile devices and enjoy high quality audio

on the go!

Package Checklist

Your Sound Blaster EVO USB package comes with the following:

lThe Sound Blaster EVO USB

lMicroUSB-to-USB cable - Length: 1.8m (5.91ft)

l4-pole analog cable - Length: 1.2m (3.94ft)

lQuick Start leaflet

Minimum System Requirements

lIntel Core™2 Duo processor 2.2 GHz, AMD Athlon 64x2 Dual Core or equivalent processor

lMicrosoft® Windows® 8 64-bit or 32-bit, Windows 7 64-bit or 32-bit, Windows Vista 64-bit or

32-bit; Macintosh OS X 10.5.8 and above

l1GB RAM

lPowered USB 2.0/3.0 port

Note:

Due to programming changes, the recommended system requirements for the software and

applications may change over time.

Congratulations! 2

More Help

For the latest news and products for the Sound Blaster, please visit www.soundblaster.com. The site

also includes information on making purchases, technical help and the latest software updates.

Alternatively, click on the Resources icon at bottom of Sound Blaster EVO Control Panel to find out

more about Sound Blaster and your product.

Using Creative Software AutoUpdate

Locating, downloading and installing updates for your Creative products is now simpler and faster with

the web-based Creative Software AutoUpdate system.

When you connect to Creative Software AutoUpdate via the Internet, the website will analyze your

computer system to determine your operating system, language and which Creative products are

connected to your system.

When this analysis is completed, you will then be given a list of only the most relevant software

updates for your connected products. The files can then be retrieved and installed.

To learn more about the Creative Software AutoUpdate, please visit www.soundblaster.com/support.

Notes:

First-time users of Creative Software AutoUpdate may be prompted to authorize the download

of a browser component required for system analysis. Check to ensure that this content is

signed by Creative Labs, Inc., then click the Yes button.

Please ensure that all your Creative products are connected and installed on the same computer

running Creative Software AutoUpdate.

Overview 3

Overview

1 - Adjustable Headband

2 - Volume Control

3 - Multifunction Button

(for calls and playback)

4 - 4-Pole Analog Jack

5 - MicroUSB Port

Overview 4

Flexible Connection Options

4-pole Analog Cable to your Smart Devices

USB Cable to your PC/Mac

Splitter Cable* to your Soundcard

* Cable not included

Using Your Sound Blaster EVO USB 5

Using Your Sound Blaster EVO USB

Set up your headset in three simple steps:

1. Connect your headset

2. Install the software

3. Use it

Step 1: Connect your headset

Connecting to a Computer (USBDigital Mode)

Connect your headset to a computer using the MicroUSB to USB cable. The LED will light up in red once

the headset is properly connected. Experience the power of Sound Blaster with all your games and

calls, on your PC and Mac.

Note:

The Sound Blaster audio processing is only available when the headset is connected via

USBDigital Mode.

Set the default audio device (for Mac only)

1. Go to System Preferences and click Sound.

2. Select Sound Blaster EVO USB in both the Output and Input tabs.

Using Your Sound Blaster EVO USB 6

Connecting to a Mobile Device(4-Pole Analog Mode)

Enjoy the power of the Sound Blaster EVO USB entertainment headset on-the-go with portable smart

devices including iPhones, Android phones and tablets. Simply connect the headset using the 4-pole to

4-pole analog cable.

Note:

Only the microphone and the Multifunction button function in 4-Pole Analog Mode.

If both the analog cable and the USB cable are connected to the same device (such as on a

laptop), the USB cable connection is prioritized unless manually configured otherwise.

Using Your Sound Blaster EVO USB 7

Step 2 :Install the Software

Your headset is now ready for use. However, you can enhance your audio and voice experience via an

optional software package that can be downloaded and installed into your PC. We recommend that you

download and install this software to make full use of all the features that your headset is equipped

with.

Note:

Please ensure that your headset is plugged into your computer before downloading and installing

the software.

For Windows

1. Using a standard web browser, visit www.soundblaster.com/downloads/EVOUSB/

2. Locate the software package for the Windows operating system for your product.

3. Download this package into your local hard disk.

4. Locate and launch the software package.

5. Follow the on-screen instructions to complete the installation.

6. When prompted, restart your computer.

7. Launch the application by clicking Start > Programs or All Programs > Creative >Sound

Blaster EVO > Sound Blaster EVO Control Panel.

For Mac

1. Using your web browser, visit www.soundblaster.com/downloads/EVOUSB/

2. Locate the software package for the Mac OS for your product.

3. Download this package into your local hard disk.

4. Double-click the downloaded file to uncompress it.

5. Double-click the uncompressed DMG file.

6. Double-click the Install icon and follow the subsequent on-screen instructions to complete the

installation.

7. Launch the application from the Applications > Creative >Sound Blaster EVO > Sound

Blaster EVO Control Panel.

For more details on the software and the various features it has to offer, please refer to Using the

Software.

Using Your Sound Blaster EVO USB 8

Step 3 : Use It

Wearing the Headset

Adjust the headband so that the headset rests lightly on your head. Do not tighten excessively.

Adjusting the Volume

In USBdigital mode, the Volume Control on the headset cup can be

used to adjust your headset volume to a comfortable level. You can

also adjust the volume via the software or the built-in volume

settings on your computer.

CAUTION:

Do not listen to audio on your headset at high volumes for prolonged

periods of time to avoid impairing your hearing.

Using Your Sound Blaster EVO USB 9

Usage Scenarios

Playing Music or Movies

Connect your Sound Blaster EVO USB to your computer via USB to enjoy the legendary Sound Blaster

audio quality. Alternatively, you may now connect it to a portable entertainment device such as mobile

phones and tablets and enjoy clear audio quality on the go.

The SBX Dialog Plus feature brings out the dialog in movies for maximum clarity, while the SBX Bass

fills extends the low frequency tones and gives the extra impact for a dramatically improved sound

experience. The SBX Surround enhances your movie or music playback by producing virtual speakers

around, above and below you, creating an immersive audio experience.

1. Play or Pause Music

Tap on the Multifunction button once to play music and again to pause it. Similarly, tap on the same

button to resume.

2. Adjusting Volume

Adjust the volume control to increase or decrease the music level.

Note: Not applicable in 4-Pole Analog Mode.
