Creative Sound Blaster Jam Manuel utilisateur

Introduction

Thank you for choosing the Sound Blaster JAM(GH0300)Bluetooth®headset! The ultra light weight

headset offers you hands-free communication and audio streaming when connected to your Bluetooth

device. With all necessary controls easily accessible on one earcup, it also provides you with one-click

audio enhancements.

Package Checklist

Your Sound Blaster JAM package comes with the following:

lThe Sound Blaster JAM headset

l1m USB cable

lQuick Start leaflet

lWarranty leaflet

System Requirements

For Windows®OS

lIntel® Core™2 Duo or AMD equivalent processor, 2.8 GHz or faster recommended

lMicrosoft®Windows 8.1 64-bit or 32-bit, Windows 8 64-bit or 32-bit, Windows 7 64-bit or 32-bit,

Windows Vista®64-bit or 32-bit

l1 GBRAM

l600 MB of free hard disk space

lPowered USB 2.0 / USB 3.0 port

For Mac®OS

lIntel® Core™2 Duo, 2.8 GHz or faster recommended

lMac OS X® 10.6.8 or higher

l1 GB RAM

l600 MB of free hard disk space

lPowered USB 2.0 / USB 3.0 port

For iOS device

liPhone®/ iPad®running iOS 5.1.1 or higher for Bluetooth

For Android device

lPhone / tablet running Android 2.3 or higher for Bluetooth

Registering Your Product

Registering your product ensures you receive the most appropriate service and product support

available. You can register your product during installation or at register.creative.com. Please note that

your warranty rights are not dependent on registration.

Introduction 1

More Help

For the latest news and products for the Sound Blaster, please visit www.soundblaster.com. The site

also includes information on making purchases, technical help and the latest software updates.

Using Creative Software AutoUpdate

Locating, downloading and installing updates for your Creative products is now simpler and faster with

the web-based Creative Software AutoUpdate system.

When you connect to Creative Software AutoUpdate via the Internet, the website will analyze your

computer system to determine your operating system, language and which Creative products are

connected to your system.

When this analysis is completed, you will then be given a list of only the most relevant software updates

for your connected products. The files can then be retrieved and installed.

To learn more about the Creative Software AutoUpdate, please visit support.soundblaster.com.

Note:

First-time users of Creative Software AutoUpdate may be prompted to authorize the download of a

browser component required for system analysis. Check to ensure that this content is signed by

Creative Labs, Inc., then click the Yes button.

Please ensure that all your Creative products are connected and installed on the same computer

running Creative Software AutoUpdate.

Introduction 2

Product Overview

(1) Multifunction button /

NFC receptor

(2) Volume +

(3) Volume -

(4) LED indicator

(5) USBport

(6) Bass Boost button

(7) Microphone

Product Overview 3

Setting Up Your Headset

Set up your headset in three simple steps:

1. Charge your headset

2. Connect your headset

3. Install the software

Step 1:Charge Your Headset

You are recommended to charge your headset before it is used for the first time. Connect your headset

to your computer using the USB cable, or connect it to a power supply via an adapter (available

separately). The LED will light in red when charging.

Using Your Headset While Charging

During subsequent charges, you can use your headset while it charges. The LED will light in red while

charging and return to its last status when fully charged.

You can also check the status of the battery via the battery indicator at the top right corner of the Sound

Blaster JAM Control Panel. Please refer to Using the Software for details.

Note:

The low battery tone will start beeping to inform users of its status 15 minutes before the headset is

completely powered off.

Setting Up Your Headset 4

Step 2:Connect Your Headset

Turn on your Sound Blaster JAM by pressing the Multifunction button.

lTurn ON: Press and hold 2 seconds

lTurn OFF:Press and hold 4 seconds

Bluetooth Pairing

1. Activate pairing mode on the headset

Turn on your headset. If the headset has not been paired with any devices previously, it will go into

Bluetooth discoverable mode. Otherwise, it will be automatically paired to previously paired devices.

The Bluetooth discoverable mode is only available for 60 seconds after the headset is turned on. To

activate Bluetooth again, press the Multifunction button for 2 seconds. The LED will begin to blink

quickly in blue for 60 seconds while waiting to be connected.

2. Activate pairing mode on your device

Activate Bluetooth on your smart device. From the list of discovered Bluetooth devices, select "Sound

Blaster JAM".

Note:

Bluetooth pairing between these devices may vary depending upon the model type. Consult your

device’s manual on how to pair.

Setting Up Your Headset 5

3. Pairing success

When the headset and the Bluetooth device are paired, the LED will flash slowly in blue to indicate

successful pairing before returning to its default / last status.

Pairing Multiple Devices

The Sound Blaster JAM is able to pair up to two smart devices at the same time! To have the second

device paired, repeat steps 1 to 3. If a user wishes to pair the headset with a third smart device, one of

the two devices that are currently paired with the headset has to be unpaired.

Note:

Only one of the devices is able to play music at one time. The last paired smart device takes

precedence over the other device.

When there's an incoming call, the call takes precedence over audio playback -- music fades out and

the ringtone will be heard.

NFCPairing

Bring your NFC-enabled device close (20mm) to the NFC zone / Multifunction button. The LED will

blink slowly in blue and a 3-note tone will be heard to indicate successful pairing. Play music from your

device and experience superb audio realism and stunning 3D surround effects.

If you wish to unpair the devices, simply tap your NFC device on the headset again.

Setting Up Your Headset 6

USBConnection

Connect your headset to a computer using the USB cable. Turn it on by pressing and holding the

Multifunction button for 2 seconds. The LED will light in green when it is successfully turned on. You

can stream audio from your computer through the USB connection.

Note:

Profile setting adjustments via Sound Blaster JAM Control Panel is only available in USB Digital Mode.

Refer to Using the Software for more information.

Set the default audio device (Mac OS ONLY)

1. Go to System Preferences and click Sound.

2. Select Sound Blaster JAM in both the Output and Input tabs.

Setting Up Your Headset 7

Step 3:Install the Software

Your headset is now ready for use. However, you can enhance your audio and voice experience via an

optional software package that can be downloaded and installed into your PC. We recommend that you

download and install this software to make full use of all the features that your headset is equipped

with.

Note:

Ensure that your headset is turned on and plugged into your computer before downloading and

installing the software.

For Windows

1. Using a standard web browser, visit www.soundblaster.com and locate the software package for the

Windows operating system for your product.

2. Download this package into your local hard disk.

3. Locate and launch the software package.

4. Follow the on-screen instructions to complete the installation.

5. When prompted, restart your computer.

6. Launch the application by clicking Start > Programs or All Programs > Creative > Sound

Blaster JAM > Sound Blaster JAM Control Panel.

For Mac

1. Using your web browser, visit www.soundblaster.com and locate the software package for the Mac

OS for your product.

2. Download this package into your local hard disk.

3. Double-click the downloaded file to decompress it.

4. Double-click the uncompressed DMG file.

5. Double-click the Install icon and follow the subsequent on-screen instructions to complete the

installation.

6. Launch the Sound Blaster JAM Control Panel from the Applications > Creative > Sound

Blaster JAM folder.

For more details on the software and the various features it has to offer, refer to Using the Software.

Setting Up Your Headset 8

Using Your Headset

Wearing the Headset

Adjust the headband so that the headset rests lightly on your head. Do not tighten excessively.

Adjusting the Volume

The Volume Control on the headset cup can be used to adjust your headset volume to a comfortable

level. You can also adjust the volume via the software or the built-in volume settings on your computer.

CAUTION:

Do not listen to audio on your headset at high volumes for prolonged periods of time to avoid

impairing your hearing.

Using Your Headset 9

Playing Music or Movies

Connect your Sound Blaster JAM wirelessly to a portable entertainment device such as mobile phones

and tablets and enjoy clear audio quality on the go! Alternatively, you may connect it to your computer

via USB to enjoy the legendary Sound Blaster audio quality.

Play, Pause or Resume Music

Tap on the Multifunction button once to play music and again to pause it. Similarly, tap on the same

button to resume.

Adjusting Volume

When listening to music, you may adjust the volume control to increase or decrease the music level.

Next Track or Previous Track

Press and hold the Volume + or Volume - button to skip to the next or previous track.

Note:

You can connect Sound Blaster JAM to a mobile device wirelessly and to your computer via USB at the

same time, and toggle between them.

Using Your Headset 10
