Warning

These installation instructions are valid with the above Ametrix styles.

Sheet 1 of 2

Visor and Non-Visor

that all sources of power are turned off. All

performed by a certified electrician.

: Before startin any work ensure

work must meet local/national codes and be

Do not

mount fixtures vertically.

Installation Instructions

Vault C-Scroll

Small, OUTDOOR

P1R

(Pendant, 1-way, Remote ballast

ADY071467 REV B(ECN80481)

with canopy.

(2x)

set screw

(2x)

set screw

#10-32 x3/8"

4. Secure canopy usin both #10-32 x3/8" set screws.

To seal door, refer to torque sequence supplementry pa e.

1. After securin fixture to ceilin , attach appropriate wires

and ensure all connections are properly matched.

2. Push wire connections into j-box and cover mountin plate

#6-32 x1/2"

#6-32 x5/8"

set screw

Securing fixture to ceiling

indicator

(2x)

When fixture head is rotated to desired an le, reti hten end

screws to secure the position.

#10-32 x5/8"

End screw

Fixture head

de rees

1. To aim fixture, loosen both #10-32 x5/8" end screws. When

both indicators are lined up, the slope of the lens face is 40-

de rees. Each subsequent notch is an additional +/- 10-

Yoke arm

indicator

(x4)

(2x)

Set screw

Use

J-box

Canopy

mountin plate.

Aiming the fixture

#8-32 x 3/8"

Usin appropriate fasteners, secure fixture to ceilin .

(by others)

Run wires from pendant and j-box throu h wirin holes in

(by others)

additional bracing around J-box to support fixture.

1. Usin both #10-32 x5/8" end screws, secure fixture head to

yoke on pendant and run wire throu h compression fittin

and into pendant.

2. Remove both #10-32 x3/8" set screws and allow canopy to

slide down pendant.

1/4" fasteners

Use additional bracing

around J-box to support

fixture.

(by others)

1/4" fasteners

J-box

#8-32 x3/8"

Set screw

#6-32 x1/2"

Set screw

Canopy

(2x)

#6-32 x 5/8"

(by others)

End screw

Set screw

Exploded view and part call-out

Wiring & sealing the fixture

(2x)

#10-32 x5/8"

Compression

fittin

Warning

Visor and Non-Visor

Sheet 2 of 2

Installation Instructions

Vault w/ visor C-Scroll w/ visor Roundel w/ visor

(lamps provided by others)

Lamping Size Chart

These installation instructions are valid with the above Ametrix styles

: Before startin any work ensure

Mounting Plate Dimensions In [mm]

that all sources of power are turned off. All

work must meet local/national codes and be

performed by a certified electrician. Do not

mount fixtures vertically.

Small, OUTDOOR

P1R

(Pendant, 1-way, Remote ballast

ADY071467 REV B(ECN80481)

Use only GE or Sylvania

CFL lamps

Side View Top View

16 "

11.42

on order

Length dependant

127

12.70

101.60

25.40

1" 2"

25.40

6.35

(4x)

12.70

FIXTURE SIZE

(inches/ mm) WATTAGE # OF

LAMPS LAMP TYPE LAMP DESCRIPTION

3/4

/ 273.05 39 W 1 T6 Ceramic Metal Halide

3/4

/ 323.85 70 W 1 T6 Ceramic Metal Halide

3/4

/ 323.85 150 W 1 T6 Ceramic Metal Halide

3/4

/ 323.85 26 W 1 4-Pin Triple

Tube Compact Fluorescent

3/4

/ 323.85 32 W 1 4-Pin Triple

Tube Compact Fluorescent

3/4

/ 323.85 42 W 1 4-Pin Triple

Tube Compact Fluorescent

3/4

/ 273.05 100 W 1 T4 Halogen (Single Ended)

3/4

/ 323.85 150 W 1 T4 Halogen (Single Ended)

3/4

/ 323.85 250 W 1 T4 Halogen (Single Ended)

LAMP

(not to scale)
