RECESSED DOWNLIGHTING Incandescent

COOPER LIGHTING

ALL-PRO™

ET700 ET700R

ET700

ET700R

ERT717

High Gloss Appliance White

Trim with Black Bafﬂe

ERT717WHT

High Gloss Appliance White Trim

with White Bafﬂe

ERT717

Large Aperture Plastic Baffle

• Coil spring retention

• Lamps:

ET700

ET700R

75W A19, 75W PAR30L,

75W PAR30, 85W BR30,

100W R30, 120W BR40,

150W R40

65W BR30, 75W PAR30L,

150W R40

ET700

ET700R

75W R30, 75W PAR30,

75W PAR30L, 85W BR30

75W R30, 75W PAR30L,

85W BR30

ET700

ET700R

150W PAR30, 150W R40

75W R30, 75W PAR30,

75W PAR30L

ET700

ET700R

40W A19, 65W BR30, 75W

PAR30, 75W PAR30L

ET700 65W BR30, 75W R30, 75W

PAR30

150W R40

ET700

ET700R

65W BR30, 75W R30, 75W

PAR30

65W R30, 75W R30, 75W

PAR30, 75W PAR30L

ERT713L

High Gloss Appliance White

Trim with Black Bafﬂe

ERT713LTS

High Gloss Appliance White Trim

with Black Bafﬂe and Torsion

Spring Construction

ERT713L - Black Metal Baffle

• Provides deeper lamp regression for

BR lamps

• ERT713LTS - Torsion spring retention

• ET713L - Friction clip retention

• Lamps:

ERT714

High Gloss Appliance White

Trim with Black Bafﬂe

ERT714WHT

High Gloss Appliance White Trim

with White Bafﬂe

ERT714 - Plastic Baffle

• Coil spring retention

• Lamps:

ERT704

High Gloss Appliance White Trim

with White Eyeball

ERT704PB

Polished Brass Trim with

Polished Brass Eyeball

ERT704

Eyeball

• Torsion springs pull trim tight to ceiling

• Lamps:

ERT711

High Gloss Appliance White Trim

and Eyeball with Black Bafﬂe

ERT711

Regressed Eyeball

• Lamps:

ERT706

High Gloss Appliance White Trim

ERT706

Open

• Coil spring retention

• Lamps:

Height:

2-1/4” [57mm]

OD:

8” [203mm]

Height:

2-3/4” [70mm]

OD:

8” [203mm]

Aperture:

3 15/16” [100mm]

OD:

8” [203mm]

Height:

3” [76mm]

OD:

8” [203mm]

Height:

5-3/8” [136mm]

OD:

7-1/4”[184mm]

ERT713LTS ERT713L

trim trim

ERT716

High Gloss Appliance White

Trim with White Bafﬂe

ERT716 - Shallow Metal Baffle

• Socket Supporting trim

• Friction clip retention

• Lamps:

trim

Height:

4-1/4” [108mm]

OD:

8” [203mm]

Aperture:

3-7/8” [98mm]

OD:

8” [203mm]

266

RECESSED DOWNLIGHTING Incandescent

COOPER LIGHTING

ALL-PRO™

ET2700

ET2700R

ET2700

ET2700R

75W PAR30, 75W PAR30L,

85W BR30, 100W R30

65W BR30, 75W R30,

75W PAR30, 75W PAR30L

ET2700

ET2700R

65W BR30, 75W R30,

75W PAR30, 75W PAR30L

ET2700

ET2700R

40W A19, 65W BR30,

75W PAR30, 75W

PAR30L,

65W BR30, 75W R30, 75W

PAR30, 75W PAR30L,

85W BR30

ET2700

ET2700R

75W R30, 75W PAR30,

85W BR30

75W PAR30, 75W PAR30L,

85W BR30

ERT710G

High Gloss Appliance White Trim

with Gold Reﬂector

ERT710

High Gloss Appliance White

Trim with Clear Specular

Reﬂector

ERT710 - Specular Reflector

• Coil Spring retention

• Lamps:

ERT707

High Gloss Appliance White

Trim with Black Bafﬂe

ERT707WHT

High Gloss Appliance White Trim

with White Bafﬂe

ERT707 - Metal Baffle

• Coil spring retention

• Lamps:

Height:

2-7/8” [73mm]

OD:

7-1/4”[184mm]

Height:

2-7/8” [73mm]

OD:

8”[203mm]

ERT714

High Gloss Appliance White

Trim with Black Bafﬂe

ERT714WHT

High Gloss Appliance White Trim

with White Bafﬂe

ERT714 - Plastic Baffle

• Coil spring retention

• Lamps: Height:

2-1/4” [57mm]

OD:

8” [203mm]

ERT704

High Gloss Appliance White Trim

with White Eyeball

ERT704PB

Polished Brass Trim with

Polished Brass Eyeball

ERT704

Eyeball

• Torsion springs pull trim tight to ceiling

• Lamps:

Aperture:

3 15/16” [100mm]

OD:

8” [203mm]

ERT716

High Gloss Appliance White

Trim with White Bafﬂe

ERT716 - Shallow Metal Baffle

• Socket Supporting trim

• Friction clip retention

• Lamps:

trim

Height:

4-1/4” [108mm]

OD:

8” [203mm]

ET2700 ET2700R

ERT706

High Gloss Appliance White Trim

ERT706

Open

• Coil spring retention

• Lamps:

Aperture:

3-7/8” [98mm]

OD:

8” [203mm]

ET2700

ET2700R

65W BR30, 75W R30,

75W PAR30, 75W PAR30L
