Continental Refrigerator 1RF Manuel utilisateur

OVER/UNDER

DUAL TEMP

REFRIGERATOR/FREEZER

Standard Features

• Modern, State-of-the-Art Styling

• 3" Non-CFC Polyurethane Foam Insulation

• Performance Rated Refrigeration Systems

Utilizing Non-CFC Refrigerants

• Chrome Plated Flow Line Handles

• Cam-Action Lift-Off Hinges

• Self-Closing Doors

• Automatic Interior Lighting

• Magnetic Snap-In Door Gasket

• Cylinder Lock In Each Door

• Automatic Electric Condensate Evaporator

• 5" Casters

• Heavy-Duty, Epoxy-Coated Steel Shelves

• External Dial Thermometers

• Automatic Electric Defrost on Freezer Section

Standard (S/S Front, Aluminum Ends & Interior)

Suffix SA (S/S Exterior, Aluminum Interior)

Suffix SS (S/S Exterior & Interior)

Models Available

•1RF

•1RFE

•1RFX

Optional Features & Accessories

• Legs • Stainless Steel Case

• Pan Slide Assemblies Back

• Stainless Steel Shelves • Digital Thermometer

• Rehinging of Doors • Remote

• Glass Doors

Utilizing Environmentally Safe, CFC-free R-134a & R-404A Refrigerant

RFEX706

A Division of National Refrigeration & A/C Products, Inc.

539 Dunksferry Road Bensalem, PA 19020

(800) 523-7138 Fax: (215) 244-9579

www.continentalrefrigerator.com

SIDE VIEW 1RF FRONT VIEW

1RFE FRONT VIEW

1RF 1RFX 1RFE

Reach-In Reach-In Reach-In

CHARACTERISTICS

DIMENSIONAL DATA

Net Capacity (cu. ft.) Refrigerator 10 16 11

Net Capacity (cu.ft.) Freezer 10 16 11

Width, Overall (in.) 26 361/4281/2

Depth, Overall (Incl. Hdls.) (in.) 351/2351/2351/2

Depth (Less Door(s) (in.) 32 32 32

Depth (Doors(s) Open 90°) (in.) 551/266 58

Clear Door Width (in.) 193/8295/8217/8

Clear Half-Door Height (in.) 271/2271/2271/2

Height, Overall (Incl. 5" Casters)(in.) 821/4821/4821/4

Half Doors 2 2 2

Shelves 4 4 4

Shelf Area (sq. ft.) 10.2 24.4 10.2

Tray Slide Capacity (Half) 11ea. 11ea. 11ea.

REFRIGERATION DATA

Condensing Unit Size (H.P.) Ref. 1/51/41/5

Condensing Unit Size (H.P.) Frz. 1/41/31/4

Capacity (BTU/hr)*Ref. 1725 1940 1725

Capacity (BTU/hr)*Frz. 1250 1590 1250

ELECTRICAL DATA

Cabinet Specifications

115/60/1 115/60/1 115/60/1

Feed Wires (Incl. Ground) 3/3 3/3 3/3

Condensing Unit Specs.

115/60/1 115/60/1 115/60/1

Total Amperes 5.3/5.4 6.9/7.6 5.3/5.4

Cabinet Amperes .9/.9 1.6/1.6 .9/.9

Defrost Amperes 5.2 6.5 5.2

Power Supply Cord yes/yes yes/yes yes/yes

SHIPPING DATA

Height – crated (in.) 851/2851/2851/2

Width – crated (in.) 315/842 315/8

Depth – crated (in.) 42 42 42

Volume – crated (cu.ft.) 66 87 66

Weight Std – crated (lbs.) 420 440 420

Weight SS – crated (lbs.) 480 500 480

Weight Std – uncrated (lbs.) 320 340 320

Weight SS – uncrated (lbs.) 380 400 380

*Rating @ +25°F Evaporator, 90°Ambient (Refrigerator)

*Rating @ -15°F Evaporator, 90°Ambient (Freezer)

Note: All specifications subject to change without notice

Note: If the cabinet is located directly against wall and/or under low ceiling, a minimum

clearance of 2" is required.

361/4"

1RFX FRONT VIEW

Over / Under Dual Temp Refrigerator / Freezer
