Continental Refrigerator DL1R-SS Manuel utilisateur

REACH-IN

REFRIGERATORS

Utilizing Environmentally Safe, CFC-free R-134a Refrigerant

DL1R-SS

DL2R-SS

DL3R-SS

Standard Features

•Modern, State-of-the-Art Styling

•Performance Rated “Plug” Refrigeration

System Utilizing Environmentally Safe R-134a

Refrigerant

•3" Non-CFC Polyurethane Foam Insulation

•Chrome-Plated Flow Line Handles

•Cam-Action Lift-Off Hinges

•Self-Closing Doors

•Magnetic Snap-In Door Gasket

•Cylinder Lock in Each Door

•Automatic Hot Gas Condensate Evaporator

•Adjustable 6" Stainless Steel Legs

•Heavy-Duty, Epoxy-Coated SteeL Shelves

•External Digital Thermometer

Models Available

• Half Door • Pass-Thru

• Remote • Consult Factory

Standard (S/S Front, Aluminum Ends & Interior)

Suffix SA (S/S Exterior, Aluminum Interior)

Suffix SS (S/S Exterior & Interior)

RREEFFRRIIGGEERRAATTIIOONNSSYYSSTTEEMM

A “performance rated”, air-cooled, hermetically sealed,

capillary-type refrigeration system is installed on the top

of each refrigerator. Plasticized fin coil and air circula-

tion fans are contained within a concealed “plug”-type

insulated housing, readily accessible on top of the cab-

inet and separate from the food zone to increase food

storage capacity. The entire “plug” system is fully

charged with environmentally safe R-134a refrigerant

and mounted on a sturdy steel, rail-type base which can

be easily removed if freezer conversion is desired.

Refrigerators are designed to maintain 38-40 degrees

Fahrenheit (3 to 5 degrees Centigrade) while operating

with an unrestricted air supply in a maximum ambient

temperature of 100 degrees Fahrenheit. All conden-

sate water is evaporated by an automatic, non-electric,

corrosion-resistant condensate evaporator. A strict

quality-assurance team inspects all materials and com-

ponents to certify that each model conforms to the most

exacting standards. All models are factory perform-

ance-tested for a minimum of 16 hours prior to crating.

CCAABBIINNEETTCCOONNSSTTRRUUCCTTIIOONN

All materials are of top quality, assembled to con-

form with strict quality-assurance requirements.

The cabinet front and doors are constructed of

heavy-gauge polished stainless steel for durability.

All cabinet joints and seams are sealed vapor-tight.

Case is of all metal, welded construction and inter-

nally supported and braced for a rigid unit con-

struction. Cabinet design eliminated overlapping

panels with raw edges. Cabinet body and doors

are insulated with non-CFC, foamed-in-place

polyurethane foam with an average thickness of 3

inches to ensure increased energy efficiency. Full-

length louvered air grille located above the doors

allows equal air circulation to the condensing unit.

Easily removable, low-wattage, anti-sweat door

heaters concealed by a non-metallic, non-conduc-

tive, high-impact thermal breaker strip eliminate

condensate build-up on the cabinet front.

Automatic interior lighting is controlled by door

openings. Cabinets are equipped with 6 inch

adjustable stainless steel legs.

SSHHEELLVVIINNGG

Shelves are designed for heavy-duty use with

.306" diameter frame and brace members and

.140" diameter fill wires spaced 3/4" apart.

Shelves are welded steel and epoxy-coated

for a durable, long, rust-free service life.

Adjustments are in 1/2 inch increments and a

wide door opening allows the use of a a vari-

ety of optional pan and tray slide types.

DDOOOORRCCOONNSSTTRRUUCCTTIIOONN

Door shells are constructed of heavy-gauge

stainless steel and are internally braced and

urethane-foam-insulated for rigidity. Door cor-

ners are of welded construction and polished.

Replaceable snap-in door gaskets are self-

adjusting, heavy-duty, magnetic type. Door

handles and hinges are chrome-plated and

non-corrosive. Doors are provided with built-

in cylinder locks which are keyed alike.

Hinges are cam-action, lift-off type featuring

positive safety stop at 120 degrees.

DLREF305

REFRIGERATORS

CHARACTERISTICS Reach-In Pass-Thru Reach-In Pass-Thru Reach-In Pass-Thru

DIMENSIONAL DATA

Net Capacity (cu. ft.) 21 21 50 50 72 72

Width, Overall (in.) 26 26 52 52 78 78

Depth, Overall (Incl. Hdls.) (in.) 351/239 351/239 351/239

Depth (Less Door(s)) (in.) 32 32 32 32 32 32

Depth (Doors(s) Open 90°) (in.) 551/279 551/279 551/279

Clear Door Width (in.) 193/8193/8193/8193/8193/8193/8

Clear Full-Door Height (in.) 585/8585/8585/8585/8585/8585/8

Clear Half-Door Height (in.) 271/2271/2271/2271/2271/2271/2

Height, Overall (Inc. 6" Legs)(in.) 831/4831/4831/4831/4831/4831/4

No. of Full Door(s) 1 2 2 4 3 6

No. of Half Door(s) 2 4 4 8 6 12

No. of Shelves 3 3 6 6 9 9

Shelf Area (sq. ft.) 20.4 20.4 40.8 40.8 61.2 61.2

Tray Slide Capacity (Half) 12 ea. 12 ea. 12 ea. 12 ea. 12 ea. 12 ea.

Tray Slide Capacity (Full) 25 ea. 25 ea. 25 ea. 25 ea 25 ea 25 ea

REFRIGERATION DATA

Condensing Unit Size (H.P.) 1/41/41/31/31/21/2

Capacity (BTU/hr)** 1940 1940 2560 2560 4010 4010

ELECTRICAL DATA

Cabinet Specifications

115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1

Feed Wires (Incl. Ground) 3 3 3 3 3 3

Condensing Unit Specs.

115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1

Total Amperes 6.9 7.2 9.1 9.8 12.4 13.4

Cabinet Amperes 1.6 1.9 1.9 2.3 2.9 3.9

Defrost Amperes - - - - - -

Power Supply Cord yes yes yes yes yes yes

SHIPPING DATA

Height – crated (in.) 851/2851/2851/2851/2851/2851/2

Width – crated (in.) 315/8315/864 64 90 90

Depth – crated (in.) 42 42 42 42 42 42

Volume – crated (cu.ft.) 65 65 133 133 187 187

Weight Std – crated (lbs.) 320 350 535 595 740 825

Weight SS – crated (lbs.) 380 410 615 675 855 945

Weight Std – uncrated (lbs.) 220 250 365 425 530 620

Weight SS – uncrated (lbs.) 280 310 445 505 645 735

DL1R-SS DL2R-SS DL3R-SS

One Section Two Section Three Section

**Rating @ +25°F Evaporator, 90° Ambient

Note: All Specifications subject to change without notice.

Note: If the cabinet is located directly against a wall and/or under low ceiling, a minimum clearance of 2" is

required.

Cabinet upper side panels and refrigeration plug system can be easily removed and reinstalled at installation site

where space limitations are confining.

A Division of National Refrigeration & A/C Products, Inc.

539 Dunksferry Road Bensalem, PA 19020

(800) 523-7138 Fax: (215) 244-9579

www.continentalrefrigerator.com
