Continental Refrigerator DL27-12M Manuel utilisateur

SANDWICH UNIT

MIGHTY TOP

Standard Features

• Unique Air Flow Distribution allows Pan Product To

Maintain 33-41°F Being in Compliance With And

Certified Under The New ‘98 NSF Standard For

Preparation Units

• Modern, State-of-the-Art Styling Performance Rated

Refrigeration System Utilizing

Environmentally Safe R-134a Refrigerant

• Easily Serviceable Rear Mounted Compressor

• 2" Non-CFC Polyurethane Foam Insulation

• Spring Loaded, Self-Closing Door

• Magnetic Snap-in Gasket

• Adjustable 6" Legs

• Heavy Duty, Epoxy-coated Steel Shelves

• Interior Hanging Thermometer

• Mighty Tops-3 Rows of Pans

• 10" Deep Full Length Nylon Cutting Board

• Cabinet Construction Consisting of Stainless Steel

Exterior and Interior

• Non-Corrosive, Plasticized Fin Evaporator Coil

• Completely Enclosed, Vented and Removable

Case Back

• Automatic, Energy Saving, Non-electric Condensate

Disposal

• 1/6 Size Pans, 4" Deep

• 10 ft. Cord and Plug Attached

REFRIGERATION SYSTEM

The self-contained refrigeration system is rear mounted,

concealed behind a removable louvered cover. Full-

length front air grille allows for even air circulation to

condensing unit. A “Performance Rated”, air-cooled,

hermetically sealed, capillary type refrigeration system

is installed in each model. Plasticized finned coil and air

circulating fans are contained within an easily accessi-

ble rear mounted housing. Our unique airflow design

allows the cabinet to be enclosed on both sides or to be

mounted flush against a wall. Our refrigeration system,

fully charged with R-134a refrigerant, is designed to

maintain 38° - 40° Fahrenheit while operating with an

unrestricted air supply in an ambient temperature of

100° Fahrenheit. All condensate water is directed to a

non-electric condensate vaporizer located in the com-

pressor compartment, thus no plumbing is required. A

strict quality assurance team inspects all materials and

components to certify that each model conforms to the

most exacting standards. All models are performance

tested for a minimum of 16 hours prior to crating.

CABINET CONSTRUCTION

All materials are of top quality and are assembled

under rigid supervision conforming to strict quality

assurance requirements. Case is of all metal weld-

ed construction and is internally supported and

braced for rigid unit construction. Exterior cabinet

back and bottom are heavy gauge galvanized steel.

Worktop is constructed of heavy gauge polished

stainless steel for durability.

Cabinet design eliminates overlapping panels with

raw edges. Interior corners are rounded with a 1/4"

radius for cleaning ease. All cabinet joints and

seams are vapor-tight sealed. An easily removable

anti-sweat door heater, concealed by a non-metallic,

non-conductive, high impact thermal breaker strip,

eliminates condensation build-up on case front.

INSULATION

All cabinet walls, top, and bottom have high density,

foamed-in-place, non-CFC polyurethane insulation.

SHELVING

Shelves are designed for heavy-duty use with

.306" diameter frame and brace members and

.140" diameter fill wires spaced 3/4" apart.

Shelves are welded steel and epoxy-coated

for a durable, long, rust-free service life.

DOOR CONSTRUCTION

Door shells are constructed of heavy-gauge

stainless steel and are internally braced and

urethane-foam-insulated for rigidity. Door cor-

ners are of welded construction and polished.

Replaceable snap-in door gaskets are self

adjusting, heavy-duty, magnetic type. Door

handles and hinges are chrome-plated and

non-corrosive. Hinges are spring loaded,

heavy duty, self-closing.

REFRIGERATORS

Utilizing Environmentally Safe, CFC-free R-134a Refrigerant

Optional Features & Accessories

•Remote Models - R •Door Locks

•Electric Condensate •Single Overshelf

•Additional Shelves •Double Overshelf

•Pan Opening Sizes

DL72-30M

•DL27-12M

•DL48-12M

•DL48-18M

•DL60-12M

•DL60-18M

•DL60-24M

•DL72-18M

•DL72-27M

•DL72-30M

Models Available

REFRIGERATORS

DLM305

A Division of National Refrigeration & A/C Products, Inc.

539 Dunksferry Road Bensalem, PA 19020

(800) 523-7138 Fax: (215) 244-9579

www.continentalrefrigerator.com

MODEL MODEL MODEL MODEL MODEL MODEL MODEL MODEL MODEL

CHARACTERISTICS

DL27-12M DL48-12M DL48-18M DL60-12M DL60-18M DL60-24M DL72-18M DL72-27M DL72-30M

DIMENSIONAL DATA

Net Capacity (cu. ft.) 7.4 13.4 13.4 17.0 17.0 17.0 20.6 20.6 20.6

1/6 Size Pans (4" Deep) 12 12 18 12 18 24 18 27 30

Width, Overall (in.) 271/248 48 60 60 60 72 72 72

Depth, Overall (Incl. Hdls.) (in.) 34 34 34 34 34 34 34 34 34

Depth, Body only (Less Door(s) (in.) 271/2271/2271/2271/2271/2271/2271/2271/2271/2

Depth, Cutting Board 10 10 10 10 10 10 10 10 10

Height (Incl. 6" Legs) 43 43 43 43 43 43 43 43 43

Shelf Area (sq.ft.) 3.5 6.8 6.8 8.1 8.1 8.1 10.2 10.2 10.2

Shelves 1222 22333

Doors 1222 22333

Condensing Unit Size (H.P.) 1/51/51/51/41/41/41/41/41/4

Refrigerant R134a R134a R134a R134a R134a R134a R134a R134a R134a

Cabinets Electric 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1

Amps 6.2 7.1 7.1 8.2 8.2 8.2 9.0 9.0 9.0

Fans 2333 33444

Interior Depth (in.) 20 20 20 20 20 20 20 20 20

Interior Height (in.) 261/4261/4261/4261/4261/4261/4261/4261/4261/4

Interior Width (in.) 24 1/2 44 44 56 56 56 68 68 68

Shipping Weight (lbs.) 188 282 285 319 322 330 398 414 420

Shipping Height (in.) 431/4431/4431/4431/4431/4431/4431/4431/4431/4

Shipping Length (in.) 353/464 64 681/4681/4681/4801/4801/4801/4

Shipping Depth (in.) 46 46 46 46 46 46 46 46 46

SIDE VIEW DIMENSIONS

DL27-12M FRONT VIEW

DL27-12M TOP VIEW DL60-18M TOP VIEW

DL60-24M TOP VIEW

DL72-27M TOP VIEW

DL72-18M TOP VIEW

DL72-30M TOP VIEW

DL48-12M TOP VIEW

DL48-18M TOP VIEW

DL48-12M, 18M FRONT VIEW

DL60-12M TOP VIEW

DL72-18M, 27M,30M FRONT VIEW

DL60-12M, 18M,24M FRONT VIEW
