CONCORD Eye-Q Go Wireless Manuel utilisateur
CONTENTS
ENGLISH............................................................................................1
DEUTSCH ..........................................................................................9
CONTENTS
GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 1
This Quick Start Guide provides a quick reference for
operating your new digital camera and USB Wireless
Bluetooth Adaptor. Refer to the hard copy of the User’s
Guide or the electronic version which can be found on the
PC Software Installation Disk CD-ROM for detailed
instructions on how to use all of your camera’s features.
Before using the camera, make sure to read all safety
instructions and precautions outlined in the User’s Guide.
QUICK START GUIDE
ENGLISH
1
GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 1
2
CAMERA OVERVIEW
CAMERA OVERVIEW
Top/Front
Bottom/Back
1. Shutter Button
2. Mode Switch
3. Neck/Wrist Strap
Holder
4. Viewfinder
5. Flash Sensor
6. Flash
7. Self-timer LED
8. Lens
9. Slide Switch
10. Flash Ready LED
11. LCD
12. USB/TV Out Ports
13. Tripod Socket
14. Viewfinder
15. Navigation Button
16. Power Button
17. LCD On/Off Button
18. OK/Magnification
Button
19. Menu Button
20. Battery/Memory
Card Door
1
2
3
4
6
5
7
8
9
A
005/080
AWB
1600
A
005/080
AWB
1600
10
12
11
13
14
15
16
17
18
19
20
A
005/080
AWB
1600
A
005/080
AWB
1600
GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 2
3
TAKING PICTURES
REVIEWING PICTURES
TAKING PICTURES
1. Set the Mode
Switch to ( )
Camera Mode.
2. Position the subject
in the LCD or
viewfinder.
3. Press the Shutter
button to capture
the picture.
1. Set the camera to
( ) Review
Mode.
2. Press to
scroll through the
stored files.
JPEG
005/080
GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 3
4
DELETING PICTURES
DELETING PICTURES
1. Set the Mode
Switch to ( )
Review Mode.
2. Press the MENU
button to display
the ( ) Main
Menu.
3. Press to enter
the Delete
submenu.
4. Press to
highlight Delete
One or Delete All.
5. Press to enter
the submenu.
6. Press to
highlight Yes.
7. Press OK to select.
005/080
DELETE ONE
THIS FILE?
No
Yes
OK MENU
005/080
Delete
Thumbnail
Brightness
Transmit
MAIN MENU
Exit
Delete One
Delete All
DELETE
005/080
GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 4
5
INSTALLING THE SOFTWARE FOR THE USB BLUETOOTH WIRELESS ADAPTOR
INSTALLING THE SOFTWARE FOR THE USB BLUETOOTH
WIRELESS ADAPTOR
Do not plug the USB Bluetooth Wireless Adaptor into the computer before
installing the driver.
1. Insert the Bluetooth Adaptor Installation Disk into your computer’s CD-ROM
drive.
2. The installation screen will appear, click on Install Adaptor Drivers.
3. Follow the on-screen instructions to complete the installation.
Note: For more detailed instructions on installation, please refer to the USB
Bluetooth Wireless Adaptor Installation Guide in the hard copy of the User’s
Guide or the electronic version found in the PC Installation Disk and the
Bluetooth Adaptor Installation Disk.
This software is necessary to add Bluetooth functionality to your PC.
TRANSFERRING PICTURES TO THE COMPUTER WITH
BLUETOOTH
1. Make sure that your computer is on and that
Windows is running.
2. Power on your camera.
3. Remove the cap on the USB Bluetooth
Wireless Adaptor. (fig.1.1)
4. Plug the USB Bluetooth Wireless Adaptor into the
USB port located in the back or front of your
computer. (fig.1.2)
•Keep a distance of no more than 30 feet (10
meters) between the camera and the USB
Bluetooth Wireless Adaptor (2 meters is
recommended).
!
fig.1.1
fig.1.2
GO Wireless QSG (512708-00) 6/6/03 11:08 pm Page 5
6
INSTALLING THE SOFTWARE FOR THE USB BLUETOOTH WIRELESS ADAPTOR
5. Click on the XTNDConnect Blue Manager icon located on the
desktop of your icon. (fig.1.3)
6. Set the Mode Switch to ( ) Review Mode.
7. Press and until the picture that you want to transfer is
displayed on the LCD.
8. Press the MENU button to display the Main Menu.
9. Press until Transmit is highlighted. (fig.1.4)
10. Press the OK button.
•The camera will begin searching for the USB
Bluetooth Wireless Adaptor.
11. The name of the computer will be displayed on the
LCD. Press until the computer name on the
camera’s LCD is highlighted. (fig.1.5)
12. Press the OK button on the camera to start the
transfer.
13. After the transmission is completed, click on the In
Box... icon to display the transferred picture.
14. Double-click on the picture file you want to view.
•Windows will automatically open the picture with
the graphic viewer installed on your computer
such as Microsoft Photo Editor or Quicktime.
15. Rename or save the pictures in the Bluetooth In
Box.
Note: Only one picture can be transferred to the computer with Bluetooth at a
time. To transfer and view other pictures stored on the camera, repeat the steps
above.
fig.1.3
fig.1.4
005/080
Delete
Thumbnail
Brightness
Transmit
MAIN MENU
005/080
BLUETOOTH
My computer
Main Menu
fig.1.5
GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 6
INSTALLING THE CAMERA DRIVERS AND DIRECTX 9
Do not connect the camera to the computer with the USB cable provided
until the camera drivers have been installed.
Note to Windows 98SE, Windows 2000 and Windows ME users: In order to
view your stored video clips on your computer DirectX 9 must be installed.
1. Insert the PC Installation Disk into your computer’s CD-ROM drive.
2. The installation screen will appear, click on Install Camera Drivers.
3. Follow the on-screen instructions to complete the installation.
Note: For more detailed instructions on installation, please refer to the Camera
Drivers and Software Installation Guide in the hard copy of the User's Guide or
an electronic version can be found on the PC Installation Disk.
7
INSTALLING THE CAMERA DRIVERS AND DIRECTX 9
!
GO Wireless QSG (512708-00) 6/6/03 11:31 pm Page 7
8
CONNECTING THE CAMERA TO THE COMPUTER
DOWNLOADING PICTURES AND VIDEO CLIPS ONTO YOUR
COMPUTER USING THE MINI-USB CABLE
Downloading files from the camera:
•Internal memory: Do not insert the memory card.
•Memory Card: Insert the memory card.
Do not insert or remove the memory card when the camera is connected
to the computer.
Downloading Pictures and Video Clips onto your computer:
1. Set the camera to Pic mode.
•Set the Mode Switch to ( ).
•Press the MENU button to display the main menu.
•Press until Setup is highlighted.
•Press to enter the Setup submenu.
•In the Setup menu, press until Driver is highlighted.
•Press to change the setting to Pic.
•Press the Menu button to exit.
2. Connect the camera to the computer with the Mini-USB cable.
3. Double-click on My Computer>Removable Disk>DCIM>100GOWIR.
•The stored pictures (JPG) and video clips (AVI) stored in the internal memory
or the memory card will be displayed.
4. Click and drag the files into a directory in your computer to save them.
•To select all files, click Edit > Select all.
!
GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 8
