Conceptronic CSM3PL Firmware Upgrade Instructions

for Cyrillic firmware version OMP0 ST011208A / 1.60

A. Suitable firmware versions

Note: This firmware upgrade for the CSM3PL is only suitable for devices with the following

firmware versions:

OMP07T052907A

OMP07ST081007A

B. Upgrade information

The Conceptronic CSM3PL is equipped with n upgr de ble firmw re chip. This function m kes it

possible to improve the device nd to dd new fe tures.

Note: The firmware upgrade procedure is at your own ris . Even though a firmware upgrade can

improve the device and add new features, there’s also a possibility of an upgrade failure which

ma es the device unusable. Conceptronic is not responsible for this and this voids the warranty.

Note: This firmware is only for customers who use subtitles that contain characters from the Cyrillic

alphabet. This firmware is not for countries that don’t use the Cyrillic alphabet.

www.conceptronic.net

Page 2 of 6

C. WARNING !!!

There re two different versions of the Conceptronic Medi Pl yer on the m rket. Both versions only

differ in h rd disk connection type (SATA vs. IDE) nd the supplied remote control. Since the devices re

so simil r it is m nd tory to pick out the right product when upgr ding the firmw re. The e siest w y to

identify your Medi Pl yer is through the remote control.

Below you see n im ge of both remote controls, continue this firmw re upgr de procedure only when

you h ve the RIGHT remote control.

www.conceptronic.net

Page 3 of 6

D. Upgrade procedure from the internal hard disk of the CSM3PL

1. Copying the firmware files to the CSM3PL

1.1 If you h ve downlo ded the firmw re upgr de from www.conceptronic.net, you h ve ZIP file

cont ining folder n med ‘FW’ nd three document tion files.

1.2 Connect the CSM3PL to your computer with the USB c ble.

1.3 Copy the ‘FW’ folder including ll its content to the h rd disk of the CSM3PL.

1.4 Remove the CSM3PL from your computer with the ‘Safely remove hardware’ option.

1.5 Disconnect the USB c ble of the CSM3PL nd turn it off with the switch on the b ck side.

2. Updating the firmware

2.1 Connect the CSM3PL to TV or monitor.

2.2 Turn on the CSM3PL with remote control.

2.3 Select the ‘FW’ folder by using the n vig tion buttons on the remote control.

The upgr de process will now st rt. This will be visible in the upper left corner with the terms

‘ERASE’ nd ‘WRITE’.

Note: The CSM3PL must not be turned off during the upgrade process. Doing so will

result in an unusable product which is not covered by the warranty.

2.4 As soon s the upgr de process is completed, the screen will go bl ck.

Note: The device is still turned on. You need to manually turn off the device by pressing the

‘POWER’ button on the remote control. You can completely turn the device off by

turning off the switch on the bac side of the device.

3. Removing the ‘FW’ folder

3.1 Connect the CSM3PL to your computer with the USB c ble.

3.2 Remove the ‘FW’ folder from the h rd disk. This m kes sure the CSM3PL won’t st rt upd ting

g in when the ‘FW’ folder is selected on your TV or monitor.

3.3 Remove the CSM3PL from your computer with the ‘Safely remove hardware’ option.

3.4 Disconnect the USB c ble from the CSM3PL nd turn it off with the switch on the b ck side.

www.conceptronic.net

Page 4 of 6

4. Checking the current firmware version

4.1 M ke sure the CSM3PL is connected to TV or monitor.

4.2 Select folder by using the n vig tion buttons on the remote control.

4.3 Press the ‘FUNC’ button on the remote control, select ‘PROPERTIES’ nd press the ‘Enter’

button.

4.4 Now press the ‘Pause’ button ( II ) five (5) times in row.

4.5 Le ve the current screen by pressing the ‘FUNC’ button.

4.6 When the ‘Fast Forward’ button ( >> ) is pressed, the current firmw re version will be shown.

This must be: VER 32-O MP0 ST011208A-2L.

4.7 If the version isn’t shown long enough, you need to press the ‘Fast Forward’ button g in.

4.8 If the displ yed version isn’t the s me s the version described t point 4.6, then you need to

repe t the upgr de procedure s described in ch pter D.

E. Upgrade procedure from a USB stick or memory card

1. Copying the firmware files to a USB stick or a memory card

1.1 If you h ve downlo ded the firmw re upgr de from www.conceptronic.net, you h ve ZIP file

cont ining folder n med ‘FW’ nd three document tion files.

1.2 Connect the USB stick or memory c rd to your computer.

1.3 Copy the ‘FW’ folder including ll its content to the USB stick or memory c rd.

1.4 Remove the USB stick or memory c rd from your computer with the ‘Safely remove hardware’

option.

1.5 Disconnect the USB stick or memory c rd from your computer.

2. Updating the firmware

2.1 M ke sure the CSM3PL is connected to TV or monitor.

2.2 Turn on the CSM3PL with the remote control.

2.3 Connect the USB stick to the CSM3PL or slide the memory c rd in the right c rd slot of the

CSM3PL.

2.4 A screen will be displ yed in which you c n m ke the choice between ‘HARD DISK’ nd ‘USB

DEV’ / ‘<memory card>’, where ‘<memory card>’ is the used memory c rd type (for inst nce

‘COMPACT FLASH’). Choose the option of the USB stick or memory c rd.

2.5 Select the ‘FW’ folder by using the n vig tion buttons on the remote control.

The upgr de process will now st rt. This will be visible in the upper left corner with the terms

‘ERASE’ nd ‘WRITE’.

Note: The CSM3PL must not be turned off during the upgrade process. Doing so will

result in an unusable product which is not covered by the warranty. The same applies

to removing the USB stic or memory card.

www.conceptronic.net

Page 5 of 6

2.6 As soon s the upgr de process is completed, the screen will go bl ck.

Note: The device is still turned on. You need to manually turn off the device by pressing the

‘POWER’ button on the remote control. You can completely turn the device off by

turning off the switch on the bac side of the device.

2.7 Remove the USB stick or memory c rd from the device.

Note: Never do this when the device is turned on and the upgrade process is busy. This will

result in an unusable product.

3. Checking the firmware version

3.1 M ke sure the CSM3PL is connected to TV or monitor.

3.2 Select folder by using the n vig tion buttons on the remote control.

3.3 Press the ‘FUNC’ button on the remote control, select ‘PROPERTIES’ nd press the ‘Enter’

button.

3.4 Now press the ‘Pause’ button ( II ) five (5) times in row.

3.5 Le ve the current screen by pressing the ‘FUNC’ button.

3.6 When the ‘Fast Forward’ button ( >> ) is pressed, the current firmw re version will be shown.

This must be: VER 32-O MP0 ST011208A-2L.

3.7 If the version isn’t shown long enough, you need to press the ‘Fast Forward’ button g in.

3.8 If the displ yed version isn’t the s me s the version described t point 3.7, then you need to

repe t the upgr de procedure s described in ch pter E.

www.conceptronic.net

Page 6 of 6

F. Release notes

OMP0 ST011208A / 1.60:

- Subtitles: Improved “L tin2” ch r cter support for countries with Cyrillic lph bet.

- Firmw re upgr de procedure ch nged. From now on pop-up will show sking you if you w nt to

upgr de or not.

OMP0 ST08100 A:

- Subtitles: “L tin2” ch r cter support for countries like Hung ry, Bulg ri , etc.

OMP0 T05290 A:

- Initi l rele se.
