2RT0435T
www.IGBT-Driver.com Page 1
2RT0435T
Target Description & Application Manual
Two layer Base Board exclusively assembled with through-hole components
for 2SC0435T SCALE™-2 driver for 1200V and 1700V IGBT modules or
MOSFETs with an electrical interface for 2-level, 3-level and multilevel
converter topologies with paralleling capability
Abstract
The 2RT0435T is a dual-channel Base Board for CONCEPT’s SCALE™-2 driver core 2SC0435T, a low-cost
SCALE-2 dual-driver core for the reliable driving and safe operation of IGBTs. This Base Board is assembled
only with THT-components using a two-layer PCB.
The Base Board is suitable to drive almost all available dual IGBT modules up to 1700V like 62mm IGBT
modules, 130mm x 140mm IGBT modules and others. The plug-and-play capability (only the gate resistors
are missing) makes it ready to operate immediately after mounting. The user needs invest almost no effort in
designing or adjusting it to a specific application.
Fig. 1 2RT0435T Base Board with driver 2SC0435T
2RT0435T
Target Description and Application Manual
www.IGBT-Driver.com Page 2
Contents
System Overview ...........................................................................................................................3
The Six Steps to Success................................................................................................................4
1. Choose a suitable Base Board/driver ...................................................................................4
2. Connect the Base Board to the IGBT modules......................................................................4
3. Connect the Base Board to the control electronics................................................................4
4. Select the operating mode..................................................................................................4
5. Check the Base Board function ...........................................................................................4
6. Set up and test the power stack .........................................................................................4
Mechanical Dimensions..................................................................................................................6
Assembly Drawing of Gate Resistors.............................................................................................7
Recommended Assembly of Components......................................................................................8
2RT0435T2A0-12...................................................................................................................8
2RT0435T2A0-17...................................................................................................................8
Pin Designation of Connector X1 and X2.......................................................................................9
Description of Interfaces X1 and X2..............................................................................................9
Pin Designation of Connector X3 ...................................................................................................9
Recommended Interface Circuitry for Connector X3...................................................................10
Description of Interface X3..........................................................................................................10
General ............................................................................................................................... 10
MOD (mode selection) .........................................................................................................11
TB (input for adjusting the blocking time) ............................................................................. 11
How Do 2RT0435T Base Boards Work in Detail?.........................................................................11
Overview............................................................................................................................. 11
Vce monitoring / short-circuit protection................................................................................. 12
Advanced Active Clamping.................................................................................................... 12
Parallel connection of 2RT0435T........................................................................................... 13
3-level and multilevel topologies ........................................................................................... 13
Low-inductance layout .........................................................................................................13
Bibliography.................................................................................................................................14
The Information Source: SCALE-2 Driver Data Sheets................................................................15
Quite Special: Customized SCALE-2 Drivers ................................................................................15
Technical Support ........................................................................................................................15
Quality..........................................................................................................................................15
Legal Disclaimer...........................................................................................................................15
Ordering Information...................................................................................................................16
Information about Other Products ..............................................................................................16
Manufacturer................................................................................................................................16
2RT0435T
Target Description and Application Manual
www.IGBT-Driver.com Page 3
System Overview
The 2RT0435T are Base Boards for the driver 2SC0435T. 2SC0435T are SCALE-2 driver cores based on the
SCALE-2 technology developed by CONCEPT /1/. This is a set of application-specific integrated circuits (ASICs)
that cover the main range of functions needed to design intelligent gate drivers. The SCALE-2 driver chipset is
a further development of the proven SCALE technology /2/.
The basic topology of the 2RT0435T Base Board is shown in Fig. 2.
Fig. 2 Basic schematic of the 2RT0435T Base Board with 2SC0435T driver
The Base Board contains all necessary components for optimal and safe driving of IGBT modules or MOSFETs:
gate clamping, active-clamping diodes (overvoltage protection at turn-off), Vce monitoring (short-circuit
protection), minimum pulse suppression for both input signals (approx. 400ns for turn-on and approx. 600ns
for turn-off), decoupling of the failure outputs by a MOSFET stage as well as the input electrical connector X3
and both electrical output connectors X1 and X2 to connect the power switches. Moreover, it includes
components for setting the turn-off trip level, the response time and the dead time between both channels in
half-bridge mode. Its plug-and-play capability means that it is ready to operate immediately after mounting.
The user needs invest almost no effort in designing or adjusting the Base Board to a specific application. Only
the gate resistors are not assembled in order to provide full flexibility for the user.
For a detailed description of 2SC0435T, please also refer to “Description & Application Manual for 2SC0435T
drivers” on www.IGBT-Driver.com/go/2SC0435T.
2RT0435T
Target Description and Application Manual
www.IGBT-Driver.com Page 4
The Six Steps to Success
The following steps point out the easy way to use 2RT0435T Base Boards in power converters:
1. Choose a suitable Base Board/driver
When applying 2RT0435T Base Boards, you should note that the gate resistors are not assembled. They must
be assembled according to the used IGBT module before start of operation.
The type designation of the Base Board also includes a number corresponding to the voltage class of the used
power device.
These Base Boards are not valid for IGBT modules of other voltage classes than those specified.
Incorrect use may result in failure.
2. Connect the Base Board to the IGBT modules
Any handling of IGBT modules or drivers is subject to the general
specifications for protecting electrostatic-sensitive devices according to
international standard IEC 60747-1, Chapter IX or European standard
EN 100015 (i.e. the workplace, tools, etc. must comply with these standards).
If these specifications are ignored, both IGBTs and drivers may be damaged.
The Base Board can be easily connected to an IGBT module by using the corresponding connectors X1
(channel 1) and X2 (channel 2).
3. Connect the Base Board to the control electronics
Connect the Base Board plug X3 to your control electronics and supply the Base Board with a voltage of +15V.
4. Select the operating mode
The operating mode can be set with input MOD (interface X3: pin 17). For details, see page 11.
5. Check the Base Board function
Check the gate voltage: For the off-state, the nominal gate voltage is specified in the relevant driver data
sheet /3/. For the on-state, it is +15V. Also check the input current consumption of the Base Board without
clock signals and at the desired switching frequency.
These tests should be performed before installation, as the gate terminals may otherwise not be accessible.
6. Set up and test the power stack
Before starting up the system, it is recommended that each IGBT module be checked separately under power-
cycling conditions. It is usually sufficient to apply the single or double-pulse technique. CONCEPT specially
recommends users to check that the IGBT modules switch inside the SOA in the worst case condition, as this
strongly depends on the specific converter construction.
2RT0435T
Target Description and Application Manual
www.IGBT-Driver.com Page 5
Even if only single IGBTs are tested, all the system’s gate drivers must be supplied with energy.
All the other IGBTs are then kept in the off state by applying negative gate voltages. This is
particularly important when switching the IGBTs under test.
The short-circuit behavior can also be verified at this point.
The system is then ready to start under real-world load conditions. This allows the thermal behavior of the
whole arrangement to be determined.
The system must be re-qualified over the entire specified range of temperature and load conditions.
CAUTION: All handling with high voltages involves risk to life.
It is imperative to comply with the respective safety
regulations!
2RT0435T
Target Description and Application Manual
www.IGBT-Driver.com Page 6
Mechanical Dimensions
Fig. 3 Mechanical dimensions of 2RT0435T with 2SC0435T driver
Information about the primary connection X3:
Electrical connector on the Base Board: 71918-120LF from FCI
Recommended cable connector: 71600-020LF from FCI
Recommended twisted pair flat cable: 1700/20 or 2100/20 from 3MTM
2RT0435T
Target Description and Application Manual
www.IGBT-Driver.com Page 7
Assembly Drawing of Gate Resistors
The turn-on and turn-off gate resistors of 2RT0435T Base Boards are not assembled. They must be assembled
by the user.
Recommended gate resistors are PR03 / 3W / 1% (THT), e.g. from Vishay.
The component positions can be found in Fig. 4:
Fig. 4: Assembly drawing of 2RT0435T with highlighted gate resistors
Turn-on gate resistors for channel 1: R112 and R113 in parallel
Turn-off gate resistors for channel 1: R110 and R111 in parallel
Turn-on gate resistors for channel 2: R212 and R213 in parallel
Turn-off gate resistors for channel 2: R210 and R211 in parallel
Note that the wires of the THT gate resistors should not project more than 1.6mm after soldering (excess
length at bottom side). Furthermore, a minimum distance of 1mm must be maintained between the gate
resistor body and the PCB (see Fig. 5).
Fig. 5: Minimum and maximum distances when soldering THT gate resistors (in mm/mil)
2RT0435T
Target Description and Application Manual
www.IGBT-Driver.com Page 8
Recommended Assembly of Components
Recommended components and component values are given in the bill of material included in the production
documentation of the Base Boards. However, some components which depend on the voltage class of the
power semiconductor used are marked with N.A. in the schematics. See also Fig. 6. They are given below.
Note that gate resistor values are not explicitly given as they depend on the power semiconductor used and on
the application. The gate resistors must be determined and assembled by the user.
2RT0435T2A0-12
The following components marked with N.A. in the schematics and in Fig. 6 are recommended:
D106…D108, D206…D208: 1.5KE220A-E3 (e.g. from Vishay)
D109, D209: 1.5KE250CA-E3 (e.g. from Vishay)
2RT0435T2A0-17
The following components marked with N.A. in the schematics and in Fig. 6 are recommended:
D106…D108, D206…D208: 1.5KE350A-E3 (e.g. from Vishay)
D109, D209: 1.5KE300CA-E3 (e.g. from Vishay)
Fig. 6: Schematic of the secondary side of the Base Board 2RT0435T
2RT0435T
Target Description and Application Manual
www.IGBT-Driver.com Page 9
Pin Designation of Connector X1 and X2
Pin Des. Function
1 Cx Collector of channel x
3 N.C. Not connected
5 N.C. Not connected
7 Ex Emitter of channel x
Pin Des. Function
2 N.C. Not connected
4 N.C. Not connected
6 Gx Gate of channel x
Description of Interfaces X1 and X2
X1 and X2 are the connectors to connect the power switch to the channel 1 (X1) and channel 2 (X2)
respectively. Note that the pin assignments 2-5 must remain free (without crimp contact) in order to guaranty
sufficient creepage path between both channels.
Pin Designation of Connector X3
Pin Des. Function
1 VDC +15V for DC/DC converter
3 VDC +15V for DC/DC converter
5 VCC +15V for primary side electronics
7 VCC +15V for primary side electronics
9 SO2 Status output channel 2
11 INB Signal input channel 2
13 SO1 Status output channel 1
15 INA Signal input channel 1
17 MOD Mode selection (direct/half-bridge)
19 TB Blocking time
Pin Des. Function
2 GND Ground
4 GND Ground
6 GND Ground
8 GND Ground
10 GND Ground
12 GND Ground
14 GND Ground
16 GND Ground
18 GND Ground
20 GND Ground
Fig. 7: Schematic of the primary side of the Base Board 2RT0435T
2RT0435T
Target Description and Application Manual
www.IGBT-Driver.com Page 10
Recommended Interface Circuitry for Connector X3
Fig. 8 Recommended user interface of 2RT0435T
Description of Interface X3
General
The standard DIC20 interface X3 of the Base Board 2RT0435T is very simple and easy to use. It has the
following terminals:
4 x power-supply terminals (but only one 15V power supply is needed)
2 x drive signal inputs
2 x status outputs (fault returns)
1 x mode selection (half-bridge mode/direct mode)
1 x input to set the blocking time
The Base Board is equipped with a 20-pin interface connector. All even-numbered pins are used as GND
connections. The odd-numbered pins are used as inputs or status outputs. It is recommended to use a 20-pin
twisted flat cable. Each input and output signal is then twisted with its own GND wire. All GND pins are
connected together on the 2RT0435T Base Board and should also be connected on the control-board side.
This arrangement produces a very low-inductance connection with high immunity against interferences.
Table des matières
Manuels Carte mère populaires d'autres marques
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuel utilisateur
Gigabyte
Gigabyte GA-9IVDT Manuel utilisateur
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
