Comtech EF Data CDM-600L Manuel utilisateur

Part Number MN/CDM600L.IOM Revision 2

IMPORTANT NOTE: The information contained in this document supersedes all previously published

information regarding this product. Product specifications are subject to change without prior notice.

600L

Open Network Satellite Modem (2.4 kbps – 20 Mbps

)

Installation and Operation Manual

For Firmware Version 1.3.0 or hi

(

see New in this Release

–

Section 1.5

)

s:\tpubs\manuals\released_word\modems\cdm600l_rev2\errata\mn-cdm600l-ea2.doc 1

Errata A

Comtech EF Data Documentation Update

Subject: Changes to 15.7 Miscellaneous

Date: March 30, 2005

Original Document

Part Number/Rev:

MN/CDM600L.IOM Rev 2

Errata

Part Number:

MN/CDM600L.EA2

This information will be incorporated into the next revision.

Change Specifics:

Changed from:

Dimensions 1U high, 12 inches (305 mm) deep

To:

Dimensions 1U high, 18 inches (457 mm) deep

Note: The dimensional envelope drawing in Chapter 4 is correct.

s:\tpubs\manuals\released_word\modems\cdm600l_rev2\errata\errata b.doc 1

Errata B

Comtech EF Data Documentation Update

Subject: Changes to power consumption and fuse information

Date: April 25, 2005

Document: CDM-600L Satellite Modem Installation and Operation Manual,

Rev.2, dated March 9, 2005

Part Number: MN/CDM600L.EB2

Collating Instructions: Attach this page to page x

Comments:

This information will be incorporated into the next revision.

Change Specifics:

FUSES

The CDM-600L Satellite Modem is fitted with two fuses, one each for line and neutral

connections. These are contained within the body of the IEC power connector, behind a small

plastic flap.

• Use T5.0A, Slow blow fuse, P/N FS/5ASB-IEC.

The DC CDM-600L Satellite Modem is fitted with two fuses – one each for positive and

negative connections. These are contained within the body of the power inlet , behind a

small plastic flap.

• For 38 to 60 VDC operation, use T2.0A, 20mm fuses if the modem has no BUC

power supply.

• For 38 to 60 VDC operation, use T8.0A, 20 mm fuses if the modem is fitted with

internal BUC power supply.

IMPORTANT

For continued operator safety, always replace the fuses with the

correct type and rating.

s:\tpubs\manuals\released_word\modems\cdm600l_rev2\errata\errata c.doc 1

Errata C

Comtech EF Data Documentation Update

Subject: Change AUPC Target Eb/No Limit

Date: November 23, 2005

Document: CDM-600L Revision 2, Open Network Satellite Modem, Installation

and Operation Manual, dated March 9, 2005

Part Number: MN/CDM600L.EC2

Collating Instructions: Attach this page to page 16-23

Comments:

The following changes affects the values shown on page 6-10 and 16-23.

Change Specifics:

Change to AUPC Target Eb/No Parameter

Since Revision 2 of the CDM-600L Manual was published, the range of the value of target Eb/No has

been increased. Effective in firmware version 1.4.0 and subsequent:

• Previously the maximum value was 9.9 dB

• New maximum value is 14.9 dB.

This affects the front panel and the remote control, refer to the remote control command table for more

detail.

s:\tpubs\manuals\released_word\modems\cdm600l_rev2\errata\errata c.doc 2

AUPC

Parameters

APP=

6 bytes Command or Query.

Defines AUPC operating parameters. Has the form abc.cd,

where:

a=Defines action on max. power condition.

(0=do nothing, 1=generate Tx alarm)

b=Defines action on remote demod unlock.

(0=go to nominal power, 1=go to max power)

c.c=target Eb/No value, for remote demod, from 0.0 to

14.9 dB, where numbers above 9.9 use hex

representation for the 1 st character, ie 14.9 is

coded as E.9.

d =Max increase in Tx Power permitted, from

0.0 to 9.0 dB

Example: APP=015.67 (Sets no alarm, max power, 5.6 dB

target Eb/No and 7 dB max power increase.

APP=

APP?

APP*

APP#

APP? APP=abc.cd

(see description of

arguments)

CDM-600L

Open Network Satellite Modem (2.4 kbps – 20 Mbps)

Installation and Operation Manual

For Firmware Version 1.3.0 or higher

(see New in this Release – Section 1.5)

Part Number MN/CDM600L.IOM

Revision 2

March 9, 2005

Comtech EF Data, 2114 West 7th Street, Tempe, Arizona 85281 USA, 480.333.2200, FAX: 480.333.2161

Comtech EF Data is an ISO 9001

Registered Company.
