COMPOUND PLATINUM Series Manuel utilisateur

OWNER’S MANUAL

CAUTION: Read all precautions and instructions before using

this equipment. Save this manual for future reference.

CABLE CROSSOVER

CPL-CBC-1023

ASSEMBLY INSTRUCTIONS

SKU: CPL-CBC-1023

CABLE CROSSOVER

PIN LOADED MACHINE

PLATINUM SERIES

COMPOUND.

FITNESS EQUIPMENT

CAUTION: Read all precautions and instructions before

using this equipment. Save this manual for future reference.

CONTENTS

02 General warnings and maintenance advice

60-30 Assembly Instructions

Explained as a series of steps,with each step containing:

Pictures,descriptions of the parts required

Notes

Diagram showing how the parts fit together

tsiL traP 90- 70



Assembly Instructions

This exercise equipment is built for optimum safety. Be sure to read the entire

manual before you assemble or operate your equipment. Please note the

following safety precautions:

1. Keep children and pets away from the equipment at all times. Do not leave

children unattended in the same room with the equipment.

2. Only one person at a time should use the equipment.

3. If the user experiences dizziness, nausea, chest pain, or any other abnormal

symptoms STOP the workout at once CONSULT A PHYSICIAN IMMEDIATELY.

4. Position the equipment on a clear, level surface. DO NOT use the equipment

near water or outdoors.

5. Keep hands away from all moving parts.

6. Always wear appropriate workout clothing when exercising. DO NOT wear

robes or other clothing that could become caught in the equipment.

7. Use the equipment only for its intended use as described in this manual.

DO NOT use attachments not recommended by the manufacturer.

8. Before using the equipment, always do stretching exercises to properly

warm up.

9. Never operate the equipment if the equipment is not functioning properly.

Before Your Begin

INFORMATION

We recommend you have someone

assist you in lifting and assembling

your gym.

Follow these steps carefully and it

will make it easier to assemble your

gym.

ighten all the bolts/nuts.



STEP 1



NOTE:

In this step ,all the washers

and nuts which are not marked

are W10 and N10.

CH6-4

CH4-5

A8-3

H10-5

SC10-20

SC10-22

30 36

31 51

SC6-10

17 x6

19 x8

H6-6

W6B

×7

×10

INFORMATION

We recommend you have someone

assist you in lifting and assembling

your gym.

Follow these steps carefully and it

will make it easier to assemble your

gym.

ighten all the bolts/nuts.



STEP 2



NOTE:

In this step ,all the washers

and nuts which are not marked

are W10 and N10.

N10

W10

N10

W10

W10 SC10-29

SC10-29

SC10-14

SC10-10

SC10-11

SC10-22

SC10-10

8245mm

NOTE:Assemble the cap first.

CH4-7

INFORMATION

We recommend you have someone

assist you in lifting and assembling

your gym.

Follow these steps carefully and it

will make it easier to assemble your

gym.

ighten all the bolts/nuts.



STEP 3

S5-1



NOTE:

This step is Pre-Assembly.

A8-3

W8B 41

A8-3

W8B

INFORMATION

We recommend you have someone

assist you in lifting and assembling

your gym.

Follow these steps carefully and it

will make it easier to assemble your

gym.

ighten all the bolts/nuts.



STEP 4

SC10-19

W10

N10

PARTS LIST

Part# Description Qty

1 Main Frame 2

2 Linking Tube 1

3 Adjuster Post Base 2

4 Adjuster Post 2

5 Tube Top 4

6 Guide Post 4

7 Selecter Bar 2

8 Adjuster Lever Assembly 2

9 Swivel Pulley Carriage 2

10 Pulley Bracket 2

11 Carriage Shround 2

12 Lable Placard 2

13 Arc Plate 2

14 Pulley Cap 8

15 Guide Post Bushing 4

16 Fixing Plate 8

17 5 Kg Weight Plate 14

18 2.5 Kg Top Weight Plate 2

19 7.5 Kg Weight Plate 20

20 Weight Stack Pin 2

21 Spring Pin 2

22 Handle End Cap 6

23 Handle Ring 6

24 Rubber Foot 6

25 Footcover 6

26 Shock Rubber Gasket 8

27 Weight Stack Bushing 52

28 Weight Stack Head Bushing 4

29 Slide Bushing 6

30 Bearing 6203 16

PARTS LIST

Part# Description Qty

31 Shaft D19x117.5 2

32 ADJ Plate 4

Front Panel 2

2.5 Kg Weight Plate 2

Weight Label 2

36 Shaft D17x90.5 6

37 Shaft D17x76 2

38 E Washer 16

39 Pulley D114 14

40 Pulley D89 2

41 Panel 2

42 End Cap 40x80 2

43 Plastic Stoper 8

44 Grip 384 2

45 Grip 195 2

46 Grip 170 2

47 Retaining rings D25 4

48 Single Handle 2

Cable L8169mm

nkle Strap 2

51 Bumper 2

52 Cap D245 4

53 Half Cap D245 2

54 Carabiner 2

S5-1 Socket Set Screw M5x4 24

S8-10 Socket Set Screw M8x50 4

H10-5 Hex Head Bolt M10x25 12

SC10-10 Socket Cap Screw M10x50 12

SC10-11 Socket Cap Screw M10x55 6

SC10-14 Socket Cap Screw M10x70 2

PARTS LIST

Part# Description Qty

SC10-22 Socket Cap Screw M10x110 10

SC10-29

A6-10

Allen Bolt M6x30

ocket Cap Screw M10x145 8

A8-3 Allen Bolt M8x15 18

N10 Nylon Nut M10 52

W4 Washer 48

W6 Washer 61

W6B Big Washer 6 16

W8B Big Washer 8 OD24 16

W10 Washer 10 80

SC10-20 Socket Cap Screw M10x100 2

SC10-19 Socket Cap Screw M10x95 8

CH4-5 Cross Recessed Pan Head Screw M4x10 8

CH6-4 Cross Recessed Pan Head Screw M6x10 12

CH4-7 Cross Recessed Pan Head Screw M4x16 8
