Compaq ProLiant DL760

Service Overview

Abstract: This white paper outlines new features and benefits of the

Compaq ProLiant DL760, successor to the ProLiant 8500. Key

differences include the new PCI-X bus, new ROM Based Setup

Utility (RBSU) and the Intel Pentium III 900 MHz processor. PCI-X

information includes a description of PCI-X technology, physical

expansion board and slot configurations and distribution guidelines.

Information on RBSU addresses features, configuration options and

startup procedures. Descriptions and part numbers for three models

of the ProLiant DL760 and a list of supported operating systems are

also included. Since existing ProLiant 8500 systems can be upgraded

to ProLiant DL760 systems in the field, you will find information

and part numbers for the upgrade kits.

Compaq ProLiant DL760 2

Compaq Confidential - Need to Know Required

Rev.1.21 Page 2 of 12

Compaq and the Compaq logo Registered in U.S. Patent and Trademark Office. Microsoft and Windows

are trademarks of Microsoft Corporation in the United States and other countries. All other product names

mentioned herein may be trademarks of their respective companies.

Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information

in this document is provided “as is” without warranty of any kind and is subject to change without notice.

The warranties for Compaq products are set forth in the express limited warranty statements accompanying

such products. Nothing herein should be construed as constituting an additional warranty.

Compaq ProLiant DL760 3

Compaq Confidential - Need to Know Required

Rev.1.21 Page 3 of 12

Product Description

The Compaq ProLiant DL760 is a high-density data center server with 8-way scalable

performance intended for use in 24x7 multiserver rack environments. The server is based on the

ProFusion 8-Way architecture and is packaged in a dense, 7U form factor design.

Performance is maximized with up to 8 Pentium III Xeon processors and 16GB of ECC SDRAM

memory. Eight 64-bit PCI-X slots, three 64-bit PCI slots an integrated Smart Array Controller

and Ultra3 hard drives, enhance input/output performance.

The Compaq ProLiant DL760 has the following standard high availability features:

 PCI Hot Plug slots

 Redundant hot pluggable power supplies and fans

 Redundant processor power modules and network interface controllers

 Smart Array 4200 controllers

 Error checking and correcting (ECC) memory

 Disk System Tracking and Disk Drive Fault Tolerance

 Automatic Server Recovery (ASR2).

In addition to a new Intel Pentium III Xeon 900 MHz processor, the ProLiant DL760 ships

standard with PCI-X technology and ROM-Based-Setup-Utility (RBSU).

New Models

Three new server models are shown in the following table. The number of processors, size of

cache, memory capacity and processor speed vary according to model. The following features are

common to each model:

 Pentium III Xeon processors

 ECC protected 100MHz SDRAM DIMM memory

 PCI and PCI-X I/O busses

 Integrated Smart Array controller

NOTE: The integrated Smart Array controller is implemented using RAID on a Chip (ROC)

which is physically embedded in the system I/O board. A small jumper board called the Array

Enabler routes the ROC signals to the hard drives. This board can be replaced with a bypass cable

assembly (Integrated Array Bypass) to allow an optional controller such as the Compaq 4200

Array Controller to run the internal drives.

Processors Speed Cache Memory Part Number

2 700MHz 1MB 1GB 177656-xx1

4 700MHz 2MB 2GB 177657-xx1

4 900MHz 2MB 2GB 212692-xx1

Compaq ProLiant DL760 4

Compaq Confidential - Need to Know Required

Rev.1.21 Page 4 of 12

New Features

PCI-X technology leverages the wide acceptance of the PCI bus and provides an evolutionary

I/O upgrade to conventional PCI. PCI-X technology increases bus capacity to more than eight

times the conventional PCI bus bandwidth — from 133 MB/s with the 32-bit, 33-MHz PCI bus to

1066 MB/s with the 64-bit, 133-MHz PCI-X bus.

PCI-X enhances the PCI protocol to develop an industry-standard interconnect that exceeds a raw

bandwidth of 1 gigabyte per second (GB/s) and will meet upcoming bandwidth needs of

enterprise computing systems.

PCI-X provides backward compatibility with the PCI bus at both the expansion board and system

level.

ROM–Based Setup Utility (RBSU) will automatically configure the system based on the

operating system selected. RBSU supports a wide range of customizable configuration features.

RBSU replaces the System Configuration Utility feature.

Faster Intel Pentium III Xeon processors are supported on the ProLiant DL760 server. The

server is capable of supporting up to eight processors and eight Processor Power Modules. Each

processor requires an associated Processor Power Module. Each Processor Power Module has

two identical power circuits on it to provide redundancy for its processor. A ninth Processor

Power Module is always present to provide processor bus termination power.

NOTE: The server will NOT boot if the Intel Pentium III Xeon processors are NOT the same

speed.

Understanding PCI-X

PCI-X is an evolutionary bus architecture based on the prevalent PCI bus. PCI-X technology

leverages the wide acceptance of the PCI bus and provides an evolutionary I/O upgrade to

conventional PCI.

PCI-X technology increases bus capacity to more than eight times the conventional PCI bus

bandwidth — from 133 MB/s with the 32-bit, 33-MHz PCI bus to1066 MB/s (1GB/s) with the

64-bit, 133-MHz PCI-X bus as summarized in the table below:

PCI-X Bus Performance

64-bit card 133 MHz 1066 MB/s

The 64-bit, 133-MHz interconnect protocol achieves this performance through the use of a

such as the attribute phase and split transactions that allow more efficient use of the bus.

PCI-X technology is backward compatible with conventional PCI systems at the system, device

driver, and the adapter level. Conventional PCI adapters will operate in PCI-X systems, and vice

versa; however, when a PCI-X adapter is placed on a conventional PCI bus, it is limited to

conventional PCI speeds.

Compaq ProLiant DL760 5

Compaq Confidential - Need to Know Required

Rev.1.21 Page 5 of 12

A PCI-X system automatically switches between conventional PCI and PCI-X mode, depending

on the type of adapters installed on the bus segment. If a PCI-X bus segment includes any

conventional PCI adapters, that segment must operate in conventional PCI mode.

Just as with conventional PCI, the operating frequency is adjusted to match that of the slowest

device on the bus. If the bus includes a 33-MHz adapter, the bus must operate at 33 MHz. If only

conventional 66-MHz devices are present, a PCI bus optionally operates in conventional 66-MHz

or 33-MHz mode. The table below illustrates several possible combinations of system and adapter

frequencies:

Understanding RBSU

RBSU is an updateable, "intelligent" configuration utility that is embedded in the server ROM.

The purpose of RBSU is to help you configure certain server hardware settings and prepare your

server for operating system (OS) installation. Like its predecessor, SCU, RBSU allows you to

view and establish server configuration settings during initial system startup, as well as modify

them after the server has been configured.

The Configuration Options table describes some of the configuration options that may be

available through RBSU.

Option Description

System Select or configure system specific options such as OS,

COM ports, LPT ports, standard boot order, NUMLock

PCI devices View installed PCI devices and configure IRQs for

these devices.

Date and time View and change system date and time

Automatic Server Recovery (ASR) View and configure ASR settings

Server passwords Set and change server passwords

System identification Set the server asset tag and text displayed on the IMD

Boot controller order View and change the controller order. All mass storage

devices are included in this selection.

Advanced options Configure options normally set by default and not user-

modified, such as MPS/APIC mode, Hot-Plug

Reservation, and CPU correction marking.

Compaq ProLiant DL760 6

Compaq Confidential - Need to Know Required

Rev.1.21 Page 6 of 12

Key Features

The features that make RBSU an efficient and flexible configuration tool include:

•Familiar Interface. RBSU retains the look, feel, and functionality of SCU to ease

transition for customers accustomed to using SCU. Only a few menu and navigation

differences are noticeable.

•Flexible User Control. RBSU allows you to select between a default configuration or

create your own, customized configuration settings.

•ROM-Embedded Location. Because it is housed in the system ROM, RBSU can be

accessed by pressing the F9 function key during the system startup process. This feature

allows you to change your settings without having to depend on a SmartStart and Support

Software CD or startup diskette.

•"Silent" Conflict Resolution. Rather than allow configuration conflicts to occur, RBSU

automatically avoids any settings that would create hardware and software conflicts.

RBSU checks each setting as it is made and immediately resolves possible conflicts

without issuing an audible warning message.

•Virtual Presence. Because RBSU is embedded in the system ROM, system administrators

can use the Compaq Remote Insight Lights-Out Edition to remotely access and configure

the system in a totally unattended fashion. (When these tools are used in combination

with the SmartStart Scripting Toolkit, multiserver configurations can also be performed

remotely in a silent command line mode.)

NOTE: A reboot is required to enable the Remote Insight Board to access the ROM.

•Automated Language Selection. RBSU is available in English, French, Italian, German,

Spanish, or Japanese. RBSU allows you to change your language selection at any time

and it automatically updates the keyboard mappings to match the standard keyboard for

the language you select.

•Machine-Specific Settings. RBSU is customized to each server, based on the unique

hardware and software environment of the server. Because RBSU contains only the

information relevant to a single machine, it is smaller and runs faster than traditional

configuration utilities.

•Replication Support. RBSU is designed to work with ConRep to create an editable script

file containing the configuration settings of the server. This script file can then be

deployed across multiple servers with similar hardware and software components.

•System Restore Capability. RBSU uses the Compaq Intelligent Manageability tools to

backup system settings to a configuration file. These settings can be saved for a quick

system restore in a server recovery situation.

•Easy to Update. You can quickly install the latest version of RBSU on an already

configured server by flashing the system ROM using the latest version of ROMPaq.

•Does Not Require or Use the System Partition. RBSU can be installed as part of the

configuration process onto the system partition, if desired. However, unlike SCU, RBSU

does not automatically create the system partition – SmartStart will create the system

partition if it finds no data on the disk.

For more information, see the ROM Based Setup Utility User Guide at www.compaq.com.

Compaq ProLiant DL760 7

Compaq Confidential - Need to Know Required

Rev.1.21 Page 7 of 12

Upgrade Options

ProLiant 8500 to DL760 Upgrade

For customers who have already invested in the ProLiant 8500, Compaq provides an upgrade kit

that enables them to take advantage of the features offered in the ProLiant DL760. There is also a

kit available to upgrade 8500 processors from 550MHz to 900MHz :

Upgrade Kit Part Number

ProLiant 8500 I/O Module Upgrade Kit 180592-B21

900 MHz Processor Upgrade Kit 232291-B21

At the completion of the I/O Module upgrade, the ProLiant 8500 will be renamed the ProLiant

DL760 and will carry an additional serial number. A service white paper entitled Compaq 8500

I/O Module Upgrade (April 2001) is available on the Learning Utility.

Operating Systems Supported

The following operating systems support the ProLiant 8-Way SMP servers:

•Microsoft Windows NT 4.0 Enterprise Edition, Terminal Server Edition

•Microsoft Windows 2000 Advanced Server, Datacenter Server

•SCO Unixware 7.1.1, Unixware 7.1

•Novell Netware 5.x, Netware 4.2 SMP

•Linux from Redhat, SuSE, TurboLinux, Caldera

•Sun Solaris 7 and 8 Intel Platform Edition

Compaq ProLiant DL760 8

Compaq Confidential - Need to Know Required

Rev.1.21 Page 8 of 12

Service Considerations

New I/O Module PCI/PCI-X Slot Information

I/O Board Slot Descriptions

The new I/O module has 11 slots divided into 3 buses. The Primary bus (slots 7 through 9) is

keyed (1) for 64-bit 5V PCI boards or 64-bit PCI universal boards.

The Secondary bus (slots 1 through 6) and the Tertiary bus (slots 10 through 11) are keyed (2) for

64-bit 3.3V PCI/PCI-X boards or 64-bit universal PCI/PCI-X boards.

This is a change from the previous I/O module, where the Secondary bus (slots 1 through 6)

supported 64-bit 5V PCI boards.

I/O Expansion Board Descriptions

The Primary bus will accept a 64-bit 5-V PCI board (1) or a 64-bit universal PCI board (3).The

Secondary and Tertiary buses will accept a 64-bit 3.3-V PCI/PCI-X board (2) or a 64-bit

universal PCI/PCI-X board (3).

Compaq ProLiant DL760 9

Compaq Confidential - Need to Know Required

Rev.1.21 Page 9 of 12

PCI Hot-Plug I/O Expansion Boards

The ProLiant DL760 server supports PCI Hot Plug. PCI Hot Plug and the server’s operating

system work together to allow the following hot-plug actions:

•Hot replacement of expansion boards–This feature allows you to replace a failed

expansion board with an identical expansion board without powering down the server.

• Hot addition of expansion boards–This feature allows you to install new PCI/PCI-X

expansion boards in previously empty slots without powering down the server under

some operating systems.

• Hot upgrade of expansion boards–This feature allows you to replace an expansion

board with a different expansion board without powering down the server.

PCI Hot Plug is backward compatible, although system components fit into one of two

categories; hot-plug aware or non-hot-plug aware. The following three components are required

in the server for complete PCI Hot Plug capability:

• PCI Hot Plug system hardware (available in this server)

• Operating system with PCI Hot Plug support (currently Microsoft Windows 2000,

Microsoft Windows NT, Novell NetWare, and SCO UNIX – support level varies)

• PCI Hot Plug device drivers (available from operating system vendors, Compaq

SmartStart CD, and some individual hardware vendors)

IMPORTANT: If any of the three required components are not hot-plug aware, the system is

fully functional, but not PCI Hot Plug-capable. For further information about PCI Hot Plug

consult the ProLiant DL760 Servers User Guide First Edition (March 2001) Part Number

173774-001

IMPORTANT: Hot addition is not supported under Windows NT 4.0. Empty slots are powered

up at boot and opening the slot release lever will cause the slot to be powered off. If you add a

board in this manner, you will not be able to power up the slot. Windows NT 4.0 does, however,

support hot replacement of identical I/O expansion boards. See the Compaq QuickSpecs for the

Compaq ProLiant DL760 servers at www.compaq.com for a list of supported I/O expansion

boards.

Compaq ProLiant DL760 10

Compaq Confidential - Need to Know Required

Rev.1.21 Page 10 of 12

PCI-X and PCI Bus Distribution Guidelines

The new I/O board in the new I/O module has 11 PCI Hot Plug I/O expansion slots.

Maximum bus speed and expansion board type for each slot are shown in the table below:

Bus Distribution of PCI Hot Plug I/O Expansion Slots

Slots Bus Maximum PCI/PCI-X Bus Speed Expansion Board

1-6 Secondary 64-bit, 33 MHz PCI or 50 MHz PCI-X 64-bit, 33 MHz PCI or 66 MHz

(running at 50 MHz) PCI-X

Boards (3.3v keying)

7-9 Primary 64-bit, 33 MHz PCI 64-bit, 33 MHz PCI Boards (5v

keying)

10-11 Tertiary 64-bit, 66 MHz PCI or 100 MHz PCI-X 64-bit, 33 or 66 MHz PCI, 66 or

133 MHz (running at 100 MHz)

PCI-X Boards (3.3v keying)

Notes: 1. All PCI-X buses support PCI cards at 33 MHz.

2. The bus speed will only run as fast as the slowest board installed.

Autres manuels pour DL760 - ProLiant - 1 GB RAM

Table des matières

Autres manuels Compaq Serveur

Compaq

Compaq 195294-001 - ProLiant - ML370R Manuel utilisateur

Compaq

Compaq DL320 - ProLiant - G3 Instructions d'utilisation et de sécurité

Compaq

Compaq 112726-001 - ProLiant - 6500 Guide de référence rapide

Compaq

Compaq ProLiant 8500 Manuel d'installation et d'exploitation

Compaq

Compaq 108164-003 - ProLiant - 800 Guide de référence rapide

Compaq

Compaq ProLiant 400 Guide de démarrage rapide

Compaq

Compaq 108164-003 - ProLiant - 800 Guide de référence rapide

Compaq

Compaq StorageWorks SAN Director 64 Manuel utilisateur

Compaq

Compaq 234664-002 - ProLiant - ML330T02 Instructions d'utilisation et de sécurité

Compaq

Compaq 5500R - ProLiant - 256 MB RAM Manuel

Compaq

Compaq TruCluster Server AA-RHGWC-TE Manuel utilisateur

Compaq

Compaq ProLiant 6000 Series Instructions d'utilisation et de sécurité

Compaq

Compaq N2400 - TaskSmart - 1 GB RAM Mode d’emploi

Compaq

Compaq ProLiant 8500 Instructions d'utilisation et de sécurité

Compaq

Compaq 221050-001 - ProLiant - 5000R Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Compaq

Compaq ML570 - ProLiant - G2 Manuel

Compaq

Compaq 117755-003 - ProSignia - 740 Guide de référence rapide

Compaq

Compaq Proliant 800 Manuel utilisateur

Compaq

Compaq ProLiant 1000 Guide de référence rapide

Compaq

Compaq AlphaServer GS60 Manuel utilisateur

Compaq

Compaq ProLiant DL580 Manuel

Compaq

Compaq ProLiant 5500 Instructions d'utilisation et de sécurité

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Instructions d'utilisation et de sécurité

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur

Planet

Planet NAS-7410 Manuel utilisateur
