QuickSpecs Compaq Evo Notebook N1000c

DA-11408 North America — Version 4 —July9, 2002 1

Overview

What's New

•Mobile IntelPentium4

processors-M –– up to 1.7 GHz

•400-MHzbus

•ATI Mobility Radeon 7500

Graphics Controller

•MultiPort wireless communication

options

•Dual Pointing Device

•Common Port Replicator,

Advanced Port Replicator, and

External MultiBayOptions

At A Glance

•Mobile Intel Pentium4 processors

–– up to 1.7 GHz

•15-inch XGA

•Configurations as light as

6.82 lb/3.10 kg weight

•256 MB DDR SDRAM (266

MHz),Upgradeable to 1024 MB

•Up to 30-GB SMART hard drives

•Mini PCI modem and integrated

NIC

•Full-size keyboard

•MicrosoftWindowsXP Proand

Microsoft Windows2000

•Protected by a Three-year,

Worldwide Limited Warranty—

certain restrictions and exclusions

apply. Consult the Compaq

Customer Support Center for

details.

What’s Special

•Intel Pentium 4 processors

•All-in-one convenientdesign

•LatestUSB interface

•Wirelessfeaturesthrough\award-

winning MultiPort

•New Common Docking Options

QuickSpecs Compaq Evo Notebook N1000c

DA-11408 North America — Version 4 —July9, 2002 2

Standard Features

Processor and Panel Mobile Intel Pentium 4 processor-M - 1.7 GHz with 512-KB L2 cache

15-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)

Memory

Standard/Maximum 256 MB (266 MHz) DDR SDRAM (256 MB SODIMM in slot 1)

1024 MB (266 MHz) DDR SDRAM (512 MB SODIMMs in slots 1 and 2)

NOTE:Due to the non-industry standard nature of some third-party memory modules, we recommend Compaq

branded memory to ensure compatibility.

Communications 10/100 NICis integrated on the system board

Type III Mini PCI 56K (V.92) modem

NOTE: Designed only to allow faster downloads from V.92 compliant sources. Maximum achievable download

transmission rates currently do not reach 56 KB/s, and will vary with line conditions.

NOTE: Modem availability is subject to country regulatory approval

Keyboard 102-key compatible keyboard with isolated, inverted-T cursor control keys, and right-control key, special feature

hotkeys for instant access to power conservation, toggle between internal and external, or simultaneous displays,

and control brightness and contrast.

Easy Access Internet

Buttons The EvoNotebook N1000c comes with three Easy Access Buttons (EAB) designed to increase customer

productivity by providing one-touch access to helpful Compaq information, favorite Internet destinations, or default

e-mail application. The EAB portion of the keyboard deck also includes dedicated hardware volume control and a

quick-launch button for CD/DVD play.

Pointing Device Dual pointing devices (both pointstick and touchpad)

PC Card Slots One Type II PC Card Slot which supports both 32-bit CardBusand 16-bit PC Cards

Storage Fixed Diskette Drive 1.44-MB Diskette Drive

Primary Hard Drive 30 GB

Fixed Optical Drive DVD/CD-RW Combo Drive

Multimedia JBL Pro Speakers with bass reflex and 16-bit stereo sound

Integrated microphone

Dedicated Hardware volume controls

Headphone-out port

Microphone in port

Software MPEG1 support, MPEG2 and DVD

8X DVD/CD-RW Combination Drive (on select models)

8X DVD-ROM Drive with movie playback software (on select models)

S-video Port

IEEE 1394 Port

4X AGP graphics

32-MB of DDR (Double Date Rate) SDRAM

QuickSpecs Compaq Evo Notebook N1000c

DA-11408 North America — Version 4 —July9, 2002 3

Standard Features

Interfaces PC Card One Type II

Enhanced Parallel EPP/ECP 1

PS/2 1

S-Video 1

VGA 1

1394 1

Port Replicator 1

Headphone/Line-out 1

Microphone in 1

DC Power 1

RJ-11 (modem) 1

RJ-45 (NIC) 1

Infrared Port 1 (4 Mb/s support)

(IrDA 4 MB compliant. IR performance will vary depending on performance of IR

peripherals and application used.)

USB Port 2

LED status indicators 6

Graphics ATI Mobility Radeon 7500, 64-bit video graphics with 32-MB VRAM for increased color depth and graphics

performance

Display (External) Up to 32-bit per pixel color depth

Supports 640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1400 x 1050, 1600 x 1200, or 2048 x 1536 resolutions

up to 160-Hz refresh rate, dependent upon monitor capability, resolution and color depth settings

Display (Internal) 15-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)

Operating System Microsoft Windows XP Pro or Microsoft Windows 2000 (preinstalled)

Software Diagnostics for Microsoft Windows

DVD Playback Software

Compaq Security Management

Safety and Comfort Guide

Acrobat Reader

Reference Guide

Norton Internet Security

Compaq Easy Access Button Software

System Recovery Each unit is shipped with a CD kit for quick recovery (erases hard disk and restores manufacturer installed image)

and software recovery (installs only selected standard software)

Security Configuration Control Hardware

Memory Change Alert

Ownership Tag

Set-up Password

Power-On Password

DriveLock

Enabled for PC SmartCard options

Kensington Lock

QuickSpecs Compaq Evo Notebook N1000c

DA-11408 North America — Version 4 —July9, 2002 4

Standard Features

Power Supply External 65-watt AC adapter, power cord included.

Battery Standard 8-cell Lithium-Ion battery.

The Evo Notebook N1000c provides over 3 hours of battery life using the standard 8-cell Lithium-Ion battery.

NOTE: Actual results may vary with product model, configuration, and individual usage. Compaq results of 3:07

(hr:min) were achieved running the Business Winstone 2001 Battery Mark1.0 on a N1000c with a Intel

Pentium 4-M 1.6 GHz CPU, 15-inch XGA panel, 256-MB RAM, 30-GB HDD, 8X DVD/CDRW, 8-cell

Lithium-Ion battery, and NIC/modem. System parameters were set according to eTesting Labs’

recommendations: panel brightness 50%, hard drive timerthree minutes.

NOTE: This test was performed without independent verification by eTesting Labs Inc. eTesting Labs Inc. makes

no representations or warranties as to the result of the test. BatteryMark is a trademark of Ziff Davis

Publishing Holdings Inc., and affiliate of eTesting Labs Inc., in the U.S. and other countries.

Power Conservation Hibernation

Instant-on via Standby

Pop-ups with three presets

One custom level of power conservation

ACPI compliant

MultiPort

MultiPort is a flexible, innovative solution providing customers the ability to connect to their choice of wireless

standards such as 802.11b or Bluetooth™. This can be achieved by simply changing out the high-performance

wireless module, which is integrated into the top of the notebook. The award-winning MultiPort offers a cost

effective means to migrate to future wireless standards as they become available.

Docking NEW! Port replicator and Advanced Port Replicator. The sleek, new port replicator and advanced port replicator

designs provide simple and convenient port management. Features include NIC pass through, USB, and a 1394

digital port. Compatible across multiple platforms for lower total cost of ownership.

Service and Support Compaq Services includes a Three-Year, Worldwide Limited Warranty, carry-in or pick-up and toll-free 7 x 24

hardware technical phone support. Certain restrictions and exclusions apply. Consult the Compaq Customer

Support Center for details.

NOTE: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center for details.

QuickSpecs Compaq Evo Notebook N1000c

DA-11408 North America — Version 4 —July9, 2002 5

Standard Features

Naming Convention The Etymology of a Model name:

QuickSpecs Compaq Evo Notebook N1000c

DA-11408 North America — Version 4 —July9, 2002 6

Standard Features

MODELS

Display 15-inch color TFT XGA

Processor 1.7 GHz Intel Pentium 4 processor-M

Cache Memory 512KB, L2 Cache

N1000CP170X530WC25O

P/N 470037-782

Memory Standard 256 MB (266 MHz) DDR SDRAM

Maximum 1024 MB (266 MHz) DDR SDRAM

Optical Drive DVD/CD-RW

Hard Drive 30-GB SMART

Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC

Graphics ATI Mobility Radeon 7500, 64-bit video graphics

Video Memory 32-MB VRAM

Audio JBL Pro Speakers with bass reflex and 16bit stereo sound

Operating System Microsoft Windows XP Professional

Warranty 3 Year Parts, 3 Years Labor, 0 Years On-Site (3-3-0)

Display 15-inch color TFT XGA

Processor 1.7 GHz Intel Pentium 4 processor-M

Cache Memory 512KB, L2 Cache

N1000CP170X530WC252

P/N 470037-783

Memory Standard 256 MB (266 MHz) DDR SDRAM

Maximum 1024 MB (266 MHz) DDR SDRAM

Optical Drive DVD/CD-RW

Hard Drive 30-GB SMART

Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC

Graphics ATI Mobility Radeon 7500, 64-bit video graphics

Video Memory 32-MB VRAM

Audio JBL Pro Speakers with bass reflex and 16bit stereo sound

Operating System Microsoft Windows 2000

Warranty 3 Year Parts, 3 Years Labor, 0 Years On-Site (3-3-0)

QuickSpecs Compaq Evo Notebook N1000c

DA-11408 North America — Version 4 —July9, 2002 7

Options

Memory 512-MB (266 MHz) DDR SDRAM Memory Upgrade 269087-B25

256-MB (266 MHz) DDR SDRAM Memory Upgrade 269086-B25

128-MB (266 MHz) DDR SDRAM Memory Upgrade 269085-B25

Monitors TFT8030 Flat Panel Color 18-inch (carbon/silver) 234362-001

TFT7020 Flat Panel Color 17-inch with integrated speakers (carbon/silver) 253217-001

TFT5017 Flat Panel Color 15-inch (carbon/silver) 263874-003

TFT5017m Flat Panel Color 15-inch multimedia (carbon/silver) 279414-001

TFT5030 Flat Panel Color 15-inch (carbon/silver) 228134-001

S9500 19-inch CRT (carbon/silver) 261615-003

V7550 17-inch CRT (carbon/silver) 261611-003

Other Storage Devices IBM1-GB Microdrive(PC card Device) 217390-B25

USB Disk-on-Key – 8MB 249552-B25

USB Diskette Drive 230330-B25

Wireless Connectivity 802.11b MultiPort Wireless LAN module 233412-001

Bluetooth MultiPort module 228057-B21

Compaq WL110 Wireless LAN PC Card 191808-B21

Compaq WL510 Wireless Enterprise Access Point 216709-001

Compaq WL410 Wireless SMB Access Point 191811-001

Compaq WL310 Home Office Access Point 191813-001

Compaq Range Extender Antenna 230268-B21

CDPD WWAN PC Card (U.S. Only) 238111-001

Expansion Bases Port Replicator 269095-001

Advanced Port Replicator 269094-001

External MultiBay 217388-001

Monitor Stand 274407-B25

Power Evo Notebook N1000c 8 Cell primary battery (4.4Ah) 291369-B25

Common Power Solutions External Battery Charger 265603-001

External Battery Charger (Multiple Battery) 265604-001

AC Adapter 65W 265602-001

Aircraft Power Adapter 65W 265649-B25

AC Line Cord (10-ft/3.1 m) 217932-002

QuickSpecs Compaq Evo Notebook N1000c

DA-11408 North America — Version 4 —July9, 2002 8

Options

Input Devices External Enhanced III Keyboard (carbon) 118003-008

Compaq 2 Button Mouse (carbon) 103180-B21

USB 2 Button Scroll Mouse (carbon) 195255-B25

External 10-Key Numeric Keypad (carbon) 294317-B21

USB EZ Access Keyboard 222726-008

Wireless Keyboard and Mouse 251385-008

Security Biometric PC Card 146805-B25

Security Cable Lock 294316-B21

Compaq Smart Card PC Card Reader 135646-B25

Invaluable Accessories Parallel port cable for diskette drive 226748-B21

MP1200 Microportable Projector 261966-001

MP3800 Microportable Projector 262839-001

MP4800 Microportable Projector 257524-001

MP1200 Lamp L20 266331-B24

MP3800 Lamp L30 266633-B24

MP4800 Lamp L90 257892-001

Ceiling Mount Kit CM10 281730-001

Deluxe Carrying Case 253364-001

QuickSpecs Compaq Evo Notebook N1000c

DA-11408 North America — Version 4 —July9, 2002 9

Memory

Compaq Evo N1000

STANDARD MEMORY PLUS OPTIONAL MEMORY

Support for up to 1024 MB of DDR SDRAM memory is available with the installation of optional DDR SDRAM Memory Kits.

Memory Slot 1 Slot 2

256 MB 256 MB --

384 MB 256 MB 128 MB

512 MB 512 MB --

768 MB 512 MB 256 MB

1024 MB 512 MB 512 MB

NOTE:This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some third-party memory

modules, we strongly recommend using only Compaq branded memory modules to ensure compatibility.

Following are memory options available from Compaq:

•512-MB (266 MHz) DDR SDRAM Memory Upgrade 269087-B25

•256-MB (266 MHz) DDR SDRAM Memory Upgrade 269086-B25

•128-MB (266 MHz) DDR SDRAM Memory Upgrade 269085-B25

QuickSpecs Compaq Evo Notebook N1000c

DA-11408 North America — Version 4 —July9, 2002 10

Storage

1. Dedicated optical drive

2. Primary Hard drive

3. Dedicated disk drive

DRIVE SUPPORT

System Drive Support Quantity

Supported Drive

Supported

DVD/CD-RW Combo Drive 1 Dedicated optical drive

DVD-ROM Drive 1 Dedicated o

tical drive

CD-ROM Drive 1 Dedicated o

tical drive

1.44-MB Diskette Drive 1 Dedicated Disk Drive

Hard Drives

30-GB SMART Hard Drive 1 Dedicated hard drive bay

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Compaq Ordinateur portable

Compaq

Compaq 1700 - Armada - PII 266 MHz Mode d’emploi

Compaq

Compaq 1800 Series Fiche technique

Compaq

Compaq Presario R3000 - Notebook PC Manuel utilisateur

Compaq

Compaq Presario V3200 - Notebook PC Manuel utilisateur

Compaq

Compaq Evo Notebook N400c Series Manuel utilisateur

Compaq

Compaq EVO NOTEBOOK N410C Guide de démarrage rapide

Compaq

Compaq nw9440 - Mobile Workstation Manuel utilisateur

Compaq

Compaq Armada 1100 Manuel

Compaq

Compaq Evo Notebook N200 Series Manuel utilisateur

Compaq

Compaq Armada e500s - Notebook PC Manuel utilisateur

Compaq

Compaq Armada E500 Series Mode d’emploi

Compaq

Compaq Armada E500 Series Manuel utilisateur

Compaq

Compaq presario V6000 Manuel

Compaq

Compaq Evo n1005v - Notebook PC Guide de démarrage rapide

Compaq

Compaq 470012-741 - Armada 110 - Celeron 700 MHz Manuel utilisateur

Compaq

Compaq Aero 8000 Manuel utilisateur

Compaq

Compaq Armada 1100 Manuel utilisateur

Compaq

Compaq N400c - Evo Notebook - PIII 700 MHz Instructions d'installation

Compaq

Compaq Sapphire Instructions d'installation

Compaq

Compaq Evo D500 - Convertible Minitower Guide de démarrage rapide

Compaq

Compaq 6530s - Notebook PC Manuel utilisateur

Compaq

Compaq Evo N620c Manuel utilisateur

Compaq

Compaq Armada 6500 Guide d'installation

Compaq

Compaq 6535b - Notebook PC Manuel utilisateur

Manuels Ordinateur portable populaires d'autres marques

HP ze2401xt - Pavilion Notebook PC Manuel utilisateur

Velocity

Velocity NoteMagix M10 Manuel utilisateur

Dell

Dell Alienware 17 R2 Manuel utilisateur

Toshiba

Toshiba A105-S2236 Manuel utilisateur

HP ENVY 17 Manuel

Winbook

Winbook LM Manuel utilisateur

Dell

Dell Inspiron 1464 Manuel utilisateur

Dell

Dell Inspiron 15R 5537 Manuel utilisateur

HP PROBOOK 4520S Manuel

Dell

Dell Latitude ATG D620 Manuel utilisateur

Sony

Sony VAIO PCG-FX270 Manuel utilisateur

Dell

Dell Latitude 7310 Manuel utilisateur

Dell

Dell Precision GU806 Manuel utilisateur

Sony

Sony VAIO PCG-R505JLK Manuel utilisateur

Lenovo

Lenovo THINKPAD X32 Manuel utilisateur

HP Compaq tc4200 Guide de démarrage rapide

Toshiba

Toshiba mini NB300 Manuel utilisateur

Lenovo

Lenovo ThinkPad X201 Tablet Manuel
