Compaq Compaq Portable II Manuel

Foreword

Notice

The information in this guide is subject to change without notice.

Compaq Computer Corporation shall not be liable for technical or editorial

errors or omissions contained herein; nor for incidental or consequential

damages resulting from the furnishing, performance, or use of this material.

This guide contains information protected by copyright. No part of this

guide may be photocopied or reproduced in any form without prior written

consent from Compaq Computer Corporation.

1986, 1990 Compaq Computer Corporation.

COMPAQ, DESKPRO, SYSTEMPRO, FASTART, Registered United States Patent and

Trademark Office.

The software described in this guide is furnished under a license agreement

or nondisclosure agreement. The software may be used or copied only in

accordance with the terms of the agreement.

Product names mentioned herein are for identification purposes only and may

be trademarks and/or registered trademarks of their respective companies.

COMPAQ PORTABLE II PERSONAL COMPUTER

MAINTENANCE AND SERVICE GUIDE

Second Edition (December 1990)

First Edition (February 1986)

Manual Assy No. 101206-002

Text PN 104208-002

Binder PN 104207-001

Preface

This publication is intended as a reference for technicians trained to repair

the COMPAQ PORTABLE II Personal Computer.

Summary of Text

This guide contains the following eight chapters:

Chapter 1, "Operating and Performance Specifications," provides physical,

environmental, and performance specifications for the COMPAQ PORTABLE II

Personal Computer.

Chapter 2, "Power On Self Test," describes the internal system diagnostic

programs that execute automatically when the system is turned on. It also

includes a quick reference for identifying and correcting problems that could

occur during the Power On Self Test procedure.

Chapters 3 and 4: Please see the SUPPORT SOFTWARE MAINTENANCE AND SERVICE

GUIDE for information on the SETUP and ADVANCED DIAGNOSTICS programs.

Chapter 5, "Error Messages and Codes," lists the Power On Self Test (POST) and

DIAGNOSTICS Error Codes and provides the course of action necessary to

resolve the problem.

Chapter 6, "Illustrated Parts Catalog," provides an illustrated reference for

COMPAQ PORTABLE II Personal Computer spare parts.

Chapter 7, "Removal and Replacement Procedures," describes how to remove and

replace field replaceable subassemblies.

Chapter 8, "Jumper Settings, Switch Settings, and Adjustments," provides

detailed information for setting jumpers and switches and performing monitor

adjustments.

Tools and Supplies

The following tools and supplies are required to service the COMPAQ PORTABLE

II Personal Computer:

o Torx screwdrivers, sizes T-15 and T-10

o Slotted blade screwdriver, 1/4 inch

o Needlenosed pliers

o 25 pin printer loopback plug

o 25 pin serial loopback plug

o 9 pin serial loopback plug

o DIAGNOSTICS diskette

o Formatted diskette

Optional Tools

o Memory chip insertion tool

o Memory chip removal tool

o Diskette drive signal extension cable (PN 100546-001)

o Diskette drive power extension cable (PN 100545-001)

o Socket/Torx tool kit (PN 101089-001)

- Torx screwdrivers, sizes T-15 and T-10

- Adjustable socket tool with hex sockets and one Torx socket (T-10)

>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>><<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<

CAUTION

Only trained technicians should attempt to repair this equipment. All

troubleshooting and repair procedures are detailed to allow

subassembly/module level repair only.

Because of the complexity of the individual boards and subassemblies, no one

should attempt to make repairs at the component level or make modifications

to any printed wiring board. Improper repairs may create a safety hazard.

Indications of component replacement or printed wiring board modifications

may void any warranty or exchange allowances.

>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>><<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<

Additional Reference Information

The following support documentation is available for the COMPAQ PORTABLE II

Personal Computer.

o Operations Guide

o MS-DOS VERSION 3 REFERENCE GUIDE

o Technical Reference Guide

o HOW TO DO BUSINESS WITH COMPAQ SERVICE

o COMPAQ SERVICE QUICK REFERENCE GUIDE

o COMPAQ Service Advisories and Bulletins

o COMPAQ QuickFind Support Reference Library

>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>><<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<

WARNING

The computer is designed to be electrically grounded. To ensure proper

operation of the computer, plug the AC power cord only into a properly

grounded AC outlet.

>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>><<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<

Compaq Computer Corporation requires all peripheral devices be connected to

this computer via shielded cables with metal RFI/EMI connector hoods.

WIRE TYPE: Multipaired, overall shielded; Belden #98XX; Alpha #54XX; or

equivalent.

CONNECTOR HOOD: RFI/EMI metal shield; AMP #7451 7X-X; or equivalent.

It is important that the chassis ground of any peripheral device be connected

to the computer chassis. An Alpha #1221 flat braid strap is sufficient.

This strap is not necessary if the shielded cable connects the two chassis.

Chapter 1. Operating and Performance Specifications

Chapter 1.0 Introduction

This chapter contains operating and performance specifications for the COMPAQ

PORTABLE II Personal Computer.

Chapter 1.1 System Unit

Table 1-1. Electrical and Mechanical Specifications

==============================================================================

Dimensions:

Height 7.5 in. (19.0 cm)

Depth 13.9 in. (35.3 cm)

Width 17.7 in. (45.0 cm)

------------------------------------------------------------------------------

Weight Model 1 23.6 lb (10.7 kg)

Model 2 25.6 lb (11.6 kg)

Model 3 26.2 lb (11.9 kg)

Model 4 26.3 lb (12.2 kg)

------------------------------------------------------------------------------

Power Requirements:

Voltage 120 VAC 220 - 240 VAC

Frequency 60 Hz 50 Hz

Current 3A 2.5A

------------------------------------------------------------------------------

AC Power Cable:

Length 79 in. (2 m)

Gauge 18 AWG

------------------------------------------------------------------------------

Environmental Requirements:

Temperature:

Operating 10oC to 40oC (50oF to 104oF)

Nonoperating 10oC to 60oC (50oF to 140oF)

Shipping -30oC to 60oC (-22oF to 140oF)

Humidity:

Operating 20% to 80% (noncondensing)

Nonoperating 5% to 90% (noncondensing

Shock:

Operating 5 g, 11 ms, half sine

Nonoperating 35 g, 11 ms, half sine

Vibration:

Operating 0.5 g, 5 - 550 Hz

Nonoperating 1.0 g, 5 - 550 Hz

Heat Dissipation:

Delivered 410 BTU/hr at 120W

Total Watts 615 BTU/hr at 180W

Maximum Unpressurized Altitude:

Operating 10,000 ft (3048 m)

Nonoperating 30,000 ft (9144 m)

==============================================================================

Chapter 1.2 Keyboard

Table 1-2. Keyboard Specifications

==============================================================================

Dimensions:

Height 1.3 in. (3.30 cm)

Depth 7.0 in. (17.78 cm)

Width 17.1 in. (43.43 cm)

Number of Keys 84

Keyboard:

Cable Length 60.00 in. (152.4 cm)

Coil Diameter 0.75 in. (1.9 cm)

Coil Length 11.00 in. (27.94 cm)

==============================================================================

Chapter 1.3 Video Display Unit

Table 1-3. Video Display Unit Specifications

==============================================================================

Display 9 in. diagonal

90 degree deflection

High persistence green phosphor

Etched surface to reduce glare

Display Size 80 character by 25 line screen

40 character by 25 line screen

Graphic Resolution 640 x 200 dot resolution

320 x 200 dot resolution

Text Resolution 720 x 350 dot resolution

==============================================================================

Chapter 1.4 10 Megabyte Fixed Disk Drive

Table 1-4. 10 Megabyte Fixed Disk Drive Specifications

==============================================================================

Dimensions:

Height 1.7 in. (4.32 cm)

Depth 5.80 in. (14.73 cm)

Width 3.75 in. (9.54 cm)

Weight 2.2 lb (1.0 kg)

Media: 1 Platter

Number of Data Heads 4

Number of Cylinders 306

Average Access Time 105 ms

Data Transfer Rate 5.0 Mb/s

Type 1

==============================================================================

Chapter 1.5 20 Megabyte Fixed Disk Drive

Table 1-5. 20 Megabyte Fixed Disk Drive Specifications

==============================================================================

Dimensions:

Height 1.7 in. (4.32 cm)

Depth 4.1 in. (10.41 cm)

Width 5.75 in. (14.61 cm)

Weight 1.8 lb (0.8 kg)

Media: 2 Platter

Number of Data Heads 4

Number of Cylinders 615

Average Access Time 105 ms

Data Transfer Rate 5.0 Mb/s

Type 2

==============================================================================

Chapter 1.6 360 KByte Diskette Drive

Table 1-6. 360 Kbyte Diskette Drive Specifications

==============================================================================

Dimensions:

Height 1.1 in. (2.85 cm)

Depth 7.9 in. (20.3 cm)

Width 5.9 in. (15.0 cm)

Weight 1.98 lb (0.9 kg)

Media:

Tracks per inch 48

Number of Tracks 40 (when formatted with MS-DOS)

Data Transfer Rate 250 Kb/s

==============================================================================

Chapter 1.7 1.2 Megabyte Diskette Drive

Table 1-7. 1.2 Megabyte Diskette Drive Specifications

==============================================================================

Dimensions:

Height 1.1 in. (2.8 cm)

Depth 8.0 in. (20.3 cm)

Width 5.8 in. (14.6 cm)

Weight 1.9 lb (0.9 kg)

Media:

Tracks per Inch 96 (1.2 megabyte format)

48 (360 Kbyte format)

Number of Tracks 80 (1.2 megabyte format)

40 (360 Kbyte format)

Data Transfer Rate 500 Kb/s (1.2 megabyte format)

300 Kb/s (360 Kbyte format)

==============================================================================

Chapter 1.8 1.44 Megabyte Diskette Drive Specifications

Table 1-8. 1.44 Megabyte Diskette Drive Specifications

==============================================================================

Dimensions:

Height 0.90 in. (2.3 cm)

Depth 6.47 in. (16.42 cm)

Width 5.95 in. (11.1 cm)

Weight 1.98 lb (0.9 kg)

Media:

Tracks per Inch 135

Number of Tracks 80

Data Transfer Rate 500 Kb/s (high density)

250 Kb/s (low density)

==============================================================================

Chapter 1.9 Power Supply

Table 1-9. Power Supply Specifications

==============================================================================

Input Requirements:

Line Voltage 102 to 132 VAC. single phase

180 to 264 VAC. single phase

3.0A fuse, 125 VAC for 120 VAC operations

2.5A fuse, 150 VAC for 220/240 VAC operation

Line Frequency 47 - 62 Hz

Cooling Forced air provided by internal 12 VDC fan

------------------------------------------------------------------------------

Volts Direct Current Output

Nominal Maximum

Nominal Current Continuous Peak Regulation

Voltage Amperes Current Current Tolerance

(VDC) Minimum (Amperes) Maximum * (Amperes) Percentage

------------------------------------------------------------------------------

+5.0 3.0 13.9 13.9 ñ2

-5.0 0.0 0.5 0.5 ñ5

+12.2 1.0 4.0 7.0 ñ2

-12.0 0.0 0.5 0.5 ñ5

------------------------------------------------------------------------------

* These values are maximum values based on nominal operating conditions for

temperature, line voltage, frequency and altitude. Also, a minimum load on

l2 VDC must be maintained for proper power supply operation.

==============================================================================

Chapter 2. Power On Self Test/Problem Isolation

2.1 Power On Self Test

The Power On Self Test (POST) is a series of diagnostic tests performed

automatically when the system is turned on. These tests verify that the

computer system is operating properly. If a subassembly fails POST, an error

code appears on the screen.

To start POST, follow these steps.

1. Turn off the computer.

2. Disconnect the signal cables of any peripheral devices (printers, modems,

and so on) from the computer.

3. Remove the outer access casing to expose the system LED located on the

system board (see Chapter 7 for this procedure).

4. Install a loopback plug connector at each location from which a

peripheral signal cable was removed.

NOTE: To test your printer during the printer test or to log errors to a

printer, reconnect the printer now.

5. Verify that the AC power cable is connected to a usable, grounded, three

pronged AC power outlet.

6. Insert the DIAGNOSTICS diskette into drive A.

7. Turn on the computer. The system automatically runs POST. See

Section 2.2, "System Problem Isolation," for information on handling

system problems.

Chapter 2.2 System Problem Isolation

This section contains problem isolation procedures for identifying and

correcting system related problems.

To isolate system problems, perform the following steps:

1. Verify that the AC power switch is on.

2. Listen for the sound of the fan. Did you hear the fan?

YES: Proceed to step 3.

NO: Turn off the computer and check the condition of the AC power fuse.

Is the fuse good?

YES: Return the AC power fuse to its fuse holder and turn on the system.

Proceed to step 3.

NO: Replace the AC power fuse (refer to Chapter 7 in this guide

for AC power fuse removal and replacement information). Repeat

steps 1 and 2.

3. Did you hear an audible beep or see an error code on the screen?

YES: See Chapter 5, "Error Messages and Codes" for information on how to

identify and correct either audible or error code related problems.

NO: Proceed to step 4.

4. Check the system LED on the system board. Is it lit?

YES: Proceed to step 5. If you did not hear the fan, replace it now.

NO: Replace the power supply subassembly chassis and repeat the problem

isolation procedures.

If the problem continues, replace the system board and repeat the problem

isolation procedures.

If the problem has not been corrected, test each controller or option board

by turning off the system, removing a board and turning the power back on.

If the LED is still not on, test each video and storage device by turning off

the system, disconnecting the device power cable and then turning on the

system.

When the system LED lights, power off the system and replace the defective

subassembly.

NOTE: For removal and replacement procedures, refer to Chapter 7.

5. Check the screen for a blinking cursor. Do you see a cursor on the

screen?

YES: Proceed to step 6.

NO: Listen for an audible tone (beep) from the system speaker.

If you hear one or two short beeps, POST is complete. The system now boots

the DIAGNOSTICS program. If the screen remains blank, adjust the brightness

knob.

If the display screen remains blank after adjusting the brightness knob, the

video display unit subsystem is not functioning properly.

o If a color graphics or composite video monitor is available, connect

either device to the correct video outputs on the video display controller

board. Using the CTRL + ALT + < command, change the display mode to the

graphics mode.

If the first screen of the DIAGNOSTICS program appears on the external

monitor, replace the internal video display unit.

If the screen on the external monitor is blank, replace the video display

controller board.

o If a color graphics or composite video monitor is not available, replace

the video display controller board.

o If a color graphics or composite video monitor is not available and

replacing the video display controller board does not solve the problem,

replace the internal video display unit.

If you do not hear a beep, replace the system board. If you hear any other

audible sounds, refer to Chapter 5 for more information on POST related error

messages.

6. Did the cursor disappear from the screen, replaced by the number of Kbytes

(shown in increments) on the display screen?

YES: This indicates the memory self test portion of POST. Proceed to

step 7.

NO: Replace the system board. Restart the system problem isolation

procedures.

7. Did the LEDs on the mass storage device flash, followed by one or two

short beeps?

YES: This indicates that POST and the SETUP utility have completed

successfully. The DIAGNOSTICS program should then boot and the

DIAGNOSTICS menu should appear on the display screen.

Refer to Chapter 4 for additional information on the COMPAQ

DIAGNOSTICS program.

NO: If the cursor reappears and remains on the screen, replace

the system board.

If one audible tone is heard and an error message appears, the SETUP

function was not completed on the system. Press the F1 key and

proceed to Chapter 3 in this guide for information on the SETUP

function.

Table des matières

Autres manuels Compaq Ordinateur de bureau

Compaq

Compaq 239158-999 - Mini Tower - Power Supply 250... Mode d’emploi

Compaq

Compaq Compaq Presario Manuel utilisateur

Compaq

Compaq 3000R - ProLiant - 128 MB RAM Guide de l'utilisateur

Compaq

Compaq Evo D510 e-pc Manuel du produit

Compaq

Compaq 5000 - Professional - 32 MB RAM Manuel

Compaq

Compaq 3000R - ProLiant - 128 MB RAM Guide de démarrage rapide

Compaq

Compaq Presario 4000 Series Manuel utilisateur

Compaq

Compaq AlphaServer ES40 Guide de démarrage rapide

Compaq

Compaq 5461 - Presario - 64 MB RAM Manuel utilisateur

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Mode d'emploi

Compaq

Compaq D310v - Evo - 256 MB RAM Manuel utilisateur

Compaq

Compaq PC938A Manuel utilisateur

Compaq

Compaq dx2040 - Microtower PC Manuel utilisateur

Compaq

Compaq AP750 - Professional - 256 MB RAM Instructions d'utilisation et d'entretien

Compaq

Compaq Presario 6500 - Desktop PC Manuel utilisateur

Compaq

Compaq Presario 5600 Series Manuel utilisateur

Compaq

Compaq Presario SR1700 - Desktop PC Manuel utilisateur

Compaq

Compaq Professional XP1000 Instructions d'utilisation

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Manuel technique

Compaq

Compaq Compaq Presario Manuel utilisateur

Compaq

Compaq CQ2009F - 1 GB RAM Manuel utilisateur

Compaq

Compaq Deskpro EXS Manuel d'utilisation et d'entretien

Compaq

Compaq AP200 - Professional - 128 MB RAM Manuel utilisateur

Compaq

Compaq 6005 - Pro Microtower PC Mode d’emploi

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
