Comnet CNGE2FE8MSPOE2 Manuel utilisateur

INSTALLATION AND OPERATION MANUAL

CNGE2FE8MSPOE2

MANAGED ETHERNET SWITCH WITH (8) 10/100 BASE-TX

+ (2) 10/100/1000 BASE-TX/FX COMBO PORTS

AND POWER OVER ETHERNET (POE)

The ComNet™CNGE2FE8MSPOE2 is a hardened Managed Ethernet Switch. It

provides IEEE 802.3af (15W) PoE to eight 10/100BASE-T(X) ports and has two-

gigabit combination SFP or RJ-45 ports. Up to 120 watts of PoE power is available

for distribution across all 8 TX ports. All SFP ports utilize ComNet SFP* modules for

fiber and connector type and distance. The CNGE2FE8MSPOE2 is a redundant switch

offering multiple Ethernet redundancy protocols, C-Ring (recovery time <10ms over

250 units of connection), ComRing, and MSTP/RSTP/STP (IEEE 802.1 s/w/D). This

redundancyfeatureprotectsyourapplicationsfromnetworkinterruptionsortemporary

malfunctions by redirecting transmission within the network. Network management

is supported by eConsole, a powerful, easy-to-use Windows-based utility, as well as

Web-based telnet, and Console (CLI) configurations. This environmentally hardened

switch is designed for direct deployment in difficult out-of-plant or roadside operating

environments.

Rev. 4.23.14

INS_CNGE2FE8MSPOE2_REV–

12/20/12 PAGE 2

INSTALLATION AND OPERATION MANUAL CNGE2FE8MSPOE2

TECH SUPPORT: 1.888.678.9427

Contents

Regulatory Compliance Statement 6

Warranty 6

Disclaimer 6

Safety Information 6

Overview 7

Introduction 7

Software Features 8

Hardware Features 9

Safety Indications 9

Hardware Installation 10

Installing Switch on DIN-Rail 10

Mount Series on DIN-Rail 11

Wall Mounting Installation 12

Mounting the CNGE2FE8MSPOE2 on a Wall 12

Hardware Overview 13

Front Panel 13

Front Panel LEDs 15

Top view Panel 16

Rear Panel 17

Cables 18

Ethernet Cables 18

100BASE-T(X) Pin Assignments 18

SFP 20

Console Port Cable 20

WEB Management 22

Configuration by Web Browser 22

About Web-based Management 22

Preparing for Web Management 23

System Login 23

Main Interface 24

INS_CNGE2FE8MSPOE2_REV–

12/20/12 PAGE 3

INSTALLATION AND OPERATION MANUAL CNGE2FE8MSPOE2

TECH SUPPORT: 1.888.678.9427

System Information 24

Enable Location Alert 24

Basic setting 25

Switch Setting 25

Admin & Password 25

IP Setting 26

Time Setting 27

PTP Client 29

LLDP 29

Auto Provision 30

Backup & Restore 31

Upgrade Firmware 31

Redundancy 32

C-Ring 32

Legacy Ring 34

COM-Ring 35

C-RSTP 36

RSTP 37

RSTP setting 37

MSTP 40

Multicast 44

Static Multicast Filtering 45

Port Setting 46

Port Control 46

Port Status 47

Rate Limit 47

Port Trunk 48

Port Trunk – Setting 48

Port Trunk – Status 49

VLAN 49

VLAN Setting - IEEE 802.1Q 49

Traffic Prioritization 51

Qos policy 51

Port-base priority 52

COS/802.1p 53

TOS/DSCP 54

INS_CNGE2FE8MSPOE2_REV–

12/20/12 PAGE 4

INSTALLATION AND OPERATION MANUAL CNGE2FE8MSPOE2

TECH SUPPORT: 1.888.678.9427

DHCP Server 55

DHCP Server – Setting 55

DHCP Server – Client List 56

DHCP Server – Port and IP bindings 56

DHCP Server –DHCP Relay Agent 57

SNMP 58

SNMP – Agent Setting 58

SNMPV3 59

SNMP –Trap Setting 60

Security 61

Management Security 61

Static MAC Forwarding 62

MAC Blacklist 63

802.1x 64

802.1x - Radius Server 64

802.1x-Port Authorized Mode 66

802.1x-Port Authorized Mode 67

TACACS+ 67

Warning 68

Monitor and Diag 71

System Event Log 71

MAC Address Table 72

Port Overview 73

Port Monitoring 74

Power over Ethernet (PoE) 75

System setting 75

Power over Ethernet - Port Control 76

Port Status 77

Save Configuration 78

Factory Default 78

System Reboot 78

Command Line Interface Management 79

About CLI Management 79

CLI Management by Telnet. 82

Commands Level 83

Symbol of Command Level. 84

INS_CNGE2FE8MSPOE2_REV–

12/20/12 PAGE 5

INSTALLATION AND OPERATION MANUAL CNGE2FE8MSPOE2

TECH SUPPORT: 1.888.678.9427

Commands Set List—System Commands Set 84

Commands Set List—Port Commands Set 86

Commands Set List—Trunk command set 88

Commands Set List—VLAN command set 89

Commands Set List—Spanning Tree command set 90

Commands Set List—QoS command set 91

Commands Set List—IGMP command set 92

Commands Set List—MAC/Filter Table command set 93

Commands Set List—SNMP command set 94

Commands Set List—Port Mirroring command set 95

Commands Set List—802.1x command set 96

Commands Set List—TFTP command set 97

Commands Set List—SYSLOG, SMTP, EVENT command set 97

Commands Set List—SNTP command set 99

Commands Set List — C-Ring command set 100

Technical Specifications 101

INS_CNGE2FE8MSPOE2_REV–

12/20/12 PAGE 6

INSTALLATION AND OPERATION MANUAL CNGE2FE8MSPOE2

TECH SUPPORT: 1.888.678.9427

Regulatory Compliance Statement

Product(s) associated with this publication complies/comply with all applicable regulations. Please

refer to the Technical Specifications section for more details.

Warranty

ComNet warrants that all ComNet products are free from defects in material and workmanship

for a specified warranty period from the invoice date for the life of the installation. ComNet will

repair or replace products found by ComNet to be defective within this warranty period, with

shipment expenses apportioned by ComNet and the distributor. This warranty does not cover

product modifications or repairs done by persons other than ComNet-approved personnel, and

this warranty does not apply to ComNet products that are misused, abused, improperly installed,

or damaged by accidents.

Please refer to the Technical Specifications section for the actual warranty period(s) of the

product(s) associated with this publication.

Disclaimer

Information in this publication is intended to be accurate. ComNet shall not be responsible for its

use or infringements on third-parties as a result of its use. There may occasionally be unintentional

errors on this publication. ComNet reserves the right to revise the contents of this publication

without notice.

Safety Information

»Only ComNet service personnel can service the equipment. Please contact ComNet Technical

Support.

»The equipment should be installed in locations with controlled access, or other means of

security, and controlled by persons of authority.

INS_CNGE2FE8MSPOE2_REV–

12/20/12 PAGE 7

INSTALLATION AND OPERATION MANUAL CNGE2FE8MSPOE2

TECH SUPPORT: 1.888.678.9427

Overview

Introduction

The CNGE2FE8MSPOE2 is a powerful managed industrial Ethernet switch containing many unique

features. These switches can work under a wide temperature range, dusty environment and humid

condition.

CNGE2FE8MSPOE2 supports PoE or Power over Ethernet, a system to transmit electrical power

with data to remote devices over standard twisted-pair cable. CNGE2FE8MSPOE2 has 8 X

10/100BASE-T(X) PSE (Power Sourcing Equipment) ports that are fully compliant with IEEE802.3af

standard.

WEB-based, TELNET, Console port or other third-party SNMP software can manage the

CNGE2FE8MSPOE2 as well. The switch can be managed by a useful utility called eConsole.

eConsole is powerful network management software. With its user-friendly and powerful interface,

multiple switches can be easily configured at the same time, and switches’ statuses monitored.

INS_CNGE2FE8MSPOE2_REV–

12/20/12 PAGE 8

INSTALLATION AND OPERATION MANUAL CNGE2FE8MSPOE2

TECH SUPPORT: 1.888.678.9427

Software Features

»World’s fastest Redundant Ethernet Ring: C-Ring (Recovery time <10ms over 250 units

connection)

»Supports Ring Coupling, Dual Homing over C-Ring

»Supports SNMPv1/v2/v3 & RMON & Port base/802.1Q VLAN Network Management

»Event notification by Email, SNMP trap and Relay Output

»Web-based, Telnet, Console, CLI configuration

»Enable/disable ports, MAC based port security

»Port based network access control (802.1x)

»VLAN (802.1Q) to segregate and secure network traffic

»Radius centralized password management

»SNMPv3 encrypted authentication and access security

»RSTP (802.1w)

»Quality of Service (802.1p) for real-time traffic

»VLAN (802.1Q) with double tagging and GVRP supported

»IGMP Snooping for multicast filtering

»Port configuration, status, statistics, mirroring, security

»Remote Monitoring (RMON)

INS_CNGE2FE8MSPOE2_REV–

12/20/12 PAGE 9

INSTALLATION AND OPERATION MANUAL CNGE2FE8MSPOE2

TECH SUPPORT: 1.888.678.9427

Hardware Features

»Two Redundant DC power inputs (48–57VDC)

»Wide Operating Temperature Range: -40 to +75ºC

»Storage Temperature Range: -40 to +85ºC

»Operating Humidity: 5% to 95%, non-condensing

»Casing: Aluminum

»10/100BASE-T(X) Ethernet port

»10/100/1000BASE-T(X) Gigabit Ethernet port (combo)

»100/1000BASE-X on SFP port (combo)

»Console Port

»Dimensions (W × D × H):74.3mm × 109.2mm × 153.6mm

Safety Indications

Only ComNet service personnel can service the equipment. Please contact ComNet Technical

Support if your unit requires service.

The equipment should be installed in locations with controlled access, or other means of security,

and controlled by persons of authority.

INS_CNGE2FE8MSPOE2_REV–

12/20/12 PAGE 10

INSTALLATION AND OPERATION MANUAL CNGE2FE8MSPOE2

TECH SUPPORT: 1.888.678.9427

Hardware Installation

Installing Switch on DIN-Rail

Each switch has a Din-Rail kit on the rear panel. The DIN-Rail kit affixes the switch to the DIN-Rail.

It is easy to install the switch on the Din-Rail:

Metal Spring
