Installation Instruction for CMAX Antennas

Installation Guide for CMAX-DM20/DM22S/DM30/

DM60-xxx Antennas

Note: Please read the complete description before starting the installation. Be sure that

connectors are properly sealed from water if no cables are connected to them

after installation.

1.Assembly

Fit the 3 parts together and fasten with screws M8 x 16, washers, and spring washers

(M8 torque: 27 N-m)

Tools required:

Wrench, width: 13 mm

Washer

Spring washer

Screw

Installation Instruction for CMAX Antennas

Page 2 M0149A7D_Installation_CMAX-DMxx-Antennas

2.Wall Mounting

1. Mark 4 holes onto the wall as shown in the drawing above.

2. Drill 4 holes into the wall and insert appropriate dowels into holes.

3. Attach the antenna pedestal.

Installation Instruction for CMAX Antennas

3.Pole Mounting

3.1. Pole Mounting with Lashing Straps (suggestion)

Note: This pole mounting procedure is for reference only. Other than the shown pole

mounting material can be used to mount bracket and antenna to a pole. Make

sure the installation will safely support the combined load of the bracket, antenna,

and connected cables.

1. Lay proper lashing straps around pole and lead them through mounting bracket.

2. Adjust bracket in antenna direction and fasten bracket.

3.2. Optional Pole Mounting Kit

Optionally, a pole-mounting kit can be ordered separately from the supplier (ID 7814722).

The recommended pole diameter for this mounting kit is 60 - 150 mm. To mount an antenna

to a pole using this kit, proceed as follows:

1. Insert the four bolts M8x200 (2) with four of the filet washers (5) into the antenna

mounting bracket (see detailed illustration of bolt head)

2. Insert the pole mounting bracket into these four bolts and place the filet & spring

washers (4 & 5) and the M8 nuts (3) over each bolt (detailed illustration).

3. Tighten the four M8 nuts observing the specified torque of 27 Nm.

4. Hang in the safety wire (6) and attach it to a suitable structure for fall protection.

Lashing

Straps

Antenna

Pedastal

Pole

200 mm max.

Installation Instruction for CMAX Antennas

Page 4 M0149A7D_Installation_CMAX-DMxx-Antennas

4.Antenna Mounting

4.1. DM60 Antenna Mounting

Attach antenna and

fasten it with washers

and M8 nuts (M8

torque: 27 N-m)

4.2. DM20/DM22S/DM30 Antenna Mounting

Depending on space available

and adjusting angle, the

DM20/DM22S/

DM30 antenna

can be mounted onto the

pedestal in 3 alternatives (see

circle marks in picture to the left-

hand side).

4.3. Azimuth angle

Loosen the 3 fixing screws.

(Do NOT unscrew them

completely.)

Adjust your desired angle.

The complete antenna

pedestal can be swiveled to

the left- / right-hand side by

up to 55°.

3. Tighten the fixing screws.

Spring

Washer

M8 nut

Washer

Installation Instruction for CMAX Antennas

4.4. Elevation Angle

Loosen the 4 fixing

screws at the left- and

right-

hand side. (Do

NOT unscrew them

completely.)

Adjust your desired

angle.

3. Tighten fixing screws.

4.5. Antenna Cable

Connected antenna cables

can be arranged and fixed

with cable ties as shown.

Installation Instruction for CMAX Antennas

Page 6 M0149A7D_Installation_CMAX-DMxx-Antennas

4.6. Outdoor installation

Note: For outdoor use, we recommend removing the plugs from the drain holes if the

antenna is exposed to high humidity or rainfall.

: Do not remove the plugs if the antenna is mounted other than bottom down,

that means the drain holes showing to the ground. For the top and bottom of the antenna

observe the arrow labeling at the rear side. Otherwise water might penetrate into and

therefore damage the antenna.

Remove the plugs from the drain holes at the bottom of the antenna with a knife or a flat

screwdriver. The below indicates the location of the drain holes, design and/or size of the

antenna may be different.

List of Changes

Version

Changes

Release Date

M0149A7A

Initial Release

29-March-2016

M0149A7B

- chapter 0updated, Note on pole mounting

20-April-2017

M0149A7C

- DM22S added to title and in chapter 4.2

02-October-2017

M0149A7D

- New pole mounting kit added in chapter 0

04-September-2018

All information contained in this manual has been revised thoroughly. Yet CommScope accepts no liability for any omissions or faults.

CommScope reserves the right to change all hardware and software characteristics without notice.

Names of products mentioned herein are used for identification purposes only and may be trademarks and / or registered trademarks of

their respective companies.

No parts of this publication may be reproduced, stored in a retrieval system, transmitted in any form or by any means, electronical,

mechanical photocopying, recording or otherwise, without prior written permission of the publisher.

CommScope, 04-September-2018
