Comeup CP-500T Manuel utilisateur

Electric Winch

Model:CP-500T

PN: 155760 380V50Hz 157799 415V50Hz 153440 440V60Hz

158842 415V50Hz 931093 380V60Hz

Introduction

Feature

Lifting capacity:

500 kg at wire rope top layer

Lifting height:

58 m

Lifting speed:

12~18 m/min at 50Hz ; 14~22m/min at 60Hz

Brake:

Electromagnetic spring-applied failsafe brake

Control:

Pendant switch powers the winch

Unpacking

．Winch assembly

1pc

．Wire rope 7 mm x 60 m

1pc

．Weight hook CHW-0005

1pc

．Pendant switch CPB-213 w/cord 3.5 mm2

x 5C x 6 m

1pc

．PN 158842 excludes remote control Part No.19

Read this manual carefully

You should carefully read and understand this manual before operating it.

Careless winch operation may result in personal injury hazards or property

damage.

Information requesting or parts ordering

Please specify the followings information:

．Winch PN

．Serial number

．Part description

．Replacement part number

．Quantity for each part

Installation

Before using the winch, make sure all electrical components have no

corrosion or damaged; the environment should be clear and dry.

Performance

Wiring Diagram

Winch Model

CP-500T

Motor

kw x p

1.8 x 4

Recommend

Wire Rope

Size (mm)

Breaking (kg)

2,700

1st

Layer

Rated Load

(kg)

50Hz

757

2nd

Layer

Rated Load

(kg)

50Hz

671

3rd

Layer

Rated Load

(kg)

50Hz

602

60Hz

Speed

(m/min)

50Hz

Speed

(m/min)

50Hz

13.4

Speed

(M/min)

50Hz

14.9

60Hz

17.8

Rope-Winding Cumulating

Sum (m)

Rope-Winding Cumulating

Sum (m)

Rope-Winding Cumulating

Sum (m)

4th

Layer

Rated Load

(kg)

50Hz

546

5th

Layer

Rated Load

(kg)

50Hz

500

60Hz

Speed

(m/min)

50Hz

16.4

Speed

(m/min)

50Hz

60Hz

19.6

60Hz

Rope-Winding Cumulating

Sum (m)

Rope-Winding Cumulating

Sum (m)

Warning

．The winch is not intended to be used in any manner for the movement or

lifting of personnel.

．The lifting capacity shown is based on the top layer of rope on the drum.

．The rope winding on the drum shall remain 5 wraps from the drum.

Parts List

Item No.

Description

Part No

Qty

Induction motor kit 380V

880459

Induction motor kit 415V

880460

Induction motor kit 380V/60Hz

880457

Control box

880957

Bridge rectifier CBR-072

880425

Support bracket

880426

Drum kit

880427

6-1

Tie bar

880428

6-2

Tie bar kit

880429

6-3

Tie bar kit

880430

2nd shaft kit

880431

Gear box kit

880432

1st stage carrier

881301

1st shaft kit

881302

Conductor kit

880435

Brake coil

880436

Conductor plate A

880438

Brake disc

880379

Hex socket

880440

Conductor plate A kit

880437

Brake cover

880442

Wire rope w/weight hook

880443

Remote control, CPB-213

880387

Winch Assembly
