Coffee Queen TOWER Manuel utilisateur
Yourretaildealer
U / GB
Rev080522
...............................................................................
...............................................................................
COFFEE QUEEN
Tower 10 litre for wall mounting
Usermanual
2.
1. Tableofcontents page 2
2. General 3
3. Functiondescription,general 3
4. Startup,general 3
5. Overviewofcomponents 4
5. Overviewoperationbuttons 5
6. Indicationswhenbrewing 5
7. Installationandstart 6-9
8. Operationinstructions,brewing 10-13
9. Maintenanceandcleaning 14-15
10. Important! 15
11. Programming 16
12. Error message 17
13. Contemplateduseandwarnings 18
15. DimensionsketchwallTower 19-20
16. Dimensionsketchservingstation 5L 21
1. Table of contents Tower wall mounting
3.
2. General. Tower wall mounting
Coffee Queen TOWER wall mounting
Wecongratulatetoyourchoice of coffee machine.
Thebrewerisequipedwithfullandhalfbrewfunction.andaseparateoutlet for hot water.
Tower is delivered with a brew unit, 2 serving stationsandfilterholders.servingtrolley,
wallbracketwithscrews( 6 adjustable feets).
Coffee Queen AB is certified ISO 9001 and 14001
and therefore a minimal stress of the enviroment.
3. Function description - General
TOWER bulk brewer
Coffeebrewer with automatic water supply.
Itisalso equipped with a separateoutlet forhotwater.
Brewingtakesplacein removable serving stations.
Brewingis carried out in paper filters. (filter523).
Brew time for 5 ltrs. approx. 7min.
4. Start up - General
Turnonthemain switch(A).
Themachinewill now fill and startheatingwater.
Machineisreadyforbrewingwhen display lights up
andthecorrecttemperaturehasbeenreached. (A)
4.
5. Overview of components. Tower wall mounting
Lid
Handle
Level tube
Tap for coffee
Display
Filter holder
Level tube
Serving
station
Tap for
coffee
ON / OFF-switch
Drip tray
Drip tray insert
Functions key
Serving trolley
Lockable wheels
Tap for
hot water
Wall bracket
5. Overview operating buttons. Tower wall mounting
1/1 Brewing
Fullbrew 5,0litre
1/2 Brewing
Halfbrew 2,5litre
PAUSE / STOP
1/1 Brewing
Fullbrew 5,0litre
1/2 Brewing
Halfbrew 2,5litre
PAUSE / STOP
5.
6. Indications, Brewing. Tower.
Whenmachineis
brewingFullbrew
Displaywillshow:seeA
Whenmachineis
brewingHalfbrew
Display will show: see B
A
B
6.
7. INSTALLATION AND START - Tower for wall mounting
7.1 Installationofwallconsole forwall-mountedTower.
7.2 IMPORTANT!
Thebrewingunit’swallconsolemustbeinstalledbyatrainedand authorised individual.
Improperinstallationmaycausethebrewingunit to come loose and result in personal injury
ormaterialdamage or cause it toslant,whichwill impair the proper functioningofthe
machine.Aspiritlevelshouldbeusedto install the wall console, to ensure the machine’s
safeandproperfunctioning.Becausethere are many different types of wall materials,
screwsforwallmountingdonotcomefactorysupplied.
Contactyourlocalretailerforadviceonsuitable screw systems,
Mounting height = 640 mm fromthebottom edge of theconsoleto the floor.
The brewing distance shouldbeapprox. 17 mm betweenthefilter holder and the
servingstation.
approx.
17mm
7.
7. INSTALLATION AND START - Tower for wall-mounting
7.3 Mounting of wall console for wall-mounted Tower.
INSTALLATIONINSTRUCTIONS
INSTALLATION ON CONCRETE OR STONE WALL:
1.Markanddrillholes.The holes should be largeenoughforawallplugandscrew.
2.Placethewallplugin the holes and use the screws toscrewthewallconsoleto the wall
INSTALLATION ON WOODEN WALL:
1.Markanddrillholes.
2.Screwthewallconsole to the wall with the appropriate screws.
90°90°
8.
7. INSTALLATION AND START - Tower for wall-mounting.
7.4 Mounting the brewing unit on the wall console.
1. Mountthemetalcasing(A)onthewallconsole.
2. Positionthebrewing unit and screw tothewallusing the 4 screws provided(B).
Seefigure.
3. Screwonthe brewing unit’s upper section with theavailablescrews(C).
AA
B
B
BBB
C
C
C
C
A
C
C
B
9.
7. Installation and start. Tower for wall-mounting.
7.5. Connectthebrewer unit to acoldwater feed -1/2"R withconnectiontube supplied.
NOTE! Thenewhoseset supplied with the appliance shallbeusedandthat old hose
setsshallnot be reused.Connectiontoa closable valve is recommended.
Min.waterpressure; 2bar(200kPa). Max. waterpressure; 8bar (800kPa).
Watersupply to themachineis the customer’sresponsibility according to
instructionandadvicefrom the supplier.
In areas with high level lime problem, a descaling filter should be mounted.
7.6. Electrical connection;
Thebrewerisnotreconnectableandmayonlybeinstalledtotheelectricsupplynetwork
withavoltagethat is stated on the brewer andshallbecarriedout by an authorized
electrician.
Recommended:Installalinecircuitbreaker and a earth fault breaker to the machine.
CAUTION! Connectiontoa separate 3 phase only
-Brewershould be connected to 380Vwith Zero and earth.
- Use 16Amp fuses.
IMPORTANT!
Electricalinstallationsmustbe done of an certificatedelectrician.
380 V 3 - phase + Zero + ground 9000W
8. Operating instructions. (Brewing coffee) Tower for wall-mounting.
8.1. Startting up machine.
TurnontheswitchA.
Themachinewill now starts filling water .
A
Display shows:
Placeafilterin the filter holder.
Filter type 523 for 5Litre.
8.3. Place a filter in the filter holder.
Use Coffee Queen´s recommended coffee filter
Filter type 523 for 5Litre. Article no. 110102 - 02
8.2. Machine starts heating water.
Whilemachineisheatingthewater, display
isblinking.
Whenwaterhas reached the right temperature.
Displaywilllightup.
Machine is now ready to brew.
10.
