CNC4PC C34G320X Manuel utilisateur

USER’S

MANUAL

VER. 2

C34G320X BOARD

Rev. 6

JUNE 2018

User’s Manual Page i

USER'S MANUAL

TABLE OF CONTENTS

Contents page#

1.0 OVERVIEW.....................................................................................................................1

2.0 FEATURES.....................................................................................................................1

3.0 BOARD DESCRIPTION..................................................................................................1

4.0 JUMPER TO SELECT (REQ OR NOT REQ)..................................................................2

5.0 JUMPER TO SELECT THE ENABLE.............................................................................3

6.0 PINOUT...........................................................................................................................4

7.0 DIMENSION....................................................................................................................5

User’s Manual Page 1

1.0 OVERVIEW

This board simplifies connecting Gecko G320/340, and G320X Stepper Drivers to RJ45

connector boards, such as the C32, C62, C76, M16 and C82 boards. As just a regular

twisted pair RJ45 cable needs to be used.

2.0 FEATURES

•Pin Header of 8 pins for Connection of Driver.

•RJ45 Connector for the axes.

•RJ45 Connector for encoders

•Terminals to power the encoder

3.0 BOARD DESCRIPTION

User’s Manual Page 2

4.0 JUMPER TO SELECT (REQ OR NOT REQ)

If using an encoder that demands less of 50mA and external power supply is not required, set

jumper to the not required position.

NOT REQ

Otherwise, add and external power supply and set the jumper to REQUIRED.

REQ

User’s Manual Page 3

5.0 JUMPER TO SELECT THE ENABLE

The drivers can be set to be enabled by the board only while the system is active. For

this set the jumper to SOFT ENABLE.

SOFT ENABLE

Hardware Enable will keep the driver enabled all the time.

HARD ENABLE

WIRING SAMPLE

http://cnc4pc.com/Tech_Docs/WS_37.pdf

Note: This wiring is just to illustrate a sample product application. Specific wiring may

vary from system to system. It is the user’s responsibility to implement it correctly.

User’s Manual Page 4

6.0 PINOUT

STEP and DIR RJ45

PIN RJ45

FUNCTION

NOT USED

STEP

NOT USED

GND

ERR/RES

DIR

NOT USED

ENCODER RJ45

PIN RJ45

FUNCTION

GND

NOT USED

A+

NOT USED

B+

User’s Manual Page 5

7.0 DIMENSION

All dimensions are in Millimeters.

DISCLAIMER

Use caution. CNC machines can be dangerous machines. Neither DUNCAN USA, LLC

nor Arturo Duncan are liable for any accidents resulting from the improper use of these

devices. This board is not a fail-safe device and it should not be used in life support

systems or in other devices where its failure or possible erratic operation could cause

property damage, bodily injury or loss of life.
