ClearCube Thin Client CD8831 Manuel utilisateur
CD8831 Thin Client
ClearCube Technology, Inc.
www.clearcube.com
(866) 652-3500
1 of 5
Front
Overview
Package
Contents
•CD8831 thin client
•Power adapter and power cable
Continued on next page
Rear
Thin Client
Features
The pictures below show CD8831 thin client features.
Power Button
USB 2.0 Ports
Audio In
Audio Out
RJ45 LAN Port
USB 2.0 Ports
USB 3.0 Ports
DVI-I
DVI-D
DC Jack
CD8831 Thin Client
ClearCube Technology, Inc.
www.clearcube.com
(866) 652-3500
2 of 5
Network Infrastructure
Ethernet
Thin Client with
Monitors and
Peripherals
Chassis with
Blades
and VMs
Overview, Continued
Thin Client
Architecture
Overview
A thin client is a remote computing device that connects a user’s monitors, keyboard,
mouse, speakers, and other peripherals to remote PC blades (computers) and to
virtual desktops (VMs). As shown below, computing resources are typically located
in remote data centers.
Using a remote connection protocol, thin clients enable users to work on a blade or
VM as if it is a local PC. See the documentation for the remote protocol application
that you use for additional information.
CD8831 Thin Client
ClearCube Technology, Inc.
www.clearcube.com
(866) 652-3500
3 of 5
Thin Client Setup
Safety and
Precautions
•Always mount the thin client vertically.
•Do not install the thin client in areas where it can become wet or be
exposed to water.
•Only use the power cord shipped with the thinclient.
•Ensure there is four inches of space surrounding the thin client.
Inadequate ventilation can damage thedevice.
Setting up a
Thin Client
The steps below show how to set up a thin client.
Step
Action
1
Carefully unpack the thin client and components. Ensure that you
have the following items:
•Power cord and adapter (included)
•USB mouse
•USB keyboard
•DVI-D monitor, DVI-I monitor, or both
2
Place the thin client vertically as shown on page 1.
3
Connect a USB keyboard and mouse to the thin client.
4
Connect an Ethernet cable to the Ethernet port on the rear of the thin
client and to the Ethernet port on the remote compute device or
network device.
5
Optionally, connect any peripherals to the thin client. If you
purchased a thin client with an internal WLAN card, attach the
included antenna to the rear of thin client.
CD8831 Thin Client
ClearCube Technology, Inc.
www.clearcube.com
(866) 652-3500
4 of 5
NOTE: Change administrator password immediately after logging in. You can
specify a new password using the Configuration Wizard.
Thin Client Setup, Continued
Setting up a
Thin Client
(continued)
You can now use remote connection software to connect to a remote computing device.
BIOS Hotkey
To access the BIOS, press the ESC key when prompted as the ClearCube splash
screen appears.
User Accounts Depending on configuration, thin clients include a Windows operating systemor
ClearCube Cloud Desktop OS.
Windows:
The thin client boots to the Administrator user account. The default Administrator
password is admin. The default user password is user.
NOTE: Change administrator and user passwords immediately after loggingin.
Cloud Desktop OS:
The thin client boots to the user account and displays the Configuration Wizard the
first time you power on the thin client. The default password is admin (case-sensitive).
Step
Action
6
Connect the included power cord and AC adapter, and then plug the
adapter into the rear of the thin client. Continue by plugging the power
cord into an AC power outlet.
7
Power on the thin client by pressing the power button on the front of
the thin client.
CD8831 Thin Client
ClearCube Technology, Inc.
www.clearcube.com
(866) 652-3500
5 of 5
WEEE Disposal Guidelines
In the European Union, this electronic product falls under the European Directive (2002/96/EC) WEEE. When
it reaches the end of its useful life or is no longer wanted, dispose of it at an approved, designated recycling
or treatment facility. Check with your local authorities for proper disposal instructions. For assistance, contact
Resources and Support
Additional
Information
CD8831 User Guide shows how to configure, operate, and troubleshoot the
CD8831 Thin Client.
Cloud Desktop OS Quick Start Guide describes how to configure, use, and deploy
the Cloud Desktop operating system. All product documentation is available from
the ClearCube Support site (see address below).
Contacting
Support
Website: www.clearcube.com/support
Email: support@clearcube.com
Phone: (512) 652-3400
Toll-free: (866) 652-3400
