Citaq H7 Manuel utilisateur
POSSystem
ModelName:H7
productManual
Pleasereadthismanualcarefullybeforeusingdevice.
Orvisitourwebsite:
www.citaq.com
Thankyouforusingourproducts!
ATTENTION
ThisisaClassBproduct.Inalivingenvironment,thisproduct
maycauseradiointerference.Inthiscase,theusermayneedto
takeadequatemeasures.
Thisdevicecomplieswithpart15oftheFCCRules.Operationis
subjecttothefollowingtwoconditions:
(1) Thisdevicemaynotcauseharmfulinterference,and
(2) Thisdevicemustacceptanyinterference
received,includinginterferencethatmaycauseundesired
operation.
Replacingwitherrorbatterymaycauseexplosion!
Replacedoldbatteryshouldbehandedovertotherepairmanfor
disposal!Donotputthemintofire!
ThereisaLithiumbatteryinthedevice.Itsvoltagewilldecline
ifitisnotturnedonforlongtime.Itwillevenstopworkingifthe
batteryvolumewasexhausted.Sothedevicerequirestobe
chargedatleastin2months.
Ifthereisanyproblemduringinstallationoranyconfusion
aboutthismanual,pleasesendemailtoourcustomersupport
department:
Therewillbeprofessionalexpertstohelpyou!
Kindlyfindbelowitemswhenopeningcarton
ITEMLIST
Device1unit
Thermalpape1roll
Adaptor1pc
Powercore1pc
Manual1pc
Twistedring1pc
Desiccative2bags
NameConfigurationRemark
CPUARMCortexA9quadcore1.8GHz
RAM1GB
ROM4GB
StorageMax32G
OSAndroid4.4.4
Display1024*768
TouchScreenCapacitivemulti‐touch
Bluetooth2.1/4.0supproted
SpeakerStereo2W
IndicatorlightProgrammableorangeandblue
3GOptionalembeddedWCDMA3G
WiFiwifi802.1b/g/n
2
NameConfigurationRemark
Printer80mmThermalprinter
PrintingSpeedMAX20mm/s
PrintingSpan200km
Sensoroutofpaper,coveropen
Cuttingtimes2milliontimes
cuttingwayhalfcut/fullcut
PowersupplyDC24V/2.5Ainput
Ports
3XUSB1XRS2321XLAN1XRJ11
forCashdrawer
COM
RJ11‐4P4C,RS232,+5V、RXD、TXD、
GND
LANRJ45,10/100M
Audiojack
3.5mmstandardaudiojack,4
phaseswithMIC.
not
available
onV8
Working
Environment
Temperature
0℃‐50 ℃Humidity10%‐90%
Non‐condensation
Storage
Environment
Tempe rature
‐10℃–60℃Humidity10%‐90%,
Non‐condensation
3
ProductSummarization(H7)
Installationofpowersupply
Pleaseconnectasperabovepicshows.
Touc hScre e n
li
g
ht
CoverliftSideUSB
Powerswitch
LAN
2USBPower
Adapter
RJ11
RS232
4
Installthethermalpaper
Step1：Takeoutarollofpaperandliftthecover.
Step2：Putthepaperinsidethegrooveandpulloutthepaper
tothefeederedge.
InstalltheSimcardandTFCard
Step1:Unscrewtheplasticcover
Step2:InserttheSimcardandTFcardtocorrespondingslot
Step3:Installthecover
SIMCard
TFCard
5
WallmountingInstallation
Step1.Asuitableflatwallshouldberequiredforinstalling
fixture.Installthe4screwsthatfixingthebracketonthewall,
andinstallthe4screwsthatembeddingtheequipmentonthe
metalbaseboard
Step2Puttheequipmentthatinstalledwith4Screwsinto
thefixationblock.
Dimension
Unit:mm
6
ProductSummarization(V8)
Installationofpowersupply
Pleaseconnectasperabovepicshows.
Touc hScre e n
li
g
ht
CoverliftSideUSB
Powerswitch
LAN
2USB Power
Adapter
RJ11
RS232
7
Installthethermalpaper
Step1：Takeoutarollofpaperandliftthecover.
Step2：Putthepaperinsidethegrooveandpulloutthepaper
tothefeederedge.
InstalltheSimcardandTFCard
Step1:Unscrewtheplasticcover
Step2:InserttheSimcardandTFcardtocorrespondingslot
Step3:Installthecover
SIMCard
TFCard
8
WallmountingInstallation
Step1.Asuitableflatwallshouldberequiredforinstalling
fixture.Installthe4screwsthatfixingthebracketonthewall,
andinstallthe4screwsthatembeddingtheequipmentonthe
metalbaseboard
Step2Puttheequipmentthatinstalledwith4Screwsinto
thefixationblock.
Dimension
Unit:mm
9
