Cisco Linksys WRV54G Manuel utilisateur

Model No.

Product Data

Wireless

WRV54G (UK/EU)

The heart of your secure small office

wired and wireless network

An Internet connec-

tion-sharing Router,

Switch, and Access

Point with built-in VPN

endpoint capability

and advanced secu-

rity features

Advanced Security:

Wireless data encryp-

tion (WEP), 802.1x

authentication and

authorization support,

SPI Firewall and Internet

Access filtering

Jump start your small

business network by

connecting both

Wireless-G (802.11g)

PCs, and local wired

PCs

Securely connect up

to 50 remote or

traveling users to your

office network via VPN

The Wireless-G VPN Broadband Router is the advanced, complete

networking solution for your small business, incorporating four

essential networking functions in one high-powered box. First, there’s

the Wireless Access Point, which lets you connect Wireless-G

(802.11g) or Wireless-B (802.11b) devices to the network. There’s also

a built-in 4-port full-duplex 10/100 Switch to connect your wired-

Ethernet devices. Connect four PCs directly, or daisy-chain out to

more hubs and switches to create as big a network as you need.

Third, the Router function ties it all together and lets your whole

network share a high-speed cable or DSL Internet connection. And

finally, the Virtual Private Network (VPN) function creates encrypted

“tunnels” through the Internet so up to 50 remote or traveling users

can securely connect to your office network from off-site, or users in

your branch office can connect to a corporate network.

To protect your data and privacy, the Wireless-G VPN Broadband

Router can encrypt all wireless transmissions with 128-bit WEP

encryption, and also supports the industrial-strength wireless security

of 802.1x authentication and authorization. The Router can serve as

a DHCP Server, and has a powerful SPI firewall to protect your PCs

against intruders and most known Internet attacks. It can be

configured to filter internal users’ access to the Internet, and has

MAC or IP address filtering so you can specify exactly who has

access to your network. Configuration is a snap with the web

browser-based configuration utility.

As the center point of your office network, the Linksys Wireless-G VPN

Broadband Router gives you the flexibility, speed, and security you

need!

VPN Broadband Router

Wireless-G

Model No.

Product Data

Model No.

Features

• Complies with IEEE 802.11g

and 802.11b standards

• Advanced security features

including DoS prevention,

MAC filtering, SPI firewall and

802.1x authentication

• Supports up to 50 IPSec VPN

tunnels

Linksys

Web: http://www.linksys.com/international

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional Offices

throughout the world. For a complete list of local

Linksys Sales and Technical Support contacts, visit

our Worldwide Web Site at

www.linksys.com/international.

WRV54G (UK/EU)

Package Contents

• Wireless-G VPN Broadband Router

• Setup Wizard CD-ROM

• User Guide on CD-ROM

•NetworkCable

• Adapter Stands

• Power Supply

• Quick Installation

VPN Broadband Router

Wireless-G

Minimum Requirements

• 200MHz or Faster Processor

• 64MB of RAM

• CD-ROM Drive

• Internet Explorer 4.0 or Netscape 4.7 or

Higher for Web-Based Configuration

• 802.11gor802.11bCompliantWireless

Network Adapter

Ethernet Network Adapter

Specifications

Model Number WRV54G

Standards IEEE 802.11b, IEEE 802.11g, IEEE 802.3,

IEEE 802.3u

Ports Internet, Ethernet (1, 2, 3, 4), Power

Buttons Power, Reset

Cabling Type UTP CAT 5

LEDs Power, Internet, LAN (1, 2, 3, 4),

Wireless-G, DMZ

Transmit Power 19 dBm

UPnP able/cert Able

Security Features WEP, 802.1x Authentication

WEP Key Bits 64, 128

Environmental

Dimensions 186 mm x 175 mm x 48 mm

W x H x D (7,32" x 6,89" x 1,89")

Unit Weight 0,57 kg (20,11 oz.)

Power 5V, 2,5A

Certifications FCC, IC-03, CE

Operating Temp. 0ºC to 40ºC (32ºF to 104ºF)

Storage Temp. -20ºC to 70ºC (-4ºF to 158ºF)

Operating Humidity 10% to 85%, Non-Condensing

Storage Humidity 5% to 90%, Non-Condensing

Warranty Three Year

WRV54G-UK/EU-DS-31111NC JL
