Cisco Catalyst IW9167I Manuel

Cisco Catalyst IW9167I Heavy Duty Access Point Hardware Installation

Guide

First Published: 2023-10-18

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

CONTENTS

Preface vii

PREFACE

About this Guide vii

Conventions vii

Related Documentation viii

Communications, Services, and Additional Information viii

Cisco Bug Search Tool viii

Documentation Feedback viii

About Cisco Catalyst IW9167I Heavy Duty Access Point 1

CHAPTER 1

Introduction to Cisco Catalyst IW9167I Heavy Duty Access Point 1

Cisco Catalyst IW9167I Heavy Duty Access Point Features 1

Connectors and Ports 2

4-Pin Micro-Fit Connector for DC Power 3

M12-RJ45 Adapter 3

M12-PWR Adapter 4

Power Sources 5

Power Adapters 5

Power Injectors 6

Ethernet (PoE) Ports 6

SFP Option 6

Antennas and Radios 7

Internal Antennas and GNSS Receiver 7

IW9167I (Internal Antenna) Radiation Patterns 8

Unpacking Your Access Point 13

CHAPTER 2

Package Contents 13

Cisco Catalyst IW9167I Heavy Duty Access Point Hardware Installation Guide

iii

Unpacking the Access Point 13

Cisco Orderable Accessories 13

Installation Overview 15

CHAPTER 3

Performing a Preinstallation Configuration (Optional) 15

Preinstallation Checks and Installation Guidelines 17

Mounting the Access Point 18

Mounting Hardware 18

Mounting Bracket Part Numbers 18

Using the Integrated Flange Mounts 19

Using the DIN Rail Mounting Bracket 20

Pole Mounting the AP with Horizontal Bracket 23

Using the Pole Mounting Bracket 24

Using the Mounting Bracket AIR-ACCPMK3700= 24

Using the Mounting Bracket AIR-ACCPMK3700-2= 25

Attaching a Power Adapter 30

Attaching a Power Adapter Using the Mounting Bracket AIR-ACCPMK3700= 30

Attaching a Power Adapter Using the Mounting Bracket AIR-ACCPMK3700-2= 31

Grounding the Access Point 33

Powering the Access Point 34

Power Feature Matrix 35

Connecting a Power Injector 35

Connecting to the DC Power Port Using Cable Gland 36

Connecting DC Power Port Using M12 Adapter 37

Connecting Data Cables 39

Connecting an Ethernet Cable to the Access Point 39

Connecting to the RJ45 Port Using Cable Gland 39

Connecting to the RJ45 Port Using M12 Adapter 40

Connecting to the SFP Port of the Access Point 42

Connecting to SFP Port Using Cable Gland 42

Using M12 Adapter on SFP Port 44

Configuring and Deploying the Access Point 47

CHAPTER 4

Controller Discovery Process 47

Cisco Catalyst IW9167I Heavy Duty Access Point Hardware Installation Guide

Contents

Deploying the Access Point in a Wireless Network 48

Checking the Access Point LEDs 48

Troubleshooting 51

CHAPTER 5

Using the Reset Button 51

Troubleshooting the Access Point to Controller Join Process 51

Important Information for Controller-based Deployments 52

Configuring DHCP Option 43 52

Safety Guidelines and Warnings 55

CHAPTER 6

Safety Instructions 55

FCC Safety Compliance Statement 56

Safety Precautions 56

Avoiding Damage to Radios in a Testing Environment 57

Performing Site Surveys 57

Declarations of Conformity and Regulatory Information 59

CHAPTER 7

Manufacturers Federal Communications Commission Declaration of Conformity Statement 59

Operation of Cisco Catalyst Access Points in México 60

VCCI Statement for Japan 60

Statement 191—Voluntary Control Council for Interference (VCCI) Class A Warning for Japan 60

ステートメント 191—日本向けVCCI クラス Aに関する警告 61

Guidelines for Operating Cisco Catalyst Access Points in Japan 61

Compliance Statement for Canada 62

Industry Canada 62

European Community, Switzerland, Norway, Iceland, and Liechtenstein 62

United Kingdom Compliance 63

Administrative Rules for Cisco Catalyst Access Points in Taiwan 64

Declaration of Conformity for RF Exposure 64

Generic Discussion on RF Exposure 64

This Device Meets International Guidelines for Exposure to Radio Waves 65

This Device Meets FCC Guidelines for Exposure to Radio Waves 65

This Device Meets the Industry Canada Guidelines for Exposure to Radio Waves 66

Cisco Catalyst IW9167I Heavy Duty Access Point Hardware Installation Guide

Contents

Cet appareil est conforme aux directives internationales en matière d'exposition aux fréquences

radioélectriques 66

Additional Information on RF Exposure 67

Declaration of Conformity Statements 67

Cisco Catalyst IW9167I Heavy Duty Access Point Hardware Installation Guide

Contents

Preface

This preface describes this guide and provides information about the conventions used in this guide, and

Related Documentation

CHAPTER 1

About Cisco Catalyst IW9167I Heavy Duty Access

Point

•Introduction to Cisco Catalyst IW9167I Heavy Duty Access Point, on page 1

•Cisco Catalyst IW9167I Heavy Duty Access Point Features, on page 1

•Connectors and Ports, on page 2

•Power Sources, on page 5

•SFP Option, on page 6

•Antennas and Radios, on page 7

Introduction to Cisco Catalyst IW9167I Heavy Duty Access Point

The Cisco Catalyst IW9167I Heavy Duty Access Point (hereafter referred to as IW9167I) is designed to make

wireless deployments simple in outdoor and industrial environments. It is built with a cast-aluminum case

that can handle water, dust, and extreme temperatures. It includes built-in antennas and supports Wi-Fi 6E to

enable higher density, higher throughput, more channels, power efficiency, and improved security.

IW9167I includes 6 GHz hardware support.

The AP hardware is supported on the following platforms:

• Cisco DNA Center on-premises

• Cisco Catalyst stack

A full listing of the AP's features and specifications is provided in the Cisco Catalyst IW9167 Heavy Duty

Access Point Data Sheet.

Cisco Catalyst IW9167I Heavy Duty Access Point Features

The Cisco Catalyst IW9167I Heavy Duty Access Point has the following features:

• 2 GB DDR4 memory, 1 GB NAND Flash

• Tri radios—2.4 GHz, 5 GHz, 6 GHz

• Integrated antenna—2.4 GHz 4x4:4SS, 5 GHz 4x4:4SS, 6 GHz 4x4:4SS,

Cisco Catalyst IW9167I Heavy Duty Access Point Hardware Installation Guide

• 2.4 GHz IoT Bluetooth Low Energy (BLE) radio

• Integrated GNSS

• 1 x multi-Gigabit (mGig) copper Ethernet port (supporting PoE, including IEEE 802.3at/bt, Cisco UPoE,

100 Mbps/1 Gbps/2.5 Gbps/5 Gbps)

• 1 x SFP interface—Supports up to 10 Gbps

• Optional M12 adapter for network and power interfaces

• Dual power input options—PoE-in and 24 - 48VDC

• Dual mounting options—Pole or wall mount

• IP67 rating

• Indoor and outdoor mode operation supported in different countries as shown in the following table:

Indoor and outdoorFCC

OutdoorIC

Indoor and outdoorCE

OutdoorC-tick

OutdoorTelec

Connectors and Ports

The following figure shows the available ports on the AP front panel.

Figure 1: IW9167I Front Panel Connectors and Ports

Cisco Catalyst IW9167I Heavy Duty Access Point Hardware Installation Guide

About Cisco Catalyst IW9167I Heavy Duty Access Point

Connectors and Ports
