Cisco Aironet 600 Series Manuel utilisateur
Cisco Systems, Inc.
www.cisco.com
Cisco has more than 200 offices worldwide.
Addresses, phone numbers, and fax numbers
are listed on the Cisco website at
www.cisco.com/go/offices.
Cisco Aironet 600 Series OfficeExtend
Access Point User Guide
Last Updated: August 2014
Text Part Number: OL-29882-03
THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL
STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT
WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT
SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE
OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.
The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public
domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California.
NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH
ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT
LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF
DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING,
WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO
OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this
URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership
relationship between Cisco and any other company. (1110R)
Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display
output, network topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in
illustrative content is unintentional and coincidental.
Cisco Aironet 600 Series OfficeExtend Access Point User Guide
© 2005-2014 Cisco Systems, Inc. All rights reserved.
iii
Cisco Aironet 600 Series OfficeExtend Access Point User Guide
OL-29882-03
CONTENTS
Preface v
Audience v
Document Organization v
Conventions vi
Related Documentation vi
CHAPTER
1Unpacking and Installing the Access Point 1-1
Unpacking the Access Point 1-1
Placing the Access Point 1-1
Parts of the Access Point 1-3
Installing the Access Point 1-4
Resetting the Access Point 1-5
Understanding the Access Point LEDs 1-5
CHAPTER
2Access Point GUI 2-1
Accessing the GUI 2-1
Home Page 2-2
AP Info 2-3
SSID 2-3
Client 2-4
Configuration Page 2-4
System Tab 2-6
SSID Tab 2-7
DHCP Tab 2-8
WAN Tab 2-8
Firewall 2-9
Download/Upload 2-12
Event Log Page 2-13
Network Diagnostics 2-13
CHAPTER
3Configuring the Access Point 3-1
Configuring the Wireless LAN Controller IP Address on the Access Point 3-1
Configuring Radio Channels on the Access Point 3-2
Contents
iv
Cisco Aironet 600 Series OfficeExtend Access Point User Guide
OL-29882-03
Configuring Personal Wireless LANs 3-3
Troubleshooting 3-4
CHAPTER
4Functionalities of the Access Point 4-1
Using the Split Tunneling Feature for Local Printing 4-1
Prerequisites for Adding a Local Printer 4-1
Adding the Local Printer in Windows 4-2
Adding the Local Printer in Mac OS 4-3
CHAPTER
5Declarations of Conformity and Regulatory Information 5-1
Manufacturers Federal Communication Commission Declaration of Conformity Statement 5-1
Industry Canada 5-2
Canadian Compliance Statement 5-2
European Community, Switzerland, Norway, Iceland, and Liechtenstein 5-3
Declaration of Conformity with Regard to the 1999/5/EC (R&TTE Directive) 5-3
Operation of Cisco Aironet Access Points in Brazil 5-6
Access Point Models 5-6
Regulatory Information 5-6
Portuguese Translation 5-7
English Translation 5-7
Declaration of Conformity for RF Exposure 5-7
Declaration of Conformity Statements 5-7
v
Cisco Aironet 600 Series OfficeExtend Access Point User Guide
OL-29882-03
Preface
The Preface contains the following sections:
•Audience, page v
•Document Organization, page v
•Conventions, page vi
•Related Documentation, page vi
Audience
This document is for experienced network administrators who configure and maintain Cisco wireless
LAN controllers and Cisco lightweight access points. It contains information useful to users who
connect to a network via a Cisco Aironet 600 Series OfficeExtend Access Point, which is referred to as
the access point or as the AP in this document.
Document Organization
The following table describes the contents of each chapter in this document:
Table 1 Document Organization
Chapter and Title Description
Chapter 1, “Unpacking and
Installing the Access Point”
This chapter provides information on unpacking and installing the
access point. It also gives you instructions on placement, and a
description of the parts of the access point.
Chapter 2, “Access Point GUI” This chapter describes the various pages in the access point’s GUI.
Chapter 3, “Configuring the
Access Point”
This chapter provides information on how to configure the access
point for use.
Chapter 4, “Functionalities of
the Access Point”
This chapter provides information about certain end-user
functionalities provided via the access point, including those which
are accessed via other external systems.
Chapter 5, “Declarations of
Conformity and Regulatory
Information”
This chapter contains declarations of conformity and regulatory
information for the Cisco Aironet 600 Series OfficeExtend Access
Point.
vi
Cisco Aironet 600 Series OfficeExtend Access Point User Guide
OL-29882-03
Conventions
The following table describes conventions used in this document:
Note Means reader needs to take note. Notes contain helpful suggestions or references to material not covered
in the manual.
Tip Means the following information will help you solve a problem.
Caution Means reader needs to be careful. In this situation, you might perform an action that could result in
equipment damage or loss of data.
Related Documentation
In addition to the information provided in this publication, you might need to refer to the following
documents:
•Cisco Wireless LAN Controller configuration guides.
http://www.cisco.com/en/US/products/ps10315/products_installation_and_configuration_guides_l
ist.html
•Cisco Wireless LAN Controller command references.
http://www.cisco.com/en/US/products/ps10315/prod_command_reference_list.html
•Cisco Wireless LAN Controller System Message Guide.
http://www.cisco.com/en/US/products/ps10315/products_system_message_guides_list.html
Table 2 Command Syntax Guide
Convention Description
boldface Commands and keywords.
italic Command input that is supplied by you.
[ ] Keywords or arguments that appear within square brackets are optional.
{ x | x | x } A choice of keywords (represented by x) appears in braces separated by
vertical bars. You must select one.
^ or Ctrl Represent the key labeled Control. For example, when you read ^D or
Ctrl-D, you should hold down the Control key while you press the D key.
screen font Examples of information displayed on the screen.
boldface screen font Examples of information that you must enter.
< > Nonprinting characters, such as passwords, appear in angled brackets.
[ ] Default responses to system prompts appear in square brackets.
vii
Cisco Aironet 600 Series OfficeExtend Access Point User Guide
OL-29882-03
•Release Notes for Cisco Wireless LAN Controllers and Lightweight Access Points.
http://www.cisco.com/en/US/products/ps10315/prod_release_notes_list.html
viii
Cisco Aironet 600 Series OfficeExtend Access Point User Guide
OL-29882-03
CHAPTER
1-1
Cisco Aironet 600 Series OfficeExtend Access Point User Guide
OL-29882-03
1
Unpacking and Installing the Access Point
This chapter provides the following information:
•Unpacking the Access Point, page 1-1
•Placing the Access Point, page 1-1
•Parts of the Access Point, page 1-3
•Installing the Access Point, page 1-4
•Resetting the Access Point, page 1-5
•Understanding the Access Point LEDs, page 1-5
Unpacking the Access Point
Each Cisco Aironet 600 Series OfficeExtend Access Point package contains the following items:
•Cisco Aironet 600 Series OfficeExtend Access Point
•Ethernet Cable
•Cisco Aironet AP600 Series Power Module (universal power supply)
•Quick reference guide
•Cisco product registration and Cisco documentation feedback cards
Placing the Access Point
To ensure the best RF coverage for your access point, place your access point in an area as close to the
wireless clients as possible and practical to do so.
If the Internet source or gateway router is in a remote area, position your access point away from metal
obstructions.
The access point can be placed/mounted in a horizontal position, as the access point has rubber feet on
its bottom panel.
The access point may also be mounted in a vertical position using the supplied cradle or wall mounted
slots.
Note The distance between the mounting hole slots is 158.75 mm (6.25 in).
1-2
Cisco Aironet 600 Series OfficeExtend Access Point User Guide
OL-29882-03
Chapter 1 Unpacking and Installing the Access Point
Placing the Access Point
Areas to avoid or places that may result in reduced range or performance are as follows.
•In a basement of a multi-story home, as the signals must penetrate many walls.
•Near large obstructions that can block the radio signals. Avoid areas like metal cabinets or
refrigerators.
•On the floor under a metal desk or other dense or conductive objects.
Note Cisco is not responsible for damages occurred by unsecured wall-mounting hardware.
