CHAPTER

1-1

Cisco ATA 186 and Cisco ATA 188 Analog Telephone Adaptor Administrator’s Guide for MGCP (version 3.0)

OL-4803-01

Cisco Analog Telephone Adaptor Overview

This section describes the hardware and software features of the Cisco Analog Telephone Adaptor

(Cisco ATA) and includes a brief overview of the Media Gateway Control Protocol (MGCP).

Cisco ATA analog telephone adaptors are handset-to-Ethernet adaptors which allow regular analog

telephones to operate on IP-based telephony networks. Cisco ATAs support two voice ports, each with

an independent telephone number. The Cisco ATA 188 also has an RJ-45 10/100BASE-T data port.

This section covers the following topics:

•Overview of Media Gateway Control Protocol, page 1-2

•Hardware Overview, page 1-3

•Software Features, page 1-5

•Installation and Configuration Overview, page 1-9

Figure 1-1 Cisco ATA Analog Telephone Adaptor

The Cisco ATA, which operates with Cisco voice-packet gateways, makes use of broadband pipes that

are deployed by means of a digital subscriber line (DSL), fixed wireless cable modem, and other Ethernet

connections.

Note The term Cisco ATA refers to both the Cisco ATA 186 and the Cisco ATA 188, unless otherwise stated.

72209

ANALOG TELEPHONE ADAPTOR

CISCO ATA 186

1-2

Cisco ATA 186 and Cisco ATA 188 Analog Telephone Adaptor Administrator’s Guide for MGCP (version 3.0)

OL-4803-01

Chapter 1 Cisco Analog Telephone Adaptor Overview

Overview of Media Gateway Control Protocol

Figure 1-2 The Cisco ATA 186 as an Endpoint in an MGCP Network

Figure 1-3 The Cisco ATA 188 as an Endpoint in an MGCP Network

Overview of Media Gateway Control Protocol

The Media Gateway Control Protocol (MGCP) is the Internet Engineering Task Force (IETF) standard

for multimedia conferencing over IP. MGCP is an ASCII-based, application-layer control protocol

(defined in RFC2705) that can be used to establish, maintain, and terminate calls between two or more

endpoints.

Like other VoIP protocols, MGCP is designed to address the functions of signaling and session

management within a packet telephony network.

Signaling allows call information to be carried across network boundaries. Session management

provides the ability to control the attributes of an end-to-end call.

One aspect of MGCP that differs from other VoIP protocols is that MGCP endpoints rely on instructions

from a Call Agent to control call progression, call tones, and call characteristics.

MGCP provides the following capabilities to the control server:

•Determines the location of the target endpoint.

•Determines the media capabilities of the target endpoint. Using Session Description Protocol (SDP),

MGCP determines the lowest level of common service between the endpoints. Conferences are

established using only the media capabilities that can be supported by all endpoints.

Cisco ATA 186

Telephone/fax Ethernet

Broadband CPE

(DSL, cable,

fixed wireless)

Broadband

Call Agent

Layer 3

IP infrastructure PSTN

Voice

gateway

82127

Cisco ATA 188

Telephone/fax Ethernet

Broadband CPE

(DSL, cable,

fixed wireless)

Broadband

Call Agent

Layer 3

IP infrastructure PSTN

Voice

gateway

82128

1-3

Cisco ATA 186 and Cisco ATA 188 Analog Telephone Adaptor Administrator’s Guide for MGCP (version 3.0)

OL-4803-01

Chapter 1 Cisco Analog Telephone Adaptor Overview

Hardware Overview

•Determines the availability of the target endpoint.

•Establishes a session between the originating and target endpoint if a call can be completed. MGCP

also supports mid-call changes, such as adding another endpoint to the conference or changing a

media characteristic or codec.

•Each MGCP endpoint supports up to two connections per device. Each connection has a fixed

ID—0, 1, 2, or 3. Connection IDs 0 and 2 are assigned to MGCP Endpoint 0, and connection IDs 1

and 3 are assigned to MGCP Endpoint 1.

MGCP is a client-server protocol. The Call Agent handles all aspects of setting up calls to and from

endpoints. Call Agents or control servers provide the feature capabilities that a particular endpoint uses.

Endpoints connected to different Call Agents likely will have a different set of features.

Each control-server vendor determines its own set of features.

Hardware Overview

The Cisco ATA 186 and Cisco ATA 188 are compact, easy-to-install devices. Figure 1-4 shows the rear

panel of the Cisco ATA 186. Figure 1-5 shows the rear panel of the Cisco ATA 188.

Figure 1-4 Cisco ATA 186—Rear View

Figure 1-5 Cisco ATA 188—Rear View

10BaseT ACT 5VPHONE 1 PHONE 2

72210

RJ-11 FXS ports

RJ-45 10BaseT ACT LED

Power

connector

10/100 UPLINK10/100 PC LINKLINK 5VPHONE 1 PHONE 2

72211

RJ-11 FXS ports LINK LED

Power

connector

LINK LED

RJ-45 10/100BaseT ports

1-4

Cisco ATA 186 and Cisco ATA 188 Analog Telephone Adaptor Administrator’s Guide for MGCP (version 3.0)

OL-4803-01

Chapter 1 Cisco Analog Telephone Adaptor Overview

Hardware Overview

The unit provides the following connectors and indicators:

•5V power connector.

•Two RJ-11 FXS (Foreign Exchange Station) ports—The Cisco ATA supports two independent RJ-11

telephone ports that can connect to any standard analog telephone device. Each port supports either

voice calls or fax sessions, and both ports can be used simultaneously.

Note The Cisco ATA186-I1 and Cisco ATA188-I1 provide 600-ohm resistive impedance. The Cisco

ATA186-I2 and Cisco ATA188-I2 provide 270 ohm + 750 ohm // 150-nF complex impedance.

The impedance option is requested when you place your order and should match your specific

application. If you are not sure of the applicable configuration, check your country or regional

telephone impedance requirements.

•Ethernet ports

–

The Cisco ATA 186 has one RJ-45 10BASE-T uplink Ethernet port to connect the

Cisco ATA 186 to a 10/100BASE-T hub or another Ethernet device.

–

The Cisco ATA 188 has two Ethernet ports: an RJ-45 10/100BASE-T uplink port to connect the

Cisco ATA 188 to a 10/100BASE-T hub or another Ethernet device and an RJ-45

10/100BASE-T data port to connect an Ethernet-capable device, such as a computer, to the

network.

Note The Cisco ATA 188 performs auto-negotiation for duplexity and speed and is capable of

10/100 Mbps, full-duplex operation. The Cisco ATA 186 is fixed at 10 Mbps, half-duplex

operation.

•The Cisco ATA 188 RJ-45 LED shows network link and activity. The LED blinks twice when the

Cisco ATA is first powered on, then turns off if there is no link or activity. The LED blinks to show

network activity and is solid when there is a link.

•The Cisco ATA 186 RJ-45 LED is solid when the Cisco ATA is powered on and blinks to show

network activity.

•Function button—The function button is located on the top panel of the unit (see Figure 1-6).

Figure 1-6 Function Button

The function button lights when you pick up the handset of a telephone attached to the Cisco ATA.

The button blinks quickly when the Cisco ATA is upgrading its configuration.

ANALOG TELEPHONE ADAPTOR

CISCO ATA 186

72214

Function

button

1-5

Cisco ATA 186 and Cisco ATA 188 Analog Telephone Adaptor Administrator’s Guide for MGCP (version 3.0)

OL-4803-01

Chapter 1 Cisco Analog Telephone Adaptor Overview

Software Features

Note If the function button blinks slowly, the Cisco ATA cannot find the DHCP server. Check your

Ethernet connections and make sure the DHCP server is available.

Pressing the function button allows you to access to the voice configuration menu. For additional

information about the voice configuration menu, see the “Voice Configuration Menu” section on

page 3-20.

Caution Never press the function button during an upgrade process. Doing so may interfere with the process.

Software Features

The Cisco ATA supports the following protocols and services:

•MGCP Versions, page 1-5

•Voice Codecs Supported, page 1-5

•Additional Supported Signaling Protocols, page 1-6

•Other Supported Protocols, page 1-6

•Cisco ATA MGCP Services, page 1-6

•Fax Services, page 1-7

•Supplementary Services that the Cisco ATA Provides, page 1-7

•Supplementary Services that the Call Agent Provides, page 1-8

MGCP Versions

The Cisco ATA supports the following MGCP versions:

•MGCP 0.1

•MGCP 1.0

•NCS 1.0

Voice Codecs Supported

The Cisco ATA supports the following voice codecs (check your other network devices for the codecs

they support):

•G.711µ-law

•G.711A-law

•G.723.1

•G.729

1-6

Cisco ATA 186 and Cisco ATA 188 Analog Telephone Adaptor Administrator’s Guide for MGCP (version 3.0)

OL-4803-01

Chapter 1 Cisco Analog Telephone Adaptor Overview

Software Features

•G.729A

•G.729B

•G.729.AB

Additional Supported Signaling Protocols

In addition to MGCP, the Cisco ATA supports the following signaling protocols:

•Skinny Client Control Protocol (SCCP)

•H.323

•Session Initiation Protocol (SIP)

If you wish to perform a cross-protocol upgrade from MGCP to another signaling image, see the

“Upgrading the Signaling Image from a TFTP Server” section on page 7-1.

Other Supported Protocols

Other protocols that the Cisco ATA supports include the following:

•802.1Q VLAN tagging

•Cisco Discovery Protocol (CDP)

•Domain Name System (DNS)

•Dynamic Host Configuration Protocol (DHCP)

•Internet Control Message Protocol (ICMP)

•Internet Protocol (IP)

•Real-Time Transport Protocol (RTP)

•Transmission Control Protocol (TCP)

•Trivial File Transfer Protocol (TFTP)

•User Datagram Protocol (UDP)

Cisco ATA MGCP Services

For a list of required MGCP parameters as well as descriptions of all supported Cisco ATA MGCP

services and cross references to the parameters for configuring these services, see Chapter 4,

“Cisco ATA-Supported MGCP Services.”

These services include the following features:

•Two MGCP endpoints per Cisco ATA

•Two connections per MGCP endpoint

•Multiple audio codecs

•Events and signals available in MGCP software packages

•Automatic MGCP version detection

•Caller ID generation

1-7

Cisco ATA 186 and Cisco ATA 188 Analog Telephone Adaptor Administrator’s Guide for MGCP (version 3.0)

OL-4803-01

Chapter 1 Cisco Analog Telephone Adaptor Overview

Software Features

•Configurable tone (dial tone, busy tone, confirm tone, reorder tone, call waiting tone)

•IP address assignment—DHCP-provided or statically configured

•Cisco ATA configuration by means of a TFTP server, web browser, or voice configuration menu.

•VLAN configuration

•Caller ID format

•Ring cadence format

•Silence suppression

•Low-bit-rate codec selection

•RTP media port configuration

•Hook-flash detection timing configuration

•Cisco Discovery Protocol (CDP)

•User interface password

•Type of Service (ToS) configuration for audio and signaling ethernet packets

•Debugging and diagnostic tools

Fax Services

The Cisco ATA supports two modes of fax services, in which fax signals are transmitted using the G.711

codec:

•Fax pass-through mode—Receiver-side Called Station Identification (CED) tone detection with

automatic G.711A-law or G.711µ-law switching.

•Fax mode—The Cisco ATA is configured as a G.711-only device.

How you set Cisco ATA fax parameters depends on what network gateways are being used. You may

need to modify the default fax parameter values (see Chapter 6, “Configuring and Debugging Fax

Services”).

Note Success of fax transmission depends on network conditions and fax modem response to these conditions.

The network must have reasonably low network jitter, network delay, and packet loss rate.

Supplementary Services that the Cisco ATA Provides

Table 1-1 lists the supplementary phone services that the Cisco ATA provides for MGCP. Table 1-1

includes links to the corresponding parameters that allow you to configure these services.

Table 1-1 Supplementary Services that Require Configuration on the Cisco ATA

Service Parameter

Caller ID CallerIdMethod, page 5-21

Call Waiting SigTimer, page 5-26

Call-Waiting-Caller ID CallerIdMethod, page 5-21, SigTimer, page 5-26

Three-way Conference ConnectMode, page 5-24—Bit 23

1-8

Cisco ATA 186 and Cisco ATA 188 Analog Telephone Adaptor Administrator’s Guide for MGCP (version 3.0)

OL-4803-01

Chapter 1 Cisco Analog Telephone Adaptor Overview

Software Features

Supplementary Services that the Call Agent Provides

The Cisco ATA supports the following services that are provided by the Call Agent:

Note For end-user information on how these services work, consult the documentation from the MGCP Call

Agent service provider.

•Anonymous Call Rejection

•Call forward—on busy

•Call forward—on no answer

•Call forward—unconditional

•Call hold

•Caller ID

•Calling Line Identification Presentation

•Calling Line Identification Restriction

•Call return

•Call transfer—Blind

•Call transfer—Consultation

•Call waiting

•Call waiting Caller ID

•Distinctive ringing

•Message-waiting-indication (stuttering dial tone)

•Speed dial

•Three-way conference

•Voice mail

1-9

Cisco ATA 186 and Cisco ATA 188 Analog Telephone Adaptor Administrator’s Guide for MGCP (version 3.0)

OL-4803-01

Chapter 1 Cisco Analog Telephone Adaptor Overview

Installation and Configuration Overview

Table 1-2 provides the basic steps required to install and configure the Cisco ATA to make it operational

in a typical MGCP environment.

Table 1-2 Overview of the Steps Required to Install and Configure the Cisco ATA and Make it Operational

Action Reference

1. Plan the network and Cisco ATA configuration.

2. Install the Ethernet connection.

3. Install and configure the other network devices.

4. Install the Cisco ATA but do not power up the Cisco ATA yet. What the Cisco ATA Package Includes, page 2-2

5. Download the desired Cisco ATA release software zip file from

the Cisco web site, then configure the Cisco ATA.

Chapter 3, “Configuring the Cisco ATA for MGCP”

6. Power up the Cisco ATA.

7. Periodically, you can upgrade the Cisco ATA to a new signaling

image by using the TFTP server-upgrade method or the

manual-upgrade method.

Chapter 7, “Upgrading the Cisco ATA Signaling

Image”

1-10

Cisco ATA 186 and Cisco ATA 188 Analog Telephone Adaptor Administrator’s Guide for MGCP (version 3.0)

OL-4803-01

Chapter 1 Cisco Analog Telephone Adaptor Overview

Installation and Configuration Overview

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Cisco Téléphone

Cisco

Cisco SPA525 Mode d’emploi

Cisco

Cisco Cisco 7940 Manuel d'instructions

Cisco

Cisco SPA502 Manuel utilisateur

Cisco

Cisco 8800 Series Manuel utilisateur

Cisco

Cisco 7841 Manuel utilisateur

Cisco

Cisco Small Business Pro SPA 504G Manuel utilisateur

Cisco

Cisco Small Business Pro SPA 504G Manuel utilisateur

Cisco

Cisco 8945 Manuel de l'opérateur

Cisco

Cisco DATAVOX 7941 Manuel utilisateur

Cisco

Cisco UNIFIED 9971 Manuel utilisateur

Cisco

Cisco 7841 Manuel utilisateur

Cisco

Cisco SPA525G - Small Business Pro IP Phone VoIP Manuel utilisateur

Cisco

Cisco i3 Manuel utilisateur

Cisco

Cisco E20 Manuel utilisateur

Cisco

Cisco SPA525G - Small Business Pro IP Phone VoIP Guide de sécurité

Cisco

Cisco 8841 Manuel utilisateur

Cisco

Cisco Webex 840 Manuel utilisateur

Cisco

Cisco 7931G - Unified IP Phone VoIP Manuel utilisateur

Cisco

Cisco Small Business Pro SPA 504G Guide de référence

Cisco

Cisco Unified 6921 Manuel utilisateur

Cisco

Cisco MPP 6851 Manuel

Cisco

Cisco 7911G - IP Phone VoIP Manuel utilisateur

Cisco

Cisco 8851 Manuel utilisateur

Cisco

Cisco 8800 Series Manuel utilisateur

Manuels Téléphone populaires d'autres marques

GE 2-9480 Manuel utilisateur

Geemarc

Geemarc PHOTOPHONE 155 Manuel utilisateur

D-Link

D-Link DWR-720/PW Manuel utilisateur

Interquartz

Interquartz Gemini IQ333 Manuel utilisateur

SSS Siedle

SSS Siedle HT 840-0 Manuel utilisateur

Motorola

Motorola TITANIUM Manuel utilisateur

Panasonic

Panasonic ICX Manuel utilisateur

LG H870DS Manuel utilisateur

Samsung

Samsung GT-I9500 Manuel utilisateur

AT&T

AT&T Trimline 205 Manuel utilisateur

Selta

Selta zenyth 600 Manuel utilisateur

Doro

Doro AFTI 20 Manuel utilisateur

UNIQCELL

UNIQCELL A1 Manuel utilisateur

Panasonic

Panasonic KX Series Manuel utilisateur

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manuel utilisateur

BT Decor 425 Manuel utilisateur

NEC

NEC SV8500 Manuel utilisateur

Teledex

Teledex PEARL Manuel utilisateur
